Assembly Instructions
CM-BR6911
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
assembling a specific product (with 1 being
(Included)
easy and 5 being difficult). For some
products, two persons are recommended.
Wrench
(Included)
DIFFICULT
EASY
Page 1 of 5
Rev.14-10-09
Advertisement
Related Manuals for Furniture of America CM-BR6911
Summary of Contents for Furniture of America CM-BR6911
- Page 1 Assembly Instructions CM-BR6911 ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List #1 x 1 pc #A x 4 pcs Gas Lift Cylinder Bolt M6x14mm #2 x 1 pc #B x 1 pc Lift Handle Allen Wrench...
- Page 4 Turn right (clockwise) to tighten #A x 4 pcs Carefully place the seat (#4) facing down over a protective surface. Align the lift handle (#2) with the pre-drilled holes on the bottom of the seat (#4). Insert 4 bolts (#A) through the lift handle (#2) and secure those bolts using the Allen wrench (#B) to lock them with...
- Page 5 Remove the protective plastic cap on the end of the gas lift cylinder (#1). Insert the gas lift cylinder (#1) into the 5-star base (#3). Place the seat (#4) over the top of the assembled gas lift cylinder (#1). Check to make sure all parts are secured, the chair is stable and the up/down lift is working properly.
