- Page 1 • kvm-tec FLEXLINE FIRST SMARTflex Single in copper Dual in copper www.kvm-tec.com V10522 Misprints, errors and technical changes reserved...
- Page 2 First SMARTFLEX smart connection First check your delivery content SMARTflex..LOCAL/CPU Unit o 1 x SV 1 local (CPU) o 1 x wall power supply 12V 1A Are your upgrades for SMARTflex o EU-plug or INT Plug o 1 x DVI - DVI cable 1,8m/5,9ft unlocked o 1 x USB cable 1,8m/ 5,9 ft o 4 x rubber feet...
- Page 3 First SMARTFLEX smart connection First check your delivery content SMARTflex dual..LOCAL/CPU Unit o 1 x SV 2 local (CPU) o 1 x wall power supply 12V 1A Are your upgrades for SMARTFLEX o EU-plug or INT Plug o 2 x DVI - DVI cable 1,8m/5,9ft dual unlocked o 1 x USB cable 1,8m/ 5,9 ft o 4 x rubber feet...
- Page 4 First SMARTFLEX smart connection Check the LEDS to get more information..Error Cause Solution LED is not The devices get no power Is the power supply connected? (white box) lighting LED is lighting No connection between Check if the RJ45/network cable is connected well. (Clicking noise when in red Loc and Rem plugging in)
- Page 5 First SMARTFLEX smart connection Your Extender..No Video Video error No Power USB is not (stripes in the (No LED) working picture) Are the USB Check if all Check if all Check the Devices plugged cables are plug- cables are plug- powerplug in correctly? ged in correctly...
- Page 6 First SMARTFLEX smart connection Check the firmware version ..To view the firmware version Make sure the main menu is open. The currently installed firmware version of the remote and local units are displayed (e.g. ‘4267’) and check that you have the same firmware on both units. Ways to update the firmware version ..
- Page 7 First SMARTFLEX smart connection Checklist ..o identify your extender o first check your delivery content o are all needed upgrades unlocked o all cables are connected and all units are switched on o check the LED status o Video - check if the DDC is set correctly (in menu under point „O“ ) o USB - are all cables connected o in case of issues check the firmware version (download for the newest firmware kvm-tec.com/support ) if everything is working fine - perfect...
-
Page 8: Support - Request
First SMARTFLEX smart connection Support - request If the shoe pinches, then we are there for you! To support your case as quickly as possible Contact Information and to be able to process and track your data, provide with following information. - Page 9 First SMARTFLEX smart connection Contact Information RMA Number Company Contact person email copper phone number Firmware & Upgrade Product copper SVX2 copper Firmware Nr.: MVX1 Fiber copper MVX2 Fiber copper Memory Option fiber copper RS232 MX48 Fiber copper Switching Manager single dual MX2000 Fiber...
