Summary of Contents for Brunner I048145
Page 1
Support frame for sus- pended fireplaces Assembly instructions...
Page 2
CONTENTS Delivery contents............4 Designation of components......... 6 Necessary tools:............6 Sequence of assembly..........7 Assembly instructions Support frame for suspended fireplaces (1.0) © 2015 Brunner GmbH...
Page 3
© 2015 Brunner GmbH Assembly instructions Support frame for suspended fireplaces (1.0)
Page 4: Delivery Contents
DELIVERY CONTENTS Support frame assembly (art. no.: I048145) Item Quan- Designation Part no. tity Right girder assembly I048135 Left girder assembly I048138 Support frame connecting I048141 rod assembly Support frame distance I048137 tube M12 draw rod I048139 M12 washer M12 hex locking nut...
Page 5
Firetable support beam I048155 Illustr. 2: Delivery contents overview assembly (I048167) Firetable hanging con- I048156 soles M12x80 hex bolt 800421 M12 hex nut 800422 Supporting bracket I048168 M12x30 hex bolt © 2015 Brunner GmbH Assembly instructions Support frame for suspended fireplaces (1.0)
Page 6: Designation Of Components
- 2 wrenches for hex bolts size no. 17 - 2 wrenches for hex bolts size no. 19 - 1 wrench for hex bolts size no. 22 - Hammer - Punch - Spirit level Assembly instructions Support frame for suspended fireplaces (1.0) © 2015 Brunner GmbH...
Page 7: Sequence Of Assembly
M12 nuts and washers. Mount only the two connecting rod assemblies first. Illustr. 4: Support frame with two connecting rods © 2015 Brunner GmbH Assembly instructions Support frame for suspended fireplaces (1.0)
Page 8
The height of the back plate can be adjusted by turning the turnbuckles. Illustr. 7: Height adjust- ment Assembly instructions Support frame for suspended fireplaces (1.0) © 2015 Brunner GmbH...
Page 9
Establishing height for back plate support adjustment: The distance of the door frame to the finished floor depends from the height adjustment of the back plate. © 2015 Brunner GmbH Assembly instructions Support frame for suspended fireplaces (1.0)
Page 10
= Distance of feet to bottom of floor Soll fireplace OK = Top level H-Au- = Distance of concrete floor to flager supporting level H-Oberkante Blende = Distance between FFB and door frame Assembly instructions Support frame for suspended fireplaces (1.0) © 2015 Brunner GmbH...
Page 11
The parts used for height adjustment – turnbuckles and hooks – (see point 3.) must be removed along with the M10 threaded rods. The turnbuckles and hooks are needed later for mounting the top door frame. © 2015 Brunner GmbH Assembly instructions Support frame for suspended fireplaces (1.0)
Page 12
- Position the fireplace in the center of the sup- port frame. Assembly instructions Support frame for suspended fireplaces (1.0) © 2015 Brunner GmbH...
Page 13
The brace is mounted onto the stiffening profile and attached with a M10x16 screw ( see Illustr. 2 - pos. 1.9). © 2015 Brunner GmbH Assembly instructions Support frame for suspended fireplaces (1.0)
Page 14
55mm (dimension 'H-Fuß' < 55mm). 10. Mount the top door frame Designation of components Illustr. 19: Detail K Illustr. 18: Mounting of top door frame/support Assembly instructions Support frame for suspended fireplaces (1.0) © 2015 Brunner GmbH...
Page 15
- Affix the girder to the building wall behind the fireplace If possible, use steel anchors to attach the girders on both sides to the building wall. Use the protruding flaps 44 ()see Illustr. 19 for this. © 2015 Brunner GmbH Assembly instructions Support frame for suspended fireplaces (1.0)
Page 16
- Provide suspension Threaded rods (see Illustr. 19 - 32) must be shortened to desired length; combine the turnbuckles with hooks (33+34) and attach at suspension points (42). Assembly instructions Support frame for suspended fireplaces (1.0) © 2015 Brunner GmbH...
Page 17
- Leveling the top door frame Illustr. 28: Turn the turnbuckles on both sides until the door frame is leveled in every direction © 2015 Brunner GmbH Assembly instructions Support frame for suspended fireplaces (1.0)
Page 18
Illustr. 31: The connection and the fireplace cladding. between top door frame and fireplace is lost af- ter the screws 31 are re- moved Assembly instructions Support frame for suspended fireplaces (1.0) © 2015 Brunner GmbH...
Page 19
After the horizontal position is set, tighten the bolts 4 (see picture: Detail S and picture: 'Mount- ing parts of firetable support') up to the support- ing bracket 6 and secure with nuts 5. © 2015 Brunner GmbH Assembly instructions Support frame for suspended fireplaces (1.0)
Page 20
The necessary substructure for the firetable is set onto the consoles. The height is only approx. 70mm – depending on the height setting choice. Illustr. 36: Firetable sec- tion Assembly instructions Support frame for suspended fireplaces (1.0) © 2015 Brunner GmbH...
Page 21
Under heavy load the firetable support will react with elasticity. Ulrich Brunner GmbH Zellhuber Ring 17-18 D-84307 Eggenfelden Tel.: +49 (0) 8721/771-0 Fax: +49 (0) 8721/771-100 Email: info@brunner.eu Art. No.: XXXXX © 2015 Brunner GmbH Assembly instructions Support frame for suspended fireplaces (1.0)
