SVAT CV503-8CH Instruction Manual

8 channel h.264 smart lcd-dvr security system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

INSTRUCTION MANUAL

www.SVAT.com
CV503-8CH-19M
8 Channel H.264 Smart LCD-DVR Security System
w/ Coaching iMenu and Night Vision Surveillance Cameras
SVAT ELECTRONICS
now you can see
COMPLETE SYSTEM
Model#:
CV503-8CH
www.SVAT.com
1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CV503-8CH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SVAT CV503-8CH

Summary of Contents for SVAT CV503-8CH

  • Page 1: Instruction Manual

    8 Channel H.264 Smart LCD-DVR Security System INSTRUCTION MANUAL www.SVAT.com CV503-8CH-19M SVAT ELECTRONICS now you can see w/ Coaching iMenu and Night Vision Surveillance Cameras COMPLETE SYSTEM Model#: CV503-8CH www.SVAT.com...
  • Page 2 Please contact us via one of the methods below: For more product information visit www.SVAT.com Note: This is manual version 1.0 for this product, you may find updated versions by visiting our website. CV503-8CH CV301-8CH NEED HELP?
  • Page 3 RISK OF ELECTRIC SHOCK, DO NOT OPEN MONITOR TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CV503-8CH SVAT USA 60 Industrial Parkway #Z64 Cheektowaga, NY...

  • Page 4: Table Of Contents

    Mobile Setup ... 31 Motion Detection ... 32 System Setup ... 34 Date and Time ... 34 Password Setup ... 37 Video Setup ... 38 Language ... 39 System Information ... 39 Maintenance... 40 CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 5 What’s Included ... 83 Features ... 83 Wiring Diagram for Cameras ... 84 Drilling Template ... 84 Camera Specifications ... 85 Camera Troubleshooting ... 86 REPLACEMENT PARTS ... 87 ADDITIONAL ACCESSORIES ... 87 CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 6: Introduction

    The coaching iMenu makes setting up and using your DVR very easy with helpful information bubbles that to assist you in using and setting up your system. The CV503-8CH comes equipped with H.264 compression which allows you to record and store more footage using less space, so you will never miss an important event.

  • Page 7: Features

    You have the option to record constantly, record based on a set schedule or record when only motion is detected. You can set each camera to record a specific schedule and choose which days of the week and hours of the day, you want to record. CV503-8CH-19M SVAT ELECTRONICS now you can see or directly from your iPhone®...

  • Page 8: Optional Accessories

    500GB hard drive, using lowest quality settings. IR illumination range up to 15ft under ideal conditions. Objects at or beyond this range may be partially or completely obscured, epending on the camera application. Although the cameras are water resistant, they are not waterproof. Cameras are not intended for use in direct exposure to water, rain or snow. USB flash drive, CD/DVD writer, and external hard drive not included. Video playback software is not Mac compatible. iPhone is a registered trademark of Apple Inc. BlackBerry is a registered trademark of Research in Motion Limited, Internet Explorer is a registered trademark of Microsoft Corporation and Sharp is a registered trademark of Sharp Corporation OPTIONAL ACCESSORIES • CVW62 (60 ft. Extension Cable) For more optional accessories, please see the back of the manual or visit: www.SVAT.com CV503-8CH-19M SVAT ELECTRONICS now you can see Compatible with...

  • Page 9: Buttons And Connections

    RCA video out jacks for spot monitors 7. Power Switch: Power on/off switch 8. External I/O Connect “PERIPHERAL CABLE” here CV503-8CH-19M SVAT ELECTRONICS now you can see LCD-DVR RIGHT SIDE 1. Removable HDD: The Hard Drive is located here for quick and easy access 2.
  • Page 10 BUTTONS AND CONNECTIONS REMOTE CONTROL MOUSE CV503-8CH-19M SVAT ELECTRONICS now you can see 1. Numerical Keypad: Buttons 1-8 will display the 2. All: 3. Menu: 4. Select/Enter: 5. Directional Keys: Allow you to navigate through 6. Audio/Search: 7. Mute: 8. Rewind: 9.

  • Page 11: Basic Setup

    5. Adjust cameras to the desired viewing angles. 6. For additional help on mounting the cameras, please see the drilling template, located at the end of the manual. CV503-8CH-19M SVAT ELECTRONICS now you can see Adjust camera to desired viewing angle...

