The system give the opportunity to record specific events through automatic or manual

markers.

The automatic markers are triggered and recorded once the condition observed. They
may thus appeared a posteriori in case of data synchronization.
The manual markers may be directly added:
- by pushing the button 1 of the ePerf Connect device (long press)
- through the ePerf Mobile application by double-clicking on the graph of the capsule
concerned.
- by pressing the marker button
The markers are then diplayed ont the graphic through a vertical line and in the raw data
file after data export.The buttons ''Next'' and ''Previous'' on the graph allow to navigate
from one marker to another.
Marker button
User marker
Power ON
Power OFF
Critical battery
Pause activated (1/2/3)
Pause deactivated (1/2/3)
Date and time update
Capsule activated (1/2/3)
Capsule deactivated (1/2/3)
Internal alert XX
Slot memory 1/2/3 full
Measurement period

SECONDARY FUNCTIONS

ID CAPSULES VISUALIZATION
It is possible to access to the unique ID of the capsule going on ePerf Mobile
application and then access to the ePerf Connect parameters (''Nut'' logo at the
bottom of the android device).
The capsule ID are in an hexadecimal format: XX.XX.XX.XX in wich X may be
from 0 to 9 and from A to F.
Once the capsule is deactivaed, it disappears of this list and is transfered to the
Archives (Cf. page 22).
Auto
no
yes
yes
yes The ePerf Connect is turned off due to a too low battery level
yes
yes A capsule (1/2/3) previsously in Pause mode is ''on'' again
yes Date and time updated through the ePerf Mobile App
yes
yes
The ePerf Connect device triggered a technical alert that re-
yes
yes
yes
P063GUI001 - User guide eCelsius Performance Connect.1 - EN
MARKERS
Signification
Marker added through a long press on button 1
or through the ePerf Mobille App
ePerf Connect turned on
ePerf Connect volontary turned off
(through the ePerf Mobile App)
A capsule (1/2/3) is put in Pause mode
A capsule (1/2/3) is associated
A capsule (1/2/3) is deactivated
quires an intervention of the support service team
Memory of the ePerf Connect device full
New measurement period applied
21
