Summary of Contents for ElectrIQ eiQ-27MF75I
- Page 1 USER MANUAL 27” SLIM LED MONITOR eiQ-27MF75I Thank you for choosing electriQ Please read the user manual before using this monitor and keep it safe for future reference Visit www.electriQ.co.uk to view our entire range of Intelligent Electricals.
-
Page 2: Table Of Contents
CONTENTS Safety Information What’s Included Monitor Dimensions Connections Available on the Monitor Wall Mounting Getting Started Monitor Controls Initial Setup Menu Options Luminance Settings Image Setup Settings Color Setup Settings OSD Setup Settings Reset Extra Specification electriQ UK Support... -
Page 3: Safety Information
SAFETY INFORMATION • Read these instructions - All the safety and operating instructions should be read before this product is operated. • Keep these instructions - The safety and operating instructions should be retained for future reference. • Heed all warnings - All warnings on the appliance and in the operating instructions should be adhered to. - Page 4 Trying to service the unit yourself is dangerous and may invalidate the product's warranty. Only qualified personnel should service this apparatus. • Do not block ventilation slots on the back cover. The monitor can be placed in a cabinet but ensure at least 5cm (2") clearance all around. Do not tap or shake the screen, this may damage internal components.
-
Page 5: What's Included
WHAT’S INCLUDED CONNECTIONS AVAILABLE ON THE MONITOR 1. HDMI port: Used to connect a compatible device. Supports HDMI 1.4 & 2.0; The VGA Input Source. 2. VGA: 3. Audio Output Port: Used for connecting headphones, or external speakers 4. DC input port: Connect the supplied power supply to power the monitor WALL MOUNTING The monitor is provided with mounting holes for a VESA approved wall mounting bracket (not supplied) The VESA mounting pattern is: 100x100mm and the size of the screws is 4 x M6 x 10 (not supplied) -
Page 6: Getting Started
GETTING STARTED MONITOR CONTROLS Enter into OSD menu and select an item for confirming settings Move down/ reduce value in the OSD menu; Display HDR Menu Move up / reduce value in the OSD menu; Display LOS (Crosshairs) Go back to previous menu, exit the on-screen display, and display source menu. POWER Turn the monitor on and off. -
Page 7: Image Setup Settings
BRIGHTNESS SETTINGS BRIGHTNESS Allows the adjustment of the image brightness, according to ambient light in the room. Value “0-100” CONTRAST Allows the adjustment of contrast between white and black areas of the image. Value “0-100” ECO MODE Allows selection of image settings between the following: STANDARD, TEXT, MOVIE, and GAME, FPS, RTS”. -
Page 8: Osd Setup Settings
COLOUR SETUP SETTINGS COLOR TEMP. Allows adjustment of the colour settings between the following options: “Warm-5800-SRGB-User-Cool- 7500”. Allows adjustment of the red element of color for the image GREEN Allows adjustment of the green element of color for the image BLUE Allows adjustment of the blue element of color for the image... -
Page 9: Reset
RESET AUTO CONFIG. Auto adjusts the image. AUTO COLOR Auto adjusts the colour of the image. RESET Returns the monitor to its factory default settings. EXTRA INPUT SELECT Allows user to choose the signal source of the display “HDMI, VGA”. MUTE Allows Mute to be turned ON and OFF VOLUME... -
Page 10: Specification
SPECIFICATION eiQ-27MF75I Panel Type 27'' Case Type Plastic Best Resolution 1920(H) x 1080(V) Active Display Area 597.8 (H) X 336.3 (V) Pixel Pitch 0.3114 (H) x 0.3114 (V) Contrast Ratio 1000:1 Typical Brightness 250 cd/m² Response Time 5ms(G2G) Viewing Angle U/D: 89°... -
Page 11: Electriq Uk Support
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. electriQ UK SUPPORT www.electriQ.co.uk/support If the unit fails to operate call: 0871 620 1057 or complete the online form Office hours: 9AM - 5PM Monday to Friday www.electriQ.co.uk...
