Page 1: Servicing Instructions
Installation & Servicing Instructions Harmony 44 Conventional Flue Gas Stoves IN1113 Edition E June 2009 PART NUMBER SERIAL NUMBER... -
Page 2: Table Of Contents
3: On the identification plate located under the gas valve. 4: On the registration form. 5: On the registration certificate returned to the user after successful registration. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 3: Safety Precautions
In your own interest, and those of safety, and in accordance with the Gas Safety (Installation and Use) Regulations, Euroheat stoves must be installed by a suitably qualified Gas Safe technician using the appropriate fittings for the gas type being used, and the stove must not be modified in anyway. -
Page 4: Technical Data For H44
Net Efficiency being 85% Nat Gas and 84.3% LPG. The test data from which it has been calculated has been certified by BELTEST. The efficiency value may be used in the Governments Standard Assessment Procedure (SAP) for energy rating of dwellings. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 5: Accessories Supplied With Stove
Grub Screw stove. Plastic Hearth Protector © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 6: Installation Instructions
1. Installation It MUST be returned to Euroheat for the registration to be completed. The stove should be installed by a competent qualified heating engineer, who will be conversant with the Building Regulations and Codes of Practice current at the time of installation. Installation instructions are supplied with the stove which contain instructions specific to the appliance. -
Page 7: Flue And Chimney Requirements
(chimney pot). If the flue has any non vertical sections the height should be increased in line with BS 5440 : Part 1. For further information see the Euroheat Flue Guide IN1087. An approved gas flue terminal MUST be fitted in accordance to the manufacturers recommendations. -
Page 8: Example Of Stove Fitted Into An Existing Chimney
The example above shows an unacceptable installation into an unsound and unlined flue. The height is less than 3 meters and there is no cowl. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 9: Installation Of The Gas Supply
Do not obstruct the area directly beneath the stove as this may block the passage of air into the appliance. If any of these conditions are not fulfilled, DO NOT FIT THE STOVE until the problem has been rectified. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 10: Installation Of The Stove To The Flue System
The flue system may now be connected to the stove, ensure that all joints are sealed with a suitable fire resistant sealant we recommend Fraxfill (available from Euroheat Part No: MS9045). Some so called “Heat Proof” mastiks will only stand a temperature of 300°C before they start breaking down. -
Page 11: Changing Flue Outlet Direction
It and its support bracket and screws can be found in the bag of installation accessories supplied with the stove. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 12: Hearth And Fireplace Requirements
6" 150mm** 4" 100mm be supplied by your dealer. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 13: Installation Of The Gas Log Effect
Back log Ceramic burner Left log 1 gram bag ember glow fibres Ember cubes EMBERGLOW Platinum Bright Embers Front log Burner and Log Assembly Complete © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 14: Placement Of The Ember Glow Fibres
Do not cover pilot ignition route holes with either ember cubes or ember fibres. Place fibres and cubes to the side of this area. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... - Page 15 Gently rub the ember glow into the burnt surfaces of the log. Left log fits into groove in burner surface © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E...
- Page 16 When the appliance is first fired small adjustments to the ceramic cubes and ember glow can be made to achieve the desired effect. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E...
-
Page 17: Gas Connection
Turn the larger left hand control anti-clockwise to increase, clockwise to decrease the desired heat output. Ensure that the main burner lights within 3 seconds. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... - Page 18 (The flat blade screw can be accessed through a hole in the bottom plate of the stove under the valve, anti-clockwise to increase, clockwise to decrease.) © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E...
-
Page 19: Low Pressure Adjusting Screw
Gas Pressure Test Nipple Locations System Pressure Test Nipple (Line Pressure) Operating Pressure Test Nipple © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 20: Fitting The Remote Control
Ensure that the receiver will accept instructions from the handset. They must match each others coding and the instructions for this are in the operating instructions. Operating Instructions These are supplied with the remote control kit. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 21: Commissioning
Turn the gas valve control knob to the minimum flame size. Observe the operating pressure. See page 18. Thermocouple TTB Flue Spillage Sensor. TTB flue spillage sensor © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 22: Information For Users Which Must Be Advised By The Installer Verbally Or In Writing
Spray Paint : Black for rear heat shield of stove 60429 Enamel Touch Up : Green 27437 Enamel Touch Up : Satin Black 27440 © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 23: Servicing Instructions
Confirm appliance is left in a safe operational condition. Use only genuine replacement parts, non standard components could invalidate the warranty and may be dangerous. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 24: Burner Removal And Replacement
The two adjustable side brackets should then be replaced, these brackets should be adjusted so that the burner is level and when the centre is pushed down there is 1 to 2mm movement, see page 24. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE... - Page 25 1 to 2mm movement up and down. 10mm Silicon sealing washer Replace the Coal or Log Effect Follow the instructions on pages 13 to 16. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E...
-
Page 26: Thermocouple Replacement
Access to the gas valve can now be achieved, see picture on page 26. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... - Page 27 Remove and retain the securing nut from the thermocouple as this will be required to fit the new thermocouple. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E...
- Page 28 Fitting the Replacement Euroheat Universal Thermocouple (38641) Feed the cable through to the back of the stove and fit the TTB to the bracket, the nut should be secured finger tight, as using a spanner could damage the supporting bracket.
-
Page 29: Changing Gas Operating Type
The air collar should be adjusted to give The air collar should be adjusted to give a 11mm wide opening (X). a 16.5mm wide opening (X). © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... -
Page 30: Door Handle Adjustment
The door can be adjusted by loosening the nut securing the eccentric latch pin and screwing the pin in or out to adjust the horizontal and vertical closing position. © EUROHEAT DISTRIBUTORS (H.B.S) LTD. June 2009 E & OE Instructions Part Number IN1113 Ed. E... - Page 31 For the latest editions of all Euroheat documentation visit our web site www.euroheat.co.uk. We would request that you inform Euroheat of information which you feel is not provided in this document which would assist other users in the future.
- Page 32 10,000 pages of technical information, spare parts, product shots, news and 1001 other things, - you will not find a more comprehensive solution to your queries, whatever time of the day. www.euroheat.co.uk Court Farm Business Park, Bishops Frome, Worcestershire WR6 5AY Pre sales:...
