49991
Installation & Servicing
Harmony 5 and Stanford 50 Gas
Conventional Flue Stove
EF EL
Part No.
Euroheat Distributors
(H.B.S.) Ltd.,
Unit 2, Court Farm
Serial Number
Business Park,
Bishops Frome,
Worcestershire,
WR6 5AY.
1
Instructions Part number IN1016 Ed G
© EUROHEAT DISTRIBUTORS (H.B.S) LTD.Aug 2006
Advertisement
Table of Contents
Related Manuals for Euroheat 49991
Summary of Contents for Euroheat 49991
- Page 1 Harmony 5 and Stanford 50 Gas Conventional Flue Stove EF EL Part No. Euroheat Distributors (H.B.S.) Ltd., Unit 2, Court Farm Serial Number Business Park, Bishops Frome, Worcestershire, WR6 5AY. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD.Aug 2006...
-
Page 2: Table Of Contents
2: On the front page of the operating instructions 3: On the rear heat shield of the stove 4: On the registration form 5: On the registration certificate returned to the user after successful registration. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD. Aug 2006... -
Page 3: Technical Data With Eurosit Gas Valve 630
The test data from which it has been calculated has been certified by BELTEST. The efficiency value may be used in the Governments Standard Assessment Procedure (SAP) for energy rating of dwellings. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD.Aug 2006... -
Page 4: Technical Data With Mertik Maxitrol Gv34 Gas Valve
The test data from which it has been calculated has been certified by BELTEST. The efficiency value may be used in the Governments Standard Assessment Procedure (SAP) for energy rating of dwellings. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD. Aug 2006... -
Page 5: General Installation And Servicing Instructions
The chimney should be swept prior to installation of the stove. However, if the flue is clean and unobstructed throughout its entire length, it need not be swept. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD.Aug 2006... -
Page 6: Installation Of The Gas Supply, Bs 6891
Care should be taken to ensure that pipe work brought through metal structures has been secured to prevent chaffing, but allow for thermal expansion. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD. Aug 2006... -
Page 7: Appliance Location
45 degree bend directly from the top of the stove, this is acceptable as long as it does not compromise the drawing power of the flue and the stove passes the necessary flue spillage test. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD.Aug 2006... -
Page 8: Hearth And Fireplace Requirements
The stove can be placed on a wooden floor if it can support the weight as long as the hearth plinth 6" 150mm** 4" 100mm is utilized. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD. Aug 2006... -
Page 9: Changing Flue Outlet Direction
Turn off the gas, remove the pressure gauge and refit the test point screw, turn the gas supply on and check that test nipple is gas sound. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD.Aug 2006... -
Page 10: Fitting The Coal Effect Kit And Fuel Guard
fl ames. Small Coals 8 = Horse Shoe Coal 1,2,3,6,7 = Large coals 4, 5 & 9 Small Coals Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD. Aug 2006... -
Page 11: Gas Control Valve
In the unlikely event of the flame being extinguished whilst the gas control is in the “on” position, immediately turn “off” and wait 2 minutes before attempting to relight. For full operating instructions see operation manual. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD.Aug 2006... -
Page 12: Thermostatic Eurosit Gas Valve 630 With Manual Override
SHOULD NOT BE Remove screw and ALTERED gently remove cover Low operation bypass. SHOULD NOT BE ALTERED Supply pressure Operating test nipple pressure test nipple Front Operating pressure adjustment Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD. Aug 2006... - Page 13 Once the pilot has been established, let out the control knob and turn it anticlockwise to the “ON” position. Manual Control Turn the larger left hand control anti clockwise to increase, clockwise to decrease the desired heat output. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD.Aug 2006...
-
Page 14: Mertik Maxitrol Gv34 Gas Valve
(The flat blade screw can be accessed through a hole in the bottom plate of the stove under the valve, anti clockwise to increase, clockwise to decrease.) Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD. Aug 2006... -
Page 15: Gas Pressure Test Nipple Locations
Receiver location Place the receiver on the hearth under the gas valve, or hidden on the hearth behind the stove. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD.Aug 2006... -
Page 16: Commissioning
Carry out a gas supply pressure test with the appliance operating. Attach a manometer to the supply pressure test nipple. If the pressure is below requirements inspect gas pipe installation for possible problems. Thermocouple TTB Flue Spillage Sensor. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD. Aug 2006... -
Page 17: Information For Users Which Must Be Advised By The Installer Verbally Or In Writing
Do not use the appliance if the glass is craked or broken. Do not use the appliance if any of the coal effect components are broken. The appliance must be guarded to protect children, the aged or infirm. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD.Aug 2006... -
Page 18: Servicing Instructions
Use only genuine replacement parts, non standard components could invalidate the warranty and may be dangerous. Pilot Assembly Correct position of thermocouple in pilot flame Thermocouple Ignition Electrode Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD. Aug 2006... - Page 19 Dismantling OPRN LIFT SLIGHTLY LOCATE Pilot jet removal and replacement 4mm Hexagon key. PUSH Reassembly Note locating lug Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD.Aug 2006...
-
Page 20: Removing Thermocouple And Pilot Assembly
Remove thermocouple from rear of gas valve. Removing Main Burner Nozzle Remove right hand side panel as above. When fitting main gas burner jet ensure sealing washers are fitted. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD. Aug 2006... -
Page 21: Removing Gas Burner
Side panel coating can be easily damaged. 3: Loosen and remove gas supply pipe. Gas supply pipe 4: Loosen burner mounting screws and remove gas burner. Mounting screws Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD.Aug 2006... -
Page 22: Changing Gas Operating Type
Primary Air Collar The air collar should be adjusted to give a 3 mm wide opening. L.P.G The air collar should be adjusted to give its maximum setting. Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD. Aug 2006... - Page 23 For the latest editions of all Euroheat documentation visit our web site www.euroheat.co.uk. We would request that you inform Euroheat of information which you feel is not provided in this document which would assist other users in the future.
-
Page 24: Service Record
Number/Street Name ......................... Locality Name ......................... Post Town ..............When this form been County ..............completed contact Euroheat for Post Code ..............additional Service records Telephone Number ............Instructions Part number IN1016 Ed G © EUROHEAT DISTRIBUTORS (H.B.S) LTD. Aug 2006...
