- Page 2 Always use on a level, even surface. It is recommended that two people handle and assemble the item. Birlea advise you use the wall straps provided to further enhance the safety of this product. CARE & MAINTENANCE: Assemble in the room of use.
- Page 3 Vendor: S000398 PARTS LIST HARDWARE LIST: Carton 1 of 2 Carton 1 of 2: Part Description Qty Part Description Left Panel CAM NUT 15mm Right Panel CAM BOLT Left Post Panel WOOD DOWEL M6 x 25mm Right Post Panel CSK SCREW M3.5 x 12mm Top Post Panel CSK SCREW M4 x 16mm Bottom Post Panel...
- Page 4 Vendor: S000398 Insert hardware part A & part B using a screwdriver (not provided). Insert hardware part C using a small mallet (not provided). Insert hardware part K using a small mallet (not provided). Fix hardware I with screw E using screwdriver (not provided). Fix hardware M with screw D using screwdriver (not provided).
- Page 5 Vendor: S000398 Attach the Post Panel together (9),(10),(11)&(12) by screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Attach the Bottom Panel(4) , Fix Shelf Panel (5) , Plinth Panel (7) Top and Back Support Panel (6) & (8) to Right Panel (3) by screwdriver (not provided).
- Page 6 Vendor: S000398 Attach the Left Panel (2) to Bottom Panel (4) , Fix Shelf Panel (5) , Plinth Panel (7) Top and Back Support Panel (6) & (8) by screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Attach ALL Post Panel (9) , (10) , (11) &...
- Page 7 Vendor: S000398 Attach the Top Panel (1) to Left and Right Panel (2) & (3) using screw (G) By screwdriver (not provided). Fix the Top panel (1) to Top Support Panel (8) by screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Attach The Back Panel (14) using Nail (K) by screwdriver (not provided).
- Page 8 .If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. .Why don't you send us photos of your assembled furniture to info@birlea.com to be shared in our #birleahome feature on lnstagram.
