Instruction
HD XL & XR license plate kit
(208917-18)
Tel. 0039 (0) 445-390437
Fax 0039 (0) 445-395539
TOOL REQUIREMENT
Installation time: 120 min.
Tools list : 1) Allen wrench metric set
2) Torx wrench set
3) Allen wrench Inch set
4) 10 mm. spanner wrench
5) 3/8 - 3/4 Inch spanner wrench
6) Wire stripping pliers
7) Medium threadlocker
8) Wire stripping pliers
9) Connector Crimp Tool
10) Warmer gun
11) Scissor lifter
Email info@freespirits.it
Site: www.freespirits.it
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Free Spirits HD XL
Summary of Contents for Free Spirits HD XL
- Page 1 Instruction HD XL & XR license plate kit (208917-18) TOOL REQUIREMENT Installation time: 120 min. Tools list : 1) Allen wrench metric set 2) Torx wrench set 3) Allen wrench Inch set 4) 10 mm. spanner wrench 5) 3/8 - 3/4 Inch spanner wrench...
- Page 2 Before starting the installation: Turn key to ON and remove the big GREEN fuse on battery side. Check schemes from page. 7 to decide the number of wire that will be used. Insert wires into the bracket and leaving 20 cm. outside on license plate side as photos.
- Page 3 Cut a piece 200mm. the shrink tube (10mm type). and insert in the cables on license plate side as photos. Insert shrink tube remaining on the opposite side. Secure two remaining screws as photos.
- Page 4 Screw and tighten with nut, the threated pin supplied as photos. Fasten license plate support as photo.
- Page 5 Shorten to 60 mm. the taillight wiring. Crimp female connectors as photo. Attention !. If you want weld connections with tinning, not use con- nectors. Cut small shrink tube in pieces of 50 mm. and insert as photos. Crimp male connectors as photo. Attention !.
- Page 6 Connect as photos and insulate. Insert wires on taillight support as photo. Apply thread lock and secure as photo.
-
Page 7: Tail Light
BLACK Cable = (GROUND) with : BLACK (OEM BROWN) Cable = (+) with : BROWN Free Spirits Srl. is not responsible for any injury or damage arising from not observance of the wiring diagram of the above. OEM PLUG SIX WAY XL 73106-96BK... - Page 8 ONLY FOR REAR TURN SIGNAL WITH TAIL LAMP & BRAKE LIGHT MODELS OEM PLUG TWO WAY OEM 73102-96 BK GROUND TAIL LIGHT 208917 PLUG OEM 73152-96 BK Remove seat, disconnect OEM tail light and remove license plate holder. Attention: for XR model will need to remove the tail. On XR model the plug is inside on tail light.
- Page 9 To support the bike, lift it under the frame. Remove shock absorber bolts LH. Insert and secure 1/2 unc x 2-1/2” allen bolt as photo. On XR model requires a additional spacer.
- Page 10 Insert and secure 1/2 unc x 3-1/2” allen bolt as photo. Remove shock absorber RH.
- Page 11 Insert 1/2 unc x 3” Allen bolt + bushing + spacer on top head and secure. Insert a supplied (Grower washer) between the bracket and swingarm. Insert 1/2 unc x 3-1/2” allen bolt as photo and place license plate.
- Page 12 Secure as photo. Choose cable path.
- Page 13 Apply three clamp as photo and secure on swingarm. ONLY FOR 2-WAY CONNECTOR (XL) Bring cable into the top of frame, near the OEM plug. Attention: in this mode of installation, the brown cable (red - brake light) is not used. Crimp female connectors as photos.
- Page 14 6-WAY CONNECTOR (XL) In case of use OEM turn signals, pull o contacts from original plug. Make ground cable as photos. Join groud cables with blue connector provided and connect the cable. Crimp female connectors as photos Insert all connectors in 6-way plug (See on page 7)
- Page 15 Connect to OEM wiring. Attention: To avoid contact with the plate holder, the OEM mudguard must be replaced or cut. 6-WAY CONNECTOR (XR) Make ground cable as photos. Join groud cables with blue connector provided and connect the cable.
- Page 16 Crimp male connectors as photos Insert all connectors in 6-way plug (See on page 7) Connect to OEM wiring.
- Page 20 -Free Spirits srl company is not responsible for damages during transport. Final revisions -Free Spirits srl company has got no connection with Harley-Davidson, Buell and Triumph brands. They are used only as references. -The BUYER declares to be completely informed that some PRODUCTS in this catalogue could not comply with the -Free Spirits srl company declines any responsibility with the wrong use of its accessories.
