- Page 1 USER MANUAL 25” FULL HD 165Hz LED MONITOR eiQ-25FHD165TFSGH Thank you for choosing electriQ Please read the user manual before using this monitor and keep it safe for future reference Visit www.electriQ.co.uk to view our entire range of Intelligent Electricals...
-
Page 2: Table Of Contents
CONTENTS SAFETY WHAT’S INCLUDED MONITOR DIMENSIONS CONNECTIONS AVAILABLE ON THE MONITOR WALL MOUNTING GETTING STARTED INITIAL SET UP MENU OPTIONS OSD MENU INPUT COLOUR ADJUST MANUAL IMAGE ADJUST AUDIO SET UP MENU VIEW MODE SPECIFICATIONS TROUBLESHOOTING SUPPORT... -
Page 3: Safety
SAFETY INFORMATION • Read these instructions - All the safety and operating instructions should be read before this product is operated. • Keep these instructions - The safety and operating instructions should be retained for future reference. • Heed all warnings - All warnings on the appliance and in the operating instructions should be adhered to. - Page 4 Trying to service the unit yourself is dangerous and may invalidate the product's warranty. Only qualified personnel should service this apparatus. • Do not block ventilation slots on the back cover. The monitor can be placed in a cabinet but ensure at least 5cm (2") clearance all around. Do not tap or shake the screen, this may damage internal components.
-
Page 5: What's Included
WHAT’S INCLUDED USER MANUAL POWER SUPPLY POWER CABLE HDMI CABLE MONITOR DIMENSIONS... -
Page 6: Connections Available On The Monitor
CONNECTIONS AVAILABLE ON THE MONITOR DC 12V HDMI1 HDMI2 AUDIO OUT 1POWER DP1 (Display Port 1.2, 280Hz, Free Sync) HDMI 1 (HDMI 2.0, 240Hz, Free Sync) HDMI 2 (HDMI 2.0. 240hz, Free Sync) DP2 (Display Port 1.2, 280Hz, Free Sync) AUDIO OUT WALL MOUNTING •... -
Page 7: Initial Setup
INITIAL SETUP Connect the monitor to a power socket. Press the POWER button on the monitor or to turn it on (The indicator will be blue). Connect the relevant cable to the corresponding input on the monitor. The source will be automatically detected. -
Page 8: Osd Menu
OSD MENU INPUT SOURCE Signal Switch the signal input or select the source. DP1, DP2, HDMI1, HDMI2 COLOUR ADJUST Contrast/ Adjust the contrast/brightness of the display between 0 and Brightness 100. Change the Colour Temperature of the display to standard, Colour Warm, Cool or User Colour. -
Page 9: Manual Image Adjust
MANUAL IMAGE ADJUST Aspect Ratio Change the image aspect ratio to Wide Screen, 4:3,5:4,16:9,16:10. Sharpness Change the clarity from 0 to 100. Blue light filter Change the display blue light from 0 to 100. Advanced DCR Change the Dynamic Contrast Ratio Feature between 0, 75 and 100. -
Page 10: Setup Menu
SETUP MENU Change the OSD Menu display language between English, Chinese, Korean, Russian, Language Spanish, Japanese and French. Resolution Notice Turn the Resolution Notice feature On or Off. Information Resolution:1920x1080 Horizontal frequency: 137.36KHz Vertical frequency:120.0Hz Clock frequency: 285.5MHz. OSD Timeout Change the OSD Timeout from 0 to 100. -
Page 11: View Mode
VIEW MODE Standard Enter standard mode. Game The game mode is divided into FPS1, PFS2, RTS, Night, Vision, Gamer1, Gamer2, Gamer3. Movie Enter movie mode. Enter Web mode. Text Enter text mode. -
Page 12: Specifications
SPECIFICATIONS eiQ-25FHD165TFSGH Panel Type 25”(16:9)LED Backlit Monitor Panel Dimensions 622.28mm Diagonal Case Type Plastic 1920(H)x1080(V)@165Hz Best Resolution Active Display Area 543.744(H)x302.616(V) Pixel Pitch 0.283(H)x0.280(V) Contrast Ratio 1000:1 Typical Brightness 350 cd/m² Response Time 5ms (GTG) Viewing Angle 178°/178° CR≥10 Display Colours 16.7M... -
Page 13: Troubleshooting
Please contact the local council for details of your local household waste recycling centres electriQ UK SUPPORT www.electriQ.co.uk/support If the unit fails to operate call: 0330 390 3061 or complete the online form Office hours: 9AM - 5PM Monday to Friday www.electriQ.co.uk...
