- Page 1 ® Smith Meter Ultra™ Series C Liquid Ultrasonic Flowmeters & MPU™ Series C Ultrasonic Flowmeters SoM Replacement Manual Bulletin MN0A005 Issue/Rev. 0.0 (4/22)
- Page 2 All information and technical specifications in this document have been carefully checked and compiled by the author; however, we cannot completely exclude the possibility of errors. TechnipFMC is always grateful to be informed of any errors; contact us at TechnipFMC.com. Technical Support Field Service Response Center 24/7 Technical Support/Schedule a Technician: +1 844.798.3819...
-
Page 3: Table Of Contents
SoM Replacement Manual Contents 1 Introduction 1.1 Weights and Measures Requirements 1.2 Product Description 1.2.1 SoM Upgrade Kit Contents 1.3 Receipt of Equipment 1.4 Storage Instructions 1.5 Warnings and Precautions 1.5.1 Hazardous Locations 1.5.2 Electrostatic Discharge Precautions 2 Replacing the SoM 2.1 Required Tools 2.2 Backing Up Existing SoM Database 2.3 Removing the UMCB... -
Page 4: Introduction
UMCB enclosure that is mounted in the hazardous area. 1.1 Weights and Measures Requirements TechnipFMC's Ultra and MPU series of ultrasonic meters are used in a global market. Requirements regarding weights and measures may vary depending on the region of installation and type of installation. -
Page 5: Som Upgrade Kit Contents
SoM Replacement Manual such as Ultrasonic Software updates, to be faster and more reliable. Multiple SoM upgrade kits are available, depending on the version of your UMCB: P8000019905 SoM 2.0 upgrade kit for use in UMCB version 4.0 and UMCB-W version 3 and above P8000019988 SoM 2.0 upgrade kit for use in UMCB version 3.0 and UMCB-W version 2 and below... -
Page 6: Storage Instructions
Prior to installation, the unit should be stored in its original packaging and protected from adverse weather conditions and abuse. If the control board module is damaged or parts are missing, a written report must be submitted to: TechnipFMC c/o Inside Sales Department, Measurement Solutions PO Box 10428 Erie, PA 16514 1.4 Storage Instructions... -
Page 7: Electrostatic Discharge Precautions
SoM Replacement Manual safety requirements. It is recommended (and may be required in some jurisdictions) that the final installation be verified and inspected by the authority having jurisdiction before placing the equipment back into service. Electrical installations in hazardous areas have features specifically designed to make them suitable for use in such locations and it is the operator’s responsibility to maintain the integrity of those special features. -
Page 8: Replacing The Som
PH1 Phillips head screwdriver (included in the SoM Replacement Kit) Personal computer (PC) with a web browser (Google Chrome is recommended) Ethernet connection TechnipFMC Plotter Tool for Series C Ultrasonic Flow Meters version usmplot- 0.5.7-BETA or newer (contact your TechnipFMC service representative to get a copy of this software) Note: The external Ethernet connection should be available in an area where it is safe to use a laptop computer. -
Page 9: Backing Up Existing Som Database
SoM to the meter. 2. Using the TechnipFMC Log Plotter Tool, open the USC file and determine whether any parameters are missing. Missing parameters are highlighted in red; the status bar indicates the number of missing parameters. - Page 10 SoM Replacement Manual Figure 1: Grounded Anti-Static Wrist Strap 4. Using a 2.5 mm slotted screwdriver, loosen the two captive screws from the UMCB’s power supply connector CN1 and unplug the connector. This step can be done for the remaining field wiring connectors if you need to remove cable connections to allow removal of the UMCB board from the enclosure housing.
-
Page 11: Exchanging The Som
SoM Replacement Manual Figure 2: UMCB 7. While supporting the UMCB with one hand, remove the four mounting screws using the 6.5 mm slotted screwdriver. 8. Remove the UMCB from its enclosure (without disconnecting the transducer cables) and gently rotate it to set it down on the cover of the meter. 2.4 Exchanging the SoM Complete the following steps to exchange the SoM: When removing the SoM, do not touch the gold-plated contacts. - Page 12 SoM Replacement Manual Figure 3: Removing the Old SoM 4. Remove the SoM from the connector, ensuring that you only touch the edges of the module. 5. Remove the two spacers between the SoM and the UMCB. Failing to remove these spacers may result in damage to the circuit boards when installing the new SoM.
-
Page 13: Replacing Labels
SoM Replacement Manual 7. Gently press the SoM down until the two clips snap into place. Ensure that you do not force the SoM into place. 8. After the SoM is seated, re-position the spacers using tweezers. The spacers must be placed between the boards and aligned with the screw holes. -
Page 14: Re-Assembling The Umbc
SoM Replacement Manual 2.6 Re-Assembling the UMBC After replacing the SoM, complete the following steps to re-assemble the UMBC: 1. Verify that the power is turned off. 2. Gently rotate the PCB and place it into the enclosure. 3. While supporting the UMCB with one hand, attach the four mounting screws using a 6.5 mm slotted screwdriver. -
Page 15: Related Publications
SoM Replacement Manual 3 Related Publications The following literature can be obtained from TechnipFMC Measurement Solutions Literature Fulfillment at Measurement.Fulfillment@TechnipFMC.com or online at info.smithmeter.com/literature/online_index.html. When requesting literature, please reference the appropriate title and document number, as follows: Ultra Series C Liquid Ultrasonic Flowmeters Installation, Operation, and... - Page 16 (i) is the property of TechnipFMC plc (TechnipFMC) and its subsidiaries, (ii) is disclosed by TechnipFMC only in confidence, and (iii) except as TechnipFMC may otherwise permit in writing, is to be used, disclosed or copied only to the extent necessary for the evaluation and use thereof by the recipient.
