Summary of Contents for ElectrIQ eiQ-27MF75I-V2
- Page 1 USER MANUAL 27 INCH SLIM LED MONITOR eiQ-27MF75I-V2 Thank you for choosing electriQ Please read the user manual before using this monitor and keep it safe for future reference Visit www.electriQ.co.uk to view our entire range of Intelligent Electricals.
-
Page 3: Table Of Contents
CONTENTS SAFETY INFORMATION WHAT’S INCLUDED CONNECTIONS AVAILABLE ON THE MONITOR WALL MOUNTING GETTING STARTED MONITOR CONTROLS INITIAL SETUP MENU OPTIONS LUMINANCE SETTINGS IMAGE SETUP SETTINGS COLOR SETUP SETTINGS OSD SETUP SETTINGS RESET EXTRA SPECIFICATION electriQ UK SUPPORT... -
Page 4: Safety Information
SAFETY INFORMATION • Read these instructions - All the safety and operating instructions should be read before this product is operated. • Keep these instructions - The safety and operating instructions should be retained for future reference. • Heed all warnings - All warnings on the appliance and in the operating instructions should be adhered to. - Page 5 Trying to service the unit yourself is dangerous and may invalidate the product's warranty. Only qualified personnel should service this apparatus. • Do not block ventilation slots on the back cover. The monitor can be placed in a cabinet but ensure at least 5cm (2") clearance all around. Do not tap or shake the screen, this may damage internal components.
-
Page 6: What's Included
WHAT’S INCLUDED DIMENSIONS... -
Page 7: Connections Available On The Monitor
CONNECTIONS AVAILABLE ON THE MONITOR 1. HDMI port: Used to connect a compatible device. Supports HDMI 1.4 & 2.0; Used to connect a compatible VGA device 2. VGA: 3. Audio In: Used for connecting headphones, or external speakers. The audio input is used in conjunction with the VGA input if a HDMI source is in use, the sound will come from the HDMI connection. -
Page 8: Getting Started
GETTING STARTED MONITOR BUTTONS The monitor button is located on the rear left side of the monitor. The button can be used to move up, down, left or right within the menus. The center button is used as enter. When the monitor has no display, the monitor buttons can be used as below: Press once to turn the monitor on. -
Page 9: Initial Setup
INITIAL SETUP Connect the monitor to a power outlet. 1. Press the POWER button on the monitor to turn it on (The indicator will be blue) 2. Connect the relevant cable to the corresponding input on the monitor. The source will be automatically detected. -
Page 10: Luminance Settings
LUMINANCE SETTINGS BRIGHTNESS Allows the adjustment of the image brightness, according to ambient light in the room between “0- 100” CONTRAST Allows the adjustment of contrast between white and black areas of the image between “0-100” ECO MODE Allows selection of image settings between the following: STANDARD, MOVIE, INTERNET and GAME. -
Page 11: Color Setup Settings
COLOUR SETUP SETTINGS COLOR TEMP. Allows adjustment of the colour settings between the following options: Warm, Normal, User and Cool. Allows adjustment of the red element of color for the image GREEN Allows adjustment of the green element of color for the image BLUE Allows adjustment of the blue element of color for... -
Page 12: Reset
RESET AUTO CONFIG. Auto adjusts the image. AUTO COLOR Auto adjusts the colour of the image. RESET Returns the monitor to its factory default settings. EXTRA INPUT SELECT Allows user to choose the signal source for the display between “HDMI, VGA”. MUTE Allows Mute to be turned ON and OFF VOLUME... -
Page 13: Specification
SPECIFICATION eiQ-27MF75I-V2 Panel Type 27'' Case Type Plastic Best Resolution 1920(H) x 1080(V) Active Display Area 597.888 (H) X 336.312 (V) Pixel Pitch 0.3114 (H) x 0.3114 (V) Contrast Ratio 1000:1 Typical Brightness 250 cd/m² Response Time 5ms(G2G) Viewing Angle U/D: 89°... -
Page 14: Electriq Uk Support
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. electriQ UK SUPPORT www.electriQ.co.uk/support If the unit fails to operate call: 0330 390 3061or complete the online form Office hours: 9AM - 5PM Monday to Friday www.electriQ.co.uk...