  • Page 12: Connecting Peripheral Cable

    6. Connect the yellow male RCA plug (H) from the 60 ft cable to the BNC to RCA (K) connector and your “PERIPHERAL CABLE”(J). 7. Repeat the above steps for all of the included cameras. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 13: Connecting Additional Devices

    4. For further instruction on connecting your PTZ camera, please consult the PTZ camera’s instruction manual. CONNECTING A SPOT MONITOR The CV503-8CH supports up to two spot monitors in addition to your 19” LCD screen. To Connect a Spot Monitor: 1.

  • Page 14: Powering On Dvr

    After a few moments, your DVR system will immediately begin recording! GETTING STARTED The CV503-8CH is deisgned to be user friendly - you will notice the iMenu bubbles located toward the bottom of your screen which will describe your menu options. USING THE MOUSE The included USB mouse makes using the CV503-8CH quick and easy.

  • Page 15: Function Menu

    Unlock Menu Prompt Video Search Selecting this prompts the Video Search which allows you to search through recorded footage. For more information, please see Video Search on page 25. CV503-8CH-19M SVAT ELECTRONICS now you can see Function Menu DEFAULT PASSWORD...

  • Page 16: Ptz Camera

    8. To erase all preset cruise points click on “clean.” 9. To start the PTZ cruise, open the shortcut menu and select “start cruise”. To stop the PTZ cruise, open the shortcut menu and select “stop cruise”. CV503-8CH-19M SVAT ELECTRONICS now you can see PTZ setup menu...

  • Page 17: Pip Mode

    3. To select which camera you are viewing in the picture-in-picture, left click the smaller image to cycle through to the desired channel. 4. To exit “PIP Mode,” right click the mouse. PIP Mode 1x1 CV503-8CH-19M SVAT ELECTRONICS now you can see PIP Mode 1x2...

  • Page 18: Main Menu

    This option will confirm and save all of the adjustments made from this screen 3. EXIT: This button will exit the current screen without saving the adjustments Main Menu Note: All sub menus have some or all of the above options. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 19: Using The Keyboard

    1. Under the “NAME” column, navigate to and select the channel you would like to edit. 2. The keyboard will prompt, input desired title, then select enter. 3. Select “APPLY” to save changes. CV503-8CH-19M Camera Menu SVAT ELECTRONICS now you can see...
  • Page 20 1. Navigate to and select the “LIVE” drop down list next to the camera you would like to turn on/off. 2. Select “OFF” to prevent live camera display or “ON” to remain live. 3. Repeat for all desired cameras. 4. Select “APPLY” to save your changes. CV503-8CH-19M SVAT ELECTRONICS now you can see Color Setup...

  • Page 21: Privacy Zone

    MAIN MENU Time Display The CV503-8CH allows you to select if you would like the time and date displayed while in live view or while recording. To Enable/Disable the Time Display: 1. Select the drop down list next to the time display mode you would like to change.

  • Page 22: Record Setup

    1. Navigate to and select the quality level you would like to choose (BEST, GOOD or NORMAL). Selecting “BEST” will provide you with the best video quality but will also use up the most HDD space. 2. Select “APPLY” to save settings. CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 23 Note: Higher quality and resolution settings use up more space on your hard drive. Rec. Mode The CV503-8CH allows you to select if you want continuous recording or to record on a set schedule. To program your LCD-DVR to always record: 1.
  • Page 24 MAIN MENU To customize your record schedule : The CV503-8CH allows you to set different recording schedules and recording types for each individual channel. (Normal record, motion record or no record) 1. From the camera setup menu, ensure that “TIME SCHEDULE RECORD” is selected.

  • Page 25: Network Setup Menu

    To adjust the type of IP Mode you are using: 1. Select the drop down menu beside the word TYPE. 2. Highlight the IP Mode you would like to use and press select. 3. Select “apply” to save your changes. CV503-8CH-19M SVAT ELECTRONICS now you can see Network Menu...

