The informations available on the screen of the device are the following:
Pause mode activated with at least 1 capsule (the symbol disappears when the Pause mode is
deactivated)
Loss of communication of more than 5 minutes on at least 1 capsule (the symbol disappears
when the communication est restored for all the capsules)
Time view (24h or 12h format)
If the symbol --:-- appears instead of the time, it is necessary to reconnect the device to the
ePerf Mobile Application to set again the date and time.
The application should send to the device the time in the 12h or 24h format depending on the
parameters set on the ePerf Mobile Application.
Battery level: the gauge provides the indication of the ePerf Connect battery level.
An exclamation mark appears if the level is low and the corresponding alert is triggered.
An outlet symbol appears if the system is on charge.
BLE connexion activated: the ePerf Connect device is connected to an Android device in real time
The symbol disapears if the device is not connected anymore in real time to a BLE device.
Errors messages may appear before the time is displayed. It is recommanded to contact the after sales
service if an internal error code is displayed (Int. err.).
Specific messages related to ongoing actions may also appear:
* Associat. BLE + code: cf BLE peering process (long press on button 2)
* BLE associated: Message displayed if BLE peering has worked
* Echec BLE: Message displayed in case of BLE peering failed
* Add marker: in case of manual marker add-on (long press bouton 1)
* Good bye! : in cas of device turned off (through ePerf Mobile App)
* Update: if you update the ePerf Connect device software (through ePerf Mobile App)
