Page 1: Servicing Instructions
Installation & Servicing Instructions Harmony 15 Stanford 15 Balanced Flue Gas Stoves IN1159 Edition F March 2012 PART NUMBER SERIAL NUMBER... - Page 2 Information from the Euroheat Technical Team Euroheat and Nestor Martin have a policy of continual research and development and reserve the right to modify its appliances without prior notice. We make every effort to ensure that the information provided in this document is correct and accurate at the time of printing.
-
Page 3: Table Of Contents
3: On the identification plate located below the gas valve. 4: On the registration form. 5: On the registration certificate returned to the user after successful registration. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed F... -
Page 4: Safety Precautions
In your own interest, and those of safety, and in accordance with the Gas Safety (Installation and Use) Regulations, Euroheat stoves must be installed by a suitably qualified Gas Safe technician using the appropriate fittings for the gas type being used, and the stove must not be modified in anyway. -
Page 5: Technical Data With Mertik Maxitrol Gv34 Gas Valve
Technical Data with Mertik Maxitrol GV34 Gas Valve Harmony 15 and Stanford 15 Gas Balanced Flue Model Number Harmony 15 Stanford 15 Heat Output Maximum G20 Natural Gas 4.05kW G31 Propane 4.03kW Standard supply appliance is configured for Natural Gas; for LPG specify at time of order... -
Page 6: Accessories Supplied With Stove
Grub Screw but should be removed unless required to help level the stove. Plastic Hearth Protector © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed.F... -
Page 7: Operating Instructions
1. Installation It MUST be returned to Euroheat for the registration to be completed. The stove should be installed by a competent qualified heating engineer, who will be conversant with the Building Regulations and Codes of Practice current at the time of installation. Installation instructions are supplied with the stove which contain instructions specific to the appliance. -
Page 8: Hearth And Fireplace Clearances
Curtains and furnishings should be a minimum of 1m from the stove. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed.F... -
Page 9: Appliance Location
Care should be taken to ensure that pipe work brought through metal structures has been secured to prevent chaffing, but allow for thermal expansion. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed F... -
Page 10: Flue Spigot Fitting
1) Remove the inner adapter pipe, see above, and choke plate from the top of the stove. The choke plate is not required for the rear flue option. Choke plate © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed.F... - Page 11 Do not fit the choke plate to the rear outlet as it will restrict the air flow and stall the flue gasses and the stove will not work. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed F...
- Page 12 7) Fit the gasket and rear blanking plate onto the top flue exit using the countersunk screws. If it has an enamel finish the cup washers should also be used to protect the enamel finish. Cup washer for enamelled finished stoves © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed.F...
-
Page 13: Installation Of The Flue System
We would advise the use of Fraxfill on all flue joints and for all fuel types, available from your Euroheat dealer or directly from Euroheat. -
Page 14: 12Installation Of The Gas Log Effect
Right Hand Log Identified by the “V” at one end. Front Log Identified by the one round hole which locates the log on the ceramic burner base. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed.F... -
Page 15: Placement Of The Ember Glow Fibres
(see the log fitting instructions which follow). The pack containing the ember glow fibres contains more than required. The additional embers should be kept for further service requirements. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed F... - Page 16 The other end of the log resting upon the back log. Place in indentations provided © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed.F...
-
Page 17: Installation Of The Gas Coal Effect
The addition of further ceramic logs or coals is strictly prohibited. The Set of Coal Pieces The Burner © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed F... - Page 18 When fitted correctly the back and front coals will look like this. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed.F...
- Page 19 With the coals in position a small amount of Ember glow that has been teased carefully into very loose shapes can be added. It should be put over the jets of the burner in front of the front coal © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE...
-
Page 20: Gas Connection
Turn the larger left hand control anti-clockwise to increase, clockwise to decrease the desired heat output. Ensure that the main burner lights within 3 seconds. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed.F... - Page 21 (The flat blade screw can be accessed through a hole in the bottom plate of the stove under the valve, anti-clockwise to increase, clockwise to decrease.) © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed F...
-
Page 22: Gas Pressure Test Nipple Locations
Gas Pressure Test Nipple Locations System Pressure Test Nipple (Line Pressure) Operating Pressure Test Nipple (8mm spanner required) © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed.F... -
Page 23: Fitting The Remote Control
Ensure that the receiver will accept instructions from the handset. They must match each others coding and the instructions for this are in the operating instructions. Operating Instructions These are supplied with the remote control kit. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed F... -
Page 24: Information For Users Which Must Be Advised By The Installer Verbally Or In Writing
40785 Spray Paint : Black for rear heat shield of stove 60429 Enamel Touch Up : Green 27437 Enamel Touch Up : Satin Black 27440 © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed.F... -
Page 25: Servicing Instructions
Confirm appliance is left in a safe operational condition. Use only genuine replacement parts, non standard components could invalidate the warranty and may be dangerous. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed F... -
Page 26: Burner Removal And Replacement
The rear of the burner should be slid into the two locating brackets at the rear of the stove (See below). The two adjustable front brackets should then be replaced. Two Locating Brackets © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed.F... - Page 27 Replace the Coal or Log Effect Follow the instructions on pages 12 to 18. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed F...
-
Page 28: Changing Gas Operating Type
G31 LPG The air collar should be adjusted to 3mm open The air collar should be adjusted to 5mm Primary Air Collar Primary Air Collar © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed.F... -
Page 29: Thermocouple Replacement
3) Remove the screws and withdraw the gas valve cover plate from within the stove (see below). Gas Valve Cover Plate Cover Plate Screw © EUROHEAT DISTRIBUTORS (H.B.S) LTD. March 2012 E & OE Instructions Part number IN1159 Ed F... - Page 30 Remove the retaining nut from the thermocouple as this will be required to fit the new thermocouple. Fitting the Replacement Euroheat Universal Thermocouple (MS2017) Mertik Pilot Assembly, flat blade 1) Loosely fit the 10mm nut to the pilot assembly and push the thermocouple sensor through the nut to the correct position and tighten the nut.
-
Page 31: Door Handle Adjustment
For the latest editions of all Euroheat documentation visit our web site www.euroheat.co.uk. We would request that you inform Euroheat of information which you feel is not provided in this document which would assist other users in the future. - Page 32 10,000 pages of technical information, spare parts, product shots, news and 1001 other things, - you will not find a more comprehensive solution to your queries, whatever time of the day. www.euroheat.co.uk Court Farm Business Park, Bishops Frome, Worcestershire WR6 5AY Pre sales:...