  • Page 26: Web Port

    Note: The internal IP address is the most important number on the Network Setup Menu screen and the ports will be used to set up Port Forwarding which is necessary for viewing the DVR outside of the current network. CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 27 5. Highlight “USER NAME” and press select, the keyboard will appear to input your user name. 6. Navigate to and select “PASSWORD.” Keyboard will prompt to input a password. 7. Navigate to and select “APPLY” to save your settings. DDNS Setup CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 28: Video Search

    2. Navigate to and select the date to view footage from (2), this will prompt a keyboard to input date. 3. Navigate to and select the time to view footage from (5), this will prompt a keyboard to input time. 4. Navigate to and select “PLAYBACK.” CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 29: File List

    • Exit: Exits the file list 4. To only view one recording type, navigate to and select the “TYPE” drop down list. Choose between all recordings, only normal recordings or only motion recordings. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 30: Devices

    MAIN MENU Backup The CV503-8CH allows you to back up footage onto a USB device such as a USB memory stick, USB HDD or a USB CD/ DVD writer for playback on a computer. To Backup footage onto USB device: 1.

  • Page 31: Hdd

    HDD Menu Overwrite When the HDD is overwrite enabled, the CV503-8CH will continue to record over the oldest footage rather than stop recording when HDD is full. Disabling this option will prompt recording to stop when the hard drive is full.
  • Page 32 4. It may take a few minutes to format the HDD, you are unable to cancel during this process. 5. Once complete, you will be notified the HDD has been formatted successfully. 6. Select “OK,” exit all menus and the CV503-8CH will restart. USB Format USB format erases everything stored on the connected USB device.

  • Page 33: Alarm Setup

    MAIN MENU Alarm Setup This menu allows for the adjustment of a variety of alarm types and settings including an internal audible buzzer and email alerts. The CV503-8CH features many types of alarms and alerts. Types of Alarms: • BUZZER: An internal buzzer that sounds from the LCD-DVR •...

  • Page 34: Ptz Setup

    3. When all PTZ related information is entered, select “APPLY” to save changes. Mobile Setup The CV503-8CH is compatible with iPhone®, BlackBerry®, Windows Mobile® and Symbian® smart phones. Port forwarding on the router must be configured to enable mobile viewing.

  • Page 35: Motion Detection

    2. Select 1 to 4 from the drop down list to adjust the sensitivity. 1 is the lowest sensitivity and 4 is the highest. 3. Repeat for all desired cameras. 4. Select “APPLY” to save the changes. Motion Detection Menu CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 36 1. Navigate to and select “SETUP” for the channel you would like to adjust the motion detection area. This will prompt the MD Area grid. NOTE: By default, the grid is entirely red: the CV503-8CH is automatically designated to detect motion throughout the whole screen.

  • Page 37: System Setup

    This menu option allows you to adjust the date and time, change the format of the displayed date, adjust the time format, set time zones and adjust the LCD-DVR for daylight saving time. CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 38 1. Select the scroll bar next to “TIME FORMAT” and a list will appear. 2. Highlight and select the type of time format you would like. Choose between a 12 hour clock or a 24 hour clock. 3. Select “APPLY” to save your changes. Time Setup CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 39: Daylight Saving

    MAIN MENU Daylight Savings Time (DST) You can adjust the CV503-8CH to change automatically when daylight savings time occurs, or, at your scheduled preference. To set the LCD-DVR to adjust for daylight savings time automatically: 1. Select the drop down list “DST,” select “ON.”...

  • Page 40: Password Setup

    DVR. When you enable password protection, you will be prompted to input a password each time you wish to access the main menu. The default password is set to 123456. Note: For security purposes, the CV503-8CH will automatically log out of the admin account after 60 seconds of nonuse Device ID The Device ID allows you to change the identifying number your of your LCD-DVR.

  • Page 41: Video Setup

    Geographically, throughout the world, there are two common video formats: NTSC and PAL. National Television System Committee (NTSC) is the commonly used format for North America and Japan. Phase Altering Line (PAL) is the common format in European nations. The CV503-8CH is automatically configured to NTSC. To change the video system: 1.

  • Page 42: Language

    MAIN MENU Language The CV503-8CH allows you to set different languages. The included languages are: English, German, Italian, Russian, French, Spanish, Portuguese, Polish and Danish. To adjust the language: 1. Select the drop down list, “SYSTEM LANGUAGE.” 2. Select desired language.

