USER MANUAL
27" LED MONITOR
eiQ-27CVQHD165IFSGHLD
Thank you for choosing electriQ
Please read the user manual before using this monitor and keep it safe for future reference
Visit
www.electriQ.co.uk
to view our entire range of Intelligent Electricals

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eiQ-27CVQHD165IFSGHLD and is the answer not in the manual?

Questions and answers

Summary of Contents for ElectrIQ eiQ-27CVQHD165IFSGHLD

  • Page 1 USER MANUAL 27” LED MONITOR eiQ-27CVQHD165IFSGHLD Thank you for choosing electriQ Please read the user manual before using this monitor and keep it safe for future reference Visit www.electriQ.co.uk to view our entire range of Intelligent Electricals...
  • Page 2: Table Of Contents

    CONTENTS SAFETY WHATS INCLUDED STAND INSTALLATION WALL MOUNTING CONNECTIONS GETTING STARTED MONITOR CONTROLS SHORTCUT BUTTONS MENU OPTIONS OSD MENU LED EFFECTS PICTURE MODE COLLIMATION MODE INPUT BRIGHTNESS/CONTRAST COLOUR PICTURE QUALITY DISPLAY AUDIO MULTI-WINDOW OTHER TECHNICAL SPECIFICATION TROUBLESHOOTING SUPPORT...
  • Page 3: Safety

    SAFETY INFORMATION • Read these instructions - All the safety and operating instructions should be read before this product is operated. • Keep these instructions - The safety and operating instructions should be retained for future reference. • Heed all warnings - All warnings on the appliance and in the operating instructions should be adhered to.
  • Page 4 inside. Trying to service the unit yourself is dangerous and may invalidate the product's warranty. Only qualified personnel should service this apparatus. • Do not block ventilation slots on the back cover. The monitor can be placed in a cabinet but ensure at least 5cm (2") clearance all around. Do not tap or shake the screen, this may damage internal components.
  • Page 5: Whats Included

    27 INCH LED MONITOR eiQ-27CVQHD165IFSGHLD Thank you for choosing electriQ Please read the user manual before using this monitor and keep it safe for future reference Visit www.electriQ.co.uk to view our entire range of Intelligent Electricals USER MANUAL STAND (UPRIGHT SECTION) MOUNTING PLATE...
  • Page 6: Stand Installation

     that they are unpacked and assembled by 2 people. electriQ and its distributors and dealers are not liable or responsible for damage or injury caused by  improper installa�on, improper use or failure to observe these safety instruc�ons. In such cases any guarantee will expire.
  • Page 7 WALL MOUNT INSTALLATION 1. As shown in the figure above, use a screwdriver to remove the four screws locked in the middle of the whole machine (when disassembling the screws, the display screen cannot leave the polyol foam to prevent the screen from breaking) Disassemble the four screws that lock the whole machine 2.
  • Page 8: Wall Mounting

    Please follow the instruc�ons provided by the wall bracket manufacturer and ensure that all fixing screws supplied are used. electriQ and its distributors and dealers are not liable or responsible for damage or injury caused by  improper installa�on, improper use or failure to observe these safety instruc�ons. In such cases any guarantee will expire.
  • Page 9: Getting Started

    GETTING STARTED MONITOR CONTROLS Select signal source or Exit the menu Go Up within the Main Menu or increase the value of the selected item Go Down within the Main Menu or decrease the value of the selected item Enter the Main OSD Menu and Select submenu Turn the monitor On or Off...
  • Page 10: Menu Options

    INITIAL SET UP Connect the monitor to a power socket. 1. Press the POWER bu�on on the monitor or to turn it on (The indicator will be blue) 2. Connect the relevant cable to the corresponding input on the monitor.The source will be automa�cally detected.
  • Page 11: Collimation Mode

    COLLIMATION Mode Used to choose the Crosshairs that can be displayed in the centre of the screen. Collimation Mode Point Collimation1 Point Collimation2 Cross Collimation1 Cross Collimation2 INPUT SOURCE HDMI2 Resolution: 2560x1440@60Hz SDR Type-C HDMI1 HDMI2 HDMI3 InputSource: HDMI2 InputSource: Resolution: 2560x1440@60Hz Resolution:...
  • Page 12: Brightness/Contrast

    BRIGHTNESS/CONTRAST HDMI2 Resolution: 2560x1440@60Hz SDR Blacklevel Light Sensor InputSource: HDMI2 InputSource: Resolution: 2560x1440@60Hz Resolution: Brightness Adjust the brightness of the display between 0 and 100. Black level Adjust the black level of the display between 0 and 100. Contrast Adjust the contrast of the display between 0 and 100. Turn the Dynamic Contrast Ra�o Feature On or Off.
  • Page 13: Picture Quality

    PICTURE QUALITY SETTINGS HDMI2 Resolution: 2560x1440@60Hz SDR Dynamic Luminous Control MPRT InputSource: HDMI2 InputSource: Resolution: 2560x1440@60Hz Resolution: Sharpness Change the display Sharpness between 0 and 100. Response Time Turn the Response Over Drive feature between Off, High, Middle of low Noise Reduc�on Adjust the level of Noise Reduc�on between Low, Medium, High, or Off.
  • Page 14: Audio

    AUDIO HDMI2 Resolution: 2560x1440@60Hz SDR AutoSource InputSource: InputSource: HDMI2 Resolution: Resolution: 2560x1440@60Hz Mute Turn On and off to mute and unmute the audio output. Volume Adjust the output volume between 0 and 100. Chose which source the audio is output from Type-C, DP, HDMI1, Audio Source HDMI2, HDMI3, AutoSource MULTI-WINDOW...
  • Page 15: Osd

    HDMI2 Resolution: 2560x1440@60Hz SDR OSD Rotation Normal InputSource: InputSource: HDMI2 Resolution: Resolution: 2560x1440@60Hz Change the OSD Menu display language between English, Chinese, Korean, Russian, Language Spanish, Japanese and French. Change the horizontal posi�on of the OSD Menu between 0 and 100. OSD H Posi�on Change the ver�cal posi�on of the OSD Menu between 0 and 100.
  • Page 16: Technical Specification

    SPECIFICATION eiQ-27CVQHD165IFSGHLD Product Model Screen Size 27” Diagonal Panel Type VA Panel Aspect Ra�o 16:9 Power Supply DC 180W 19.5V 9.23A 80W Typ, 175W Max Power Consump�on 615.8 * 122.39 * 371.9 mm Dimensions 5.18 kg / 8.4 kg Net / Gross Weight Maximum Resolu�on...
  • Page 17: Troubleshooting

    Please contact the local council for details of your local household waste recycling centers. electriQ UK SUPPORT www.electriQ.co.uk/support Call: 0330 390 3061 Office hours: 9AM - 5PM Monday to Friday www.electriQ.co.uk...
