Distributing Pro Station
Digital 2
Function SysLink
I0 13
I1 14
I2 15
I3 16
I4 17
I5 18
I6 19
I7 20
Q0 1
Q1 2
Q2 3
Q3 4
Q4 5
Q5 6
Q6 7
Q7 8
24 V A 9+10
24 V B 21+22
GND A 11
GND A 12
GND B 23+24
52
Color Designation
Grey-pink Gate valve magazine 1 retracted
Red-blue Gate valve magazine 1 advanced
White-green Magazine 1 empty
Brown-green Activate magazine 1
White-yellow Gate valve magazine 2 retracted
brown-yellow Gate valve magazine 2 advanced
White-gray Magazine 2 empty
Grey-brown Activate magazine 2
White Advance gate valve magazine 1
Brown Indicator light magazine 1 activated
Green
Yellow
Grey Advance gate valve magazine 2
Pink Indicator light magazine 2 activated
Blue
Red
black 24 V power supply for outputs
White-pink 24 V power supply for inputs
brown-pink 0 V power supply for outputs
purple 0 V power supply for outputs
White-blue 0 V power supply for inputs
