  • Page 1 Installation Guide Urfeuer Panorama 50-44-88-44 ©2023...

  • Page 2: Table Of Contents

    Basic information....................... 3 Product description....................4 Precautionary statements..................4 Delivery contents....................... 6 Assemblies........................7 Assembly........................15 Setting up............................ 15 Preparation of combustion chamber................... 19 Combustion chamber........................20 Deflector plate..........................23 Ember protection strip......................... 23 Drawings and technical data.................. 24 (1.11) © 2023 Brunner GmbH...

  • Page 3: Basic Information

    - which can only be used as an open fireplace As producer, BRUNNER provides manufacturer’s data to insure fire security and the right dimensions of the chimney system. With this information, the responsible regional chimney sweepers are able to approve and permit the installation of an Urfeuer.

  • Page 4: Product Description

    Replacement for the chapter 'In the radiant area of the fireplace insert' from 'General construction infor- mation“ of the Brunner products ment for the stove fitters': In the radiation area of the Urfeuer fireplace Parts made of flammable building materials or with...
  • Page 5 24 hours before disposal. Glowing embers can be found in ashes for a very long time. Chimney fire In case of fire call the fire brigade immediately! In the case of chimney fire move all flammable parts and elements away from the chimney. Watch out for flying sparks. © 2023 Brunner GmbH (1.11)

  • Page 6: Delivery Contents

    The basic device is delivered preassembled on a pallet. The combustion chamber linings are attached as a separate packing unit. Other components (combustion chamber extension plates, mounting frame, etc.) are delivered in further packing units. (1.11) © 2023 Brunner GmbH...

  • Page 7: Assemblies

    Panorama cover plate, short D021009 Spark mesh frame assembly side D021118 Front plate assembly D021013-02 Glowing embers protection UF50-44-66-44 strip D021004-02 Mounting frame complete as- 02450 Operating lever assembly sembly 800279 Hexagon nut M6 800496 Hexagon screw M6x60 © 2023 Brunner GmbH (1.11)
  • Page 8 Item Part No. Designation Pcs. Item Part No. Designation Pcs. D015096 Blind cover 250 D015097 Blind cover 280 D021017 Body welding assembly D021084 Pulley revision cover D020082 Revision cover for counter- D015120 Air intake nozzle d250 weights (1.11) © 2023 Brunner GmbH...
  • Page 9 Pcs. Item Part No. Designation Pcs. D021040 Shut-off flap 800386 Hexagon nut M8 800534 Bearing bush 00605 Washer 800176 Cylinder screw M8x25 D023042 Signal pin D024053 Shut-off reversing lever assembly 900826 Spring clip with groove © 2023 Brunner GmbH (1.11)
  • Page 10 D021071 Spark mesh guide rail D020099 Pulley suspension left side D021063 Cross-bracing for spark mesh D015038 Weight adjustment plate 2001902 Spark mesh counterweight wire D020091 Pulley suspension D021037 Spark mesh guide rollers D021030 Spark mesh bend (1.11) © 2023 Brunner GmbH...
  • Page 11 Flat head screw M5x16 Mounting frame Item Part No. Designation Pcs. D021076 Threaded rod M10 L=770mm 900102 Joint eye M10 Mounting frame upper cross- D021067-02 piece D021088-02 Narrow cover Mounting frame lower cross- D021053-02 piece © 2023 Brunner GmbH (1.11)
  • Page 12 Designation Pcs. Item Part No. Designation Pcs. D015166 Fire protection plate 3 D021057 Fire protection plate 1b D015091 Cast iron fireplace bottom plate 2 D015018 Fireplace bottom spacer D015005 Cast iron fireplace bottom plate 1 (1.11) © 2023 Brunner GmbH...
  • Page 13 Item Part No. Designation Pcs. 1.1 D015165 Combustion chamber wall lin- ing 3 1.2 800387 Hexagon screw M8x25 1.3 800386 Hexagon nut M8 1.4 800299 Hexagon screw M5x16 1.5 800002 Hexagon nut M5 © 2023 Brunner GmbH (1.11)
  • Page 14 Item Part No. Designation Pcs. 2.1 D021058 Combustion chamber wall lin- ing 1b 2.2 800387 Hexagon screw M8x25 2.3 800386 Hexagon nut M8 (1.11) © 2023 Brunner GmbH...

  • Page 15: Assembly

    ASSEMBLY SETTING UP © 2023 Brunner GmbH (1.11)
  • Page 16 (1.11) © 2023 Brunner GmbH...
  • Page 17 280 d 280 d 250 © 2023 Brunner GmbH (1.11)
  • Page 18 (1.11) © 2023 Brunner GmbH...

  • Page 19: Preparation Of Combustion Chamber

    PREPARATION OF COMBUSTION CHAMBER 20mm +/- 2mm 20mm +/- 2mm 10mm +/- 2mm 10mm +/- 2mm 10mm +/- 2mm 10mm +/- 2mm © 2023 Brunner GmbH (1.11)

  • Page 20: Combustion Chamber

    COMBUSTION CHAMBER 800386 800387 800002 800299 (1.11) © 2023 Brunner GmbH...
  • Page 21 D015091 D015091 D015018 D015018 D015005 D015005 D015091 D015091 © 2023 Brunner GmbH (1.11)
  • Page 22 D015091 D015091 D015166 D015018 D015166 D021057 D021057 (1.11) © 2023 Brunner GmbH...

  • Page 23: Deflector Plate

    DEFLECTOR PLATE D024014 EMBER PROTECTION STRIP D024013 © 2023 Brunner GmbH (1.11)

  • Page 24: Drawings And Technical Data

    Dimension sheets - Urfeuer® Panorama 50/44/88/44 … with mounting frame … with mounting frame R2, 90° Stand: 2023-07-20...
  • Page 25 … with mounting frame L4, 90° / R3, 90° … with mounting frame L4, 0° / R3, 0° We suggest for CAD planning Palette CAD. Permanent updated drawings: www.brunner.de Frames/ flue gas outlet connection/ combustion air supply connection/ front variants/ support bearing are marked in col-...
  • Page 26 Planning and installation - Urfeuer® Panorama 50/44/88/44 Data for functional demonstration Flue gas mass flow Flue gas temeperature °C Necessary supply pressure Total fuel load 2 - 5 Combustion air consumption Combustion air connection Ø Cross-section of gratings exhaust warm air Recirculation air Minimal distances of the fireplace to cladding, insulation layer...
  • Page 27 Zellhuber Ring 17-18 misprints reserved. Reprinting and reproduction, even in part, only with D-84307 Eggenfelden Tel.: +49 (0) 8721/771-0 / Fax: +49 (0) 8721/771-100 the express permission of the publisher. Email: info@brunner.de Art. No.: XXXXX © 2023 Brunner GmbH (1.11)