  • Page 43: Maintenance

    To reboot the DVR: 1. Select “REBOOT.” 2. You will be prompted, “Are you sure to restart machine?” If yes, select “OK,” if not, “CANCEL.” 3. LCD-DVR will restart if reboot was chosen. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 44: Playback

    Sound will only play if you have an audio supported camera (not included) hooked up to your DVR. 8. Exit: Selecting this option will exit the playback footage and return you to the playback search or file list option. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 45: Computer Playback

    3. Once everything has been successfully installed, insert USB device into USB port on computer. Make sure USB device has backed up footage on it. 4. Open the playback software you installed. CV503-8CH-19M Software Installation SVAT ELECTRONICS now you can see...

  • Page 46: File Viewing

    Note: “Open Local Dir” works the same as Open Local Disk and Open Remote Device only works if the device is directly connected to computer, which is not supported on this device. CV503-8CH-19M File Viewing Instructions differ depending on what file(s) you would like to open and play: →...

  • Page 47: Software Functions

    No application Capture Picture: This option takes a screen shot. You will be prompted to name and save the file. OSD: On Screen Display (OSD): enables/disable OSD onscreen Mute: Mutes the sound CV503-8CH-19M SVAT ELECTRONICS now you can see Play Menu...

  • Page 48: Bottom Playback Functions

    22. Volume Control: If you have an audio supported camera (not included), clicking and dragging the square along the bar will turn the volume of the playback footage up and down. Clicking on the speaker icon will mute/turn on the sound CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 49 This DVR does not support multiple bars of audio (only one audio channel) so adjusting this function will not make a difference in your footage. Video channel Split Setting: This DVR does not support video channel splitting, so adjusting this function will not make a difference in your footage. CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 50 The help menu option allows you to view what the software you are using is called as well as see which version you are using. If more updated versions are available, they can be downloaded from www.SVAT.com CV503-8CH-19M SVAT ELECTRONICS...

  • Page 51: Network Guide

    3. Connect the other end of the network cable to an available port on the router. 4. Power on the DVR by reconnecting the power cable to the back of the DVR or by switching the power on. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 52: Finding Your Dvr's Ip Address

    Finding your DVR’s IP Address By default, the DVR IP mode is set to DHCP. This means the CV503-8CH will automatically retrieve an IP address from the router that it is connected to. Unless your network requires a static IP address, leave the IP mode set to DHCP.
  • Page 53 • Allow automatic prompting for file and code downloads: ENABLE 6. Click OK. 7. Click “apply”. 8. Close the options window. This method needs to be done on every computer you wish to view your DVR from. CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 54 If the computer is not connected to the same router and is at a remote location you will need to use the external IP address for the DVR to view the DVR from that computer. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 55: Log In To The Dvr

    1-2 minutes. If your ActiveX settings are set correctly you will see the following dialogue box. Click “RUN”. Once everything has installed and loaded, you will see the web player and the connected cameras. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 56: Viewing Dvr Outside Of Your Network

    To view what ports are being used with your DVR see the network setup menu on your DVR Note: Port forwarding is required if you want to view the DVR from a computer that is not connected to the same router. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 57: Option 1

    2. Once the site has loaded you will see a list with photos of different SVAT DVR models, select the CV503-8CH. 2. You will then see a list with photos of different types of routers. Select the router most similar to yours.

  • Page 58: Option 2

    NOTE: www.portforward.com is not affiliated with SVAT. PLEASE MAKE SURE TO FORWARD PORTS 80 AND 9000 FOR ONLINE VIEWING. IF YOU WOULD LIKE TO USE MOBILE VIEWING, BE SURE TO FORWARD PORT 1024 AS WELL. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 59: Testing Port Forwarding

    SVAT’s 24/7 support team. Write down your external IP address NOTE: www.whatsmyip.org and www.canyouseeme.org are not affiliated with SVAT in any way. CV503-8CH-19M SVAT ELECTRONICS now you can see Type in your the port you forwarded (Default port is 80)

  • Page 60: If You Cannot Connect

    Note: SVAT technical support cannot troubleshoot modems, since changing these settings can potentially render your modem inoperable. Bridging or any other modifications to the modem will need to be completed by the Internet service provider. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 61: Ddns Setup

