- Page 1 Distribution station Assembly Instructions 10/02...
- Page 2 The copying, distribution and utilisation of this document, as well as the communication of its contents to others without the express authorisation of Festo Didactic is prohibited. Offenders will be held liable for the payment of damages. All rights reserved, in particular the right to carry out patent, utility model or ornamental design registration ©...
-
Page 3: Table Of Contents
Step 2 _________________________________________________________ 11 Step 3 _________________________________________________________ 12 Step 4 _________________________________________________________ 13 Step 5 _________________________________________________________ 14 Step 6 _________________________________________________________ 15 Step 7 _________________________________________________________ 17 Step 8 _________________________________________________________ 18 Step 9 _________________________________________________________ 19 © Festo Didactic GmbH & Co. „ Distribution station... - Page 4 Contents © Festo Didactic GmbH & Co. „ Distribution station...
-
Page 5: Notes On Safety
Cylinders may advance or retract as the compressed air is switched on. Mechanical Attach all components securely on the mounting plate. No manual intervention is to take place unless the machine is at rest. © Festo Didactic GmbH & Co. „ Distribution station... -
Page 6: Short Description
Magazines with feed limiting, Vibratory bowl feeder, Inclined conveyors and Hoppers with sorting devices. Workpieces handled by feed devices are Electroplated parts, Shaped parts made of plastic, Punched parts and Turned components. © Festo Didactic GmbH & Co. „ Distribution station... - Page 7 The Distribution station consists of the following: Stack magazine module Changer module Profile plate Trolley Control console PLC board © Festo Didactic GmbH & Co. „ Distribution station...
-
Page 8: Views And Tools
3. Views and tools Views Distribution station, plan view Distribution station, r.h. side view © Festo Didactic GmbH & Co. „ Distribution station... -
Page 9: Tools
Distribution station, front view Tube spanner, 9 x 10 mm Required tools Open-ended spanners 6 x 7, 12 x 13, 22 x 24 mm Slot-head screwdriver, 3.5 mm Allen key, 5 mm © Festo Didactic GmbH & Co. „ Distribution station... -
Page 10: Assembling The Station
4. Assembling the station Step 1 14. Nut Profile plate © Festo Didactic GmbH & Co. „ Distribution station... -
Page 11: Step 2
2.6 (2x) 2.7 (2x) 2.8 (2x) 2.4 (4x) Cable duct Socket-head screw M5 x 10 Washer B5.3 T-head nut M5-32 Mounting rail Socket-head screw M5 x 10 Washer B5.3 T-head nut M5-32 © Festo Didactic GmbH & Co. „ Distribution station... -
Page 12: Step 3
Assembling the station Step 3 Mounting the electrical system © Festo Didactic GmbH & Co. „ Distribution station... -
Page 13: Step 4
Assembling the station Step 4 6 (6x) I/O terminal Vacuum switch CP valve terminal Cable clip (6x) Changer module Service unit © Festo Didactic GmbH & Co. „ Distribution station... -
Page 14: Step 5
Assembling the station Step 5 Position of Changer module and cable clips © Festo Didactic GmbH & Co. „ Distribution station... -
Page 15: Step 6
Nut M 4 (2x) Socket connector cable T-head nut M 4-32 (2x) Socket head screw M 4 x 10 (2x) Adapter(2x) 9.10 Nut M 5 (4x) 9.11 Fibre optic cable “Light barrier” © Festo Didactic GmbH & Co. „ Distribution station... - Page 16 10.4 Washer B 4.3 (4x) 10.5 Socket head screw M 4 x 16 (2x) 10.6 Socket head screw M 4 x 10 (2x) 10.7 T-head nut M 4-32 (2x) 10.8 Nut M 4 (2x) © Festo Didactic GmbH & Co. „ Distribution station...
-
Page 17: Step 7
Assembling the station Step 7 11 (2x) Fibre optic device StationLink receiver Connector (2x) Stack magazine module Cable clip © Festo Didactic GmbH & Co. „ Distribution station... -
Page 18: Step 8
Assembling the station Step 8 Complete assembling of Stack magazine module and cable clips Fibre optic cable “Light barrier” © Festo Didactic GmbH & Co. „ Distribution station... -
Page 19: Step 9
Assembling the station Step 9 Station completely assembled © Festo Didactic GmbH & Co. „ Distribution station... - Page 20 Assembling the station © Festo Didactic GmbH & Co. „ Distribution station...
