P R O 4 8 I N S T A L L A T I O N S P E C I F I C AT I O N S
I N S TA L L AT I O N S P E C I F I C AT I O N S
The PRO 48 can be used free-standing or
installed as a standard or flush built-in applica-
tion. For standard built-in installations, the face
frame of the unit will extend 2" (51) beyond
cabinetry. In flush built-in installations, the
front of the face frame will be flush with
surrounding cabinetry.
For built-in installations, make sure that the
finished rough opening where the unit is to be
installed is properly prepared. Refer to the
Installation Specifications illustration to be
sure that the rough opening dimensions, elec-
trical service and plumbing are correct.
I N S TA L L A T I O N S P E C I F I C AT I O N S
Standard or flush installation for Models 648PRO and 648PROG.
ROUGH
OPENING DEPTH
24"
(610)
STANDARD
26"
(660)
FLUSH
47
MIN HEIGHT
ROUGH
REQUIRED
TO FINISHED OPENING HEIGHT
FLOORING TO FINISHED
(LEVELERS IN) FLOORING
1 3
83 / " 83 / "
2 (2121) 4 (2127)
STANDARD STANDARD
3 1
83 / " 84 / "
4 (2127) 8 (2137)
FLUSH FLUSH
36"
MIN (914)
1
/ "
4 COPPER
WATER LINE
SHUT-OFF
VALVE
TOP VIEW
7"
E
(178)
6"
(152)
LOCATE ELECTRICAL
WITHIN SHADED AREA
ROUGH
OPENING WIDTH
1
/ "
2 (1206) STANDARD
48"
(1219) FLUSH
LOCATE WATER SUPPLY
WITHIN SHADED AREA
6"
(152)
3"
W
(76)
3
5 / "
16
(132)
FRONT VIEW
IMPORTANT NOTE: To operate properly,
doors must be able to open a minimum of 90˚.
Use a filler strip in built-in corner installations
to assure a 90˚ door opening. Allow enough
clearance in front of the unit for full door
swing.
IMPORTANT NOTE: Make sure that the floor
under the unit is level with the surrounding
finished floor and will be able to support the
weight of the unit—885 lbs (401 kg) or 900 lbs
(408 kg).
M O D E L S 6 4 8 P R O A N D 6 4 8 P R O G
Rough Opening Width
(standard installation)
Rough Opening Width
(flush installation)
Rough Opening Height
(standard installation)
Rough Opening Height
(flush installation)
Minimum Height Required
(to finished flooring)
Rough Opening Depth
(standard installation)
Rough Opening Depth
(flush installation)
Dimensions are for finished rough openings.
1
75 / "
2
(1918)
1
47 / " (1206)
2
48" (1219)
3
83 / " (2127)
4
1
84 / " (2137)
8
1
83 / " (2121)
2
24" (610)
26" (660)
5