    4. In the drop down menu next to “Server”, highlight and select “dyndns”. 5. Fill out the host name, user name and password that you use for the DynDNS account you will create in the following pages. Fill out DDNS setup with DYNDNS account information CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 62 DNYNDS.org in order to complete the account activation. • The next page has information about creating your host name DynDNS home page DynDNS Account Confirmation CV503-8CH-19M SVAT ELECTRONICS now you can see DynDNS Account Setup Note: The DynDNS sites are not owned...
  • Page 63 9. Follow on screen instructions to activate and view your free DDNS host name. 10. Be sure to input the proper account information on your DVR’s DDNS setup menu before viewing. Select the Services Button Select “Get Started” CV503-8CH-19M SVAT ELECTRONICS now you can see Select Dynamic DNS...

  • Page 64: Logging Into Software

    The login screen also has the option to adjust which connection you are viewing the software with (internet or LAN). Leave this option set to Internet. Default Password:123456 Once the password is inserted, select login and the DVR software and footage will appear. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 65: Online Software

    To restore all settings to the default settings select the “Default” button on the bottom of the screen • Apply: To save changes select “apply” at the bottom of the screen • Exit: To exit the menu, select “exit” at the bottom of the screen CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 66: Live Mode

    This controls the volume if an audio supported camera or microphone is connected (not included). Pointing and dragging the mouse across the volume bars turns the volume up and down. To mute the sound, click the speaker icon next to the volume bars CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 67: Ptz Options

    • Open or close individual windows: • You can also open/close all screens: • Start recording: • Stop recording: CV503-8CH-19M SVAT ELECTRONICS now you can see Click on the screen you would like to open/close. It should have a red box around it then right click your mouse and select open/...

  • Page 68: Playback

    1. Using the scroll lists located under the calendar, select the camera and type of footage you would like to view. 2. Select “search” and only the type of footage from the camera selected will be displayed in the list below. CV503-8CH-19M SVAT ELECTRONICS...

  • Page 69: Playing Back Footage

    When you prompt video to play, it may take a few minutes to load, then the footage will begin playing automatically. The bottom of the screen will have the playback options. The playback options (from left to right) are as follows: CV503-8CH-19M Pause/Play: Pressing this pauses playback. If the video is currently paused, pressing this button again will prompt the video to begin playing.

  • Page 70: Setup

    3. This will bring you to a separate menu. 4. Select the drop down list beside the word “CHANNEL” and highlight the camera you would like to set a schedule for. CV503-8CH-19M SVAT ELECTRONICS now you can see Record Options...
  • Page 71 5. Press the “copy” button and the copied schedule will appear in the selected days. 6. Once you have completed all desired schedules, select “apply” to save settings and “exit” to exit back to record setup menu. Schedule adjust CV503-8CH-19M Records when motion or alarm is detected Constantly records SVAT ELECTRONICS...
  • Page 72 4. Once motion detection areas have been determined, exit the screen by right clicking or pressing “esc” and select “apply”, to save settings. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 73: Network Setup Menu

    The options and selections in this network setup menu are the same as the network menu on your DVR. For more information on your network menu and what it consists of please see “Network Setup Menu” on page 22 of this manual. CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 74 2. Find the area you want the files to be saved to and double click the area. 3. Select OK. 4. The file you want the footage/pictures saved to will appear in the box. 5. Select “apply” to save settings. CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 75 5. To adjust the week and month, use the drop down list, highlight the week and/or month you want and press select. 6. Once everything has been adjusted to your liking, select “apply” to save your settings. CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 76 Clicking on this tab logs you out of the online software and DVR viewing. When this tab is clicked the software will shut down, the screen will refresh and go to the initial user login. CV503-8CH-19M SVAT ELECTRONICS now you can see...

