USER MANUAL
27" LED MONITOR
eiQ-27MQ95FSHDRU
Thank you for choosing electriQ
Please read the user manual before using this monitor and keep it safe for future reference
Visit
www.electriQ.co.uk
to view our entire range of Intelligent Electricals

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eiQ-27MQ95FSHDRU and is the answer not in the manual?

Questions and answers

Related Manuals for ElectrIQ eiQ-27MQ95FSHDRU

Summary of Contents for ElectrIQ eiQ-27MQ95FSHDRU

  • Page 1 USER MANUAL 27” LED MONITOR eiQ-27MQ95FSHDRU Thank you for choosing electriQ Please read the user manual before using this monitor and keep it safe for future reference Visit www.electriQ.co.uk to view our entire range of Intelligent Electricals...

  • Page 2: Table Of Contents

    CONTENTS Safety Information What’s Included Monitor Dimensions Connections Available on the Monitor Wall Mounting Getting Started Monitor Controls Initial Setup Menu Options Picture Settings Image Settings Colour Temperature Settings OSD Settings Reset Miscellaneous Settings Specification Troubleshooting electriQ UK Support...

  • Page 3: Safety Information

    SAFETY INFORMATION • Read these instructions - All the safety and operating instructions should be read before this product is operated. • Keep these instructions - The safety and operating instructions should be retained for future reference. • Heed all warnings - All warnings on the appliance and in the operating instructions should be adhered to.
  • Page 4 • Do not remove the safety covers. There are no user serviceable parts inside. Trying to service the unit yourself is dangerous and may invalidate the product's warranty. Only qualified personnel should service this apparatus. • Do not block ventilation slots on the back cover. The monitor can be placed in a cabinet but ensure at least 5cm (2") clearance all around.

  • Page 5: What's Included

    WHAT’S INCLUDED CONNECTIONS AVAILABLE ON THE MONITOR 1. DC input port: Connect the supplied power supply to power the monitor 2. USB: Charging only. 3. Audio Output Port: Used for connecting headphones, or external speakers 4. Display Port: Used to connect a compatible device. Supports Display Port 1.2 5.

  • Page 6: Getting Started

    GETTING STARTED MONITOR CONTROLS Enter into OSD menu and select an item for confirming settings Move down/ reduce value in the OSD menu; Display HDR Menu Move up / reduce value in the OSD menu; Display LOS (Crosshairs) Go back to previous menu, exit the on screen display, and display source menu. POWER Turn the monitor on and off.

  • Page 7: Picture Settings

    PICTURE SETTINGS BRIGHTNESS Allows the adjustment of the image brightness, according to ambient light in the room. Value “0-100” CONTRAST Allows the adjustment of contrast between white and black areas of the image. Value “0-100” Allows selection of image settings between the following: STANDARD, TEXT, MOVIE, and GAME, FPS, RTS”.

  • Page 8: Image Settings

    IMAGE SETTINGS H. POSITION Allows adjustment of the horizontal position of the display image. Use the "◀" and "▶" buttons to horizontally move the image. V. POSITION Allows adjustment of the vertical position of the display image. Use the "◀" and "▶" buttons to vertically move the image.

  • Page 9: Colour Temperature Settings

    COLOUR TEMPERATURE SETTINGS COLOR TEMP. Allows adjustment of the colour settings between the following options: “Warm-5800-SRGB-User- Cool-7500”. Allows adjustment of the red element of color for the image GREEN Allows adjustment of the green element of color for the image BLUE Allows adjustment of the blue element of color for the image...

  • Page 10: Osd Settings

    OSD SETTING LANGUAGE Allows selection of desired language: “ENGLISH, FRENCH, TURKISH, ITALIAN, SPANISH, PORTUGUESE, CHINESE, GERMAN, JAPANESE, POLISH, KOREAN AND DUTCH”. OSD H. POS Allows adjustment of the horizontal position of the OSD OSD V. POS Allows adjustment of the vertical position of the OSD OSD TIMER Allows adjustment of the duration of the OSD, value “0-60”...

  • Page 11: Reset

    RESET IMAGE AUTO ADJUST Auto adjusts the image. COLOR AUTO ADJUST Auto adjusts the colour of the image. RESET Returns the monitor to its factory default settings. SHARPNESS Allows adjustment of sharpness between "0-4". BLACK LEVEL Allows adjustment of black level between "0-100".

  • Page 12: Miscellaneous Settings

    MISCELLANEOUS SIGNAL SOURCE Allows user to choose the signal source of the display “HDMI, DP”. VOLUME Allows adjustment of the volume of the monitor from “0-100”. LOW BLUE LIGHT Allows adjustment of the low blue effect of the display, value: 0-100. FREE SYNC Allows FreeSync to be turned ON and OFF.

  • Page 13: Specification

    SPECIFICATION eiQ-27MQ95FSHDRU Panel Type 27'' (16:9) LED Backlit Monitor Case Type Plastic Best Resolution 2560(H) x 1440(V) Active Display Area 596.7 (H) X 335.6 (V) Pixel Pitch 0.2331 (H) x 0.2331 (V) 1000:1 Typical Contrast Ratio Brightness 350 cd/m² Response Time...

  • Page 14: Troubleshooting

    Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. ElectrIQ UK SUPPORT www.electriQ.co.uk/support If the unit fails to operate call: 0871 620 1057 or complete the online form Office hours: 9AM - 5PM Monday to Friday www.electriQ.co.uk...
