Cyclone 4 Specifications - Void Cyclone 4 User Manual

3 About

3.4 Cyclone 4 specifications

Frequency response
Efficiency
1
Nominal impedance
Power handling
2
Maximum output 3
Driver configuration
Dispersion
Connectors
Weight
Enclosure
IP rating
4
Rigging
Finish
Height
Width
Depth
1 Measured in free space, 2 AES2 - 1984 compliant,
Figure 3.1: Horizontal directivity isobars
UG10567-1.0 - Cyclone 4 User Guide V1.0
3 Calculated, 4 BS EN 60529:1992 +A2:2013
90 Hz - 17.8 kHz ±3 dB
87 dB 1W/1m
16 Ω
30 W AES
101 dB cont, 107 dB peak
1 x 4" LF, 1 x 0.75" soft dome HF tweeter
80°H x 80°V
Phoenix connectors with link out
1.3 kg (2.7 lbs)
ABS
IP-55
Wall bracket included
Type 51 plate
Smooth cellulose
150 mm (5.9")
179 mm (7.1")
175 mm (6.9")
Figure 3.2: Vertical directivity isobars
Page 7