  • Page 77: Mobile Viewing

    DVR User ID: Input the user ID that you have set under the mobile settings on your DVR Password: Input the password that you have set under the mobile settings on your DVR CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 78 1. The installed software will be located in the “Downloads” directory from the menu. menu, select the software icon 2. Once the program has started, select the settings icon information. CV503-8CH-19M 4 5 6 7 8 to start the application. , from the settings screen, input the following...
  • Page 79 This will be the mobile port you forwarded and specified on the DVR to view mobile settings we recommend using port 1024 Channel: This will be the camera you would like displayed when you view your DVR CV503-8CH-19M SVAT ELECTRONICS now you can see to begin playing the footage.
  • Page 80 9. For a full screen view, select the footage being displayed. Note: Directions may vary depending on the type of phone that is being used. Refer to your phone’s instruction manual on how to access files from your mobile device. CV503-8CH-19M SVAT ELECTRONICS now you can see...
  • Page 81 The browser keeps freezing/ won’t let me play the footage CV503-8CH-19M • Check if you have sequence turned on under the camera menu options • You must initiate the sequencing to get it to start by right clicking and selecting start auto sequence from the sub menu.

  • Page 82: Dvr Troubleshooting

    DHCP enabled, but my DVR will not acquire an IP address CV503-8CH-19M • The DVR will run as long as it is plugged in and power switch is set to on. Flip power switch to off or remove plug to turn off power to LCD- DVR •...
  • Page 83 • There could be video loss, HDD loss, motion detection or no HDD space on your DVR. The CV503-8CH is set to alarm when those actions take place. This is to alert you if anything is tampering with the camera to DVR connections the alarm will go off.

  • Page 84: Dvr Specifications

    Web Interface ...Licensed software AP, IE browser Remote Alarm Notification ...Email Alerts Network Protocol ...TCP/IP, PPPoE, DHCP and DDNS, 3G IR Receiver ...Yes CV503-8CH-19M SVAT ELECTRONICS now you can see Composite Video Signal 1 Vp-p 75Ω BNC;Call Monitor Output: No...
  • Page 85 Power Consumption ... <30 W Operating Temperature ... 100C ~ 400C (500F ~ 1040F) Dimensions (mm) ... 315 (W) × 52 (H) × 224 (L) System Recovery ... System auto recovery after power failure CV503-8CH-19M SVAT ELECTRONICS now you can see (0-10 sec.)

  • Page 86: Camera Manual

    Night Vision CCD Color Cameras • BNC to RCA Connector • 1 Power Adapter for Cameras • Mounting Hardware FEATURES CV503-8CH-19M SVAT ELECTRONICS now you can see 4 PIN DIN to RCA (male) Video/Power Wire • Instruction Manual • 1 Year Warranty •...

  • Page 87: Wiring Diagram For Cameras

    To wall mount the camera, drill three holes using a 3/16" drill bit and the template below. Insert the supplied wall anchors into holes and secure camera to wall with supplied screws. DRILL HOLES IN THESE POSITIONS CV503-8CH-19M SVAT ELECTRONICS now you can see DRILL HOLES IN...

  • Page 88: Camera Specifications

    Operating Humidity ... 98% Camera Power Input ... DC 12V 300mA Power Adapter Input ... 120V 60Hz LED Power Indicator ... No Dimensions ... 4.7”(L) x 2.5”(W) x 2.5”(H) Weight ... 0.7 lbs CV503-8CH-19M SVAT ELECTRONICS now you can see Camera...

  • Page 89: Camera Troubleshooting

    Night Vision is not working • Cup your hands around the front of the camera and look at the LEDs. They CV503-8CH-19M Toll free telephone: 1.866.946.7828 channel 3. Common terms for this channel is INPUT, AV CHANNEL, LINE 1, LINE 2 and AUX.

  • Page 90: Replacement Parts

    PRODUCT MODEL# CVW62 VU301-C VU100-ST SGN100 For more information on additional accessories, parts and much more, please visit: www.svat.com DESCRIPTION 4 PIN DIN Cable BNC to RCA Connector Four-to-One Power Supply Your product software and manual are available for download at: http://www.svat.com/downloads.php DESCRIPTION Extend the range of your cameras with a 60ft extension. Upgrade your camera to a higher resolution and advanced UV filters for accurate and vibrant colours. Alert all potential criminals of your security and help deter crime with a window sticker. Alert all potential criminals of your security and help deter crime with this durable aluminum sign. www.svat.com SVAT ELECTRONICS now you can see...
  • Page 91 ► Specification Sheets ► Software Updates ► Firmware Upgrades www.SVAT.com www.SVAT.com SVAT ELECTRONICS now you can see ► Specification Sheets ► Software Updates ► Firmware Upgrades Model#: Model# CV503-8CH CV503-8CH-19M...
