- Page 2 ASSEMBLY INSTRUCTIONS HOUSTON 2 DRAWER BEDSIDE IMPORTANT : READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR USE YOUR HOUSTON 2 DRAWER BEDSIDE . PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. ASSEMBLY: Assembly should be carried out with this item laying flat, not standing upright.
- Page 3 Vendor: S000350 Parts List Hardware List Part Descripion Part Description Top panel Cam lock Bottom panel Minifix screw Side panel ( Left ) Plastic cap Side panel ( Right ) M8 x 30mm Wood Dowel Back panel M6 x 50mm CSK Cap Wood screw Drawer front ( Up ) Allen key M4 Drawer front ( Down )
- Page 4 Vendor: S000350 Step 1: Prepare these parts for assembly using hardware parts A1, A2, B, F and L1. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 2: Attach side panel (3) and (4) to top panel (1) using hardware A1 and A2 with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
- Page 5 Vendor: S000350 Step 4: Attach bottom panel (2) to side panel (3) and (4) using hardware C and D. DO NOT use any power tools as this may damage the frame and will invalidate any claim. C x 4 Step 5: Attach hardware J1 into top panel (1), bottom panel (2), side panel (3) and (4) using hardware J2 with a screwdriver (not provided).
- Page 6 Vendor: S000350 Step 6: Attach metal frame (11) to metal bone (12) using hardware D and I. DO NOT use any power tools as this may damage the frame and will invalidate any claim. I x 8 Step 7: Attach metal frame (11) to bottom panel (2) using hardware D and H. DO NOT use any power tools as this may damage the frame and will invalidate any claim.
- Page 7 Vendor: S000350 Step 8: Attach the hardware K to the drawer front down (7) using hardware E, attach the drawer front up (6) or drawer front down (7) and the drawer back (9) to 1x drawer side (8) using hardware G. Slide in the drawer bottom (10) and attach the other drawer side (8) using hardware G.
- Page 8 If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. · Why don't you send us photos of your assembled furniture to info@birlea.com to be shared in our #birleahome feature on instagram. Page...
