Furniture of America CM-BR6887 Assembly Instructions

Download this manual

Assembly Instructions

CM-BR6887

ASSEMBLY RATING

Tools Required for Assembly:

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

Allen Wrench

(Included)

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

DIFFICULT

EASY

Page 1 of 5

Rev.14-02-25

Need help?

Do you have a question about the CM-BR6887 and is the answer not in the manual?

Page 1 Assembly Instructions CM-BR6887 ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
Page 2 Page 2 of 5...
Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List #1 x 1 pc #A x 4 pcs Gas Lift Cylinder Bolt M6x14 #2 x 1 pc #B x 1 pc Foot Rest Assembly Allen Wrench...
Page 4 Insert the base ring (#5) onto the top of the base (#3). Then insert Step 1 the gas lift cylinder (#1) onto the base ring (#5). Remove the protective plastic sleeve on the end of the gas lift cylinder. Enlarged Align the 4 pre-drilled holes of the foot rest assembly (#2) with the 4 pre- Step 2 drilled holes on the bottom of the seat (#4).
Page 5 Place the assembled footrest/seat assembly over the Step 3 top of the assembled gas lift cylinder/base assembly. Check to make sure all parts are secured, the bar stool Step 4 is stable and the up and down lift is working properly. Page 5 of 5...
