Summary of Contents for Ovation SPACE MINI PROFILE 40Z

  • Page 1 SPACE MINI PROFILE 40Z USER MANUAL...
  • Page 2: Table Of Contents

    Table of contents Caution! ������������������������������������������������������������������������������������������������������������������������������������������������ 3 Introduction ������������������������������������������������������������������������������������������������������������������������������������������ 3 Safety instructions ������������������������������������������������������������������������������������������������������������������������������� 3 Overview ���������������������������������������������������������������������������������������������������������������������������������������������� 4 Installation ������������������������������������������������������������������������������������������������������������������������������������������� 4 Read ‘Safety information’ before installing the fixture................4 Instruction Installation of 3 Circuits Track System ...................4 3-circuit Track ..............................5 Track clamp mounting instruction ......................5 Mounting Instructions ..........................7 Remove Instructions ...........................8 Cautions for installation and remove ......................8...
  • Page 3: Caution

    - download the latest version of the user manual from the Internet Introduction Thank you for having chosen Space Mini Profile 40Z. You will see you acquired a powerful and versatile device. Unpack your item. Before you initial start-up, please make sure that there is no damage caused by transportation.
  • Page 4: Overview

    Dimmer knob Space Track DC output Display dealers. DMX out Overview DMX in Yoke Gobo holder slot Gobo holder (optional) Shutters Accessories clip Focus knob Color frame (optional) Zoom knob Installation Read ‘Safety information’ before installing the fixture. The fixture is designed for indoor use only and must be used in a dry location with adequate ventilation. Ensure that none of the fixture’s ventilation slots are blocked.
  • Page 5: 3-Circuit Track

    Space Track 3-circuit Track Track clamp mounting instruction hotion.com Ver 1.0...
  • Page 6 Space Track hotion.com Ver 1.0...
  • Page 7: Mounting Instructions

    Space Track Mounting Instructions Power Knob(OFF position) Track Plane Hand Grip Flange Step 1 Step 2 Make sure the positions are The adaptor flange is in exactly the same as the pictures the same direction with the show before instrallation. track plane.
  • Page 8: Remove Instructions

    Space Track Remove Instructions Hand Grip Position Rotate Hand Grip Position Step 1 Step 2 Make sure the track adaptor’s positions When power knob at the “OFF” position, are the same as the picture shows before rotate the hand grip at 90 degree. removing.
  • Page 9: Securing With A Safety Cable

    Operation The Space Mini Profile 40Z can operate in three different modes. In each mode you can run the fixture as a stand alone fixture or in a master/slave confiugration. This next section will detail the differences in the operating modes.
  • Page 10: Universal Dmx Control

    In the case of the Space Mini Profile 40Z, which is 1/2/3/4 channels fixture. If you set, for example, the address in the 2 channel mode to channel 2, the device will use the channel 2 to channel 3 for control.
  • Page 11: Control Menu Map

    Space Track Control Menu Map MENU SUB MENU OPERATION A001 001-512 DMX address setting Run if no signal STA1 Blackout STAT STA2 Auto STA3 Keep last step U001 000-225 Manual dimmer 1.2F/4.8F/12F/24F Frequency setting ON/OFF Off screen setting (60 seconds) DMX Protocol 1 Channel Mode Function...
  • Page 12: Technical Specifications

    Space Track Technical specifications Model SPACE MINI PROFILE 40Z Power supply: AC220-240V, 50/60Hz Light source: 40W COB LED Color temperature: 3200K or 5600K Color Rendition: CRI 92 Zoom range: 15°- 30° Signal connection: 3-pin XLR in & out DMX channels:...
