4.4 Cyclone glanded connector wiring
•
Remove both M6 bolts from the rear of the
connector plate
•
Undo the glanded connectors from the rear
of the connector plate and remove the rubber
plugs from the connectors.
•
Insert the cable through the glanded
connectors and tighten.
UG10588-2.0 - Cyclone 10 User Guide V2.0
Figure 4.2: Connector plate removal
Figure 4.3: Glanded connector removal
Figure 4.4: Cable connection
