- Page 2 Always use on a level, even surface. It is recommended that two people handle and assemble the item. Birlea advise you use the wall straps provided to further enhance the safety of this product. CARE & MAINTENANCE: Assemble in the room of use.
- Page 3 Vendor: S000398 PARTS LIST HARDWARE LIST: Carton 1 of 1 Carton 1 of 1: Part Description Part Description CAM NUT 15mm Top Panel CAM BOLT Left Panel WOOD DOWEL M6 x 25mm Right Panel CSK SCREW M4 x 38mm Front Support Panel CSK SCREW M3.5 x 12mm Bottom Front Panel METAL RUNNER TRUCK 12"...
- Page 4 Vendor: S000398 Insert hardware part A & part B using a screwdriver (not provided). Insert hardware part C using a small mallet (not provided). Insert hardware part H using a small mallet (not provided). Attach hardware F with screw E using screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
- Page 5 Vendor: S000398 Attach the Left Front Post Panel (8) to Left Panel (2) and Right Front Post Panel (9) to Right Panel (3) by screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Attach the Front Support Panel (4) and Bottom Front Panel (5) and Bottom Back Panel (6) and Back Support Panel (7) and Top Front Post Panel (10) and Bottom Front Post Panel (11) to Right Panel (3) and Right Front Post Panel (9) by screwdriver (not provided).
- Page 6 Vendor: S000398 Attach the Front Support Panel (4) and Bottom Front Panel (5) and Bottom Back Panel (6) and Back Support Panel (7) and Top Front Post Panel (10) and Bottom Front Post Panel (11) to Left Panel (2) and Left Front Post Panel (8) by screwdriver (not provided).
- Page 7 Vendor: S000398 Attach the Back Panel (18) with Nail (I) by small mallet (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Attach the Drawer Left Panel (14) and Drawer Right Panel (15) and Drawer Support Panel (16) to Drawer Back Panel (13) with Screw (D) by screwdriver (not provided).
- Page 8 Vendor: S000398 Insert Drawer Bottom Panel (17) as shown and fix Drawer Front Panel (12) by screwdriver (not provided). Fix hardware (G) onto the Drawer Left Panel (14) and Drawer Right Panel (15) using Screw (E) by screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
- Page 9 .If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. .Why don't you send us photos of your assembled furniture to info@birlea.com to be shared in our #birleahome feature on lnstagram.
