Weather Protection - Davey SILENSOR PRO SP200BTP Installation And Operating Instructions Manual

Dimensions
DIMENSIONS (inches)
Mounting Inlet/
Net Weight
Holes
Outlet
Model A B C D E F G H I
(lbs)
Diameter PVC
SP200BTP 12 26.3 12.6 13.7 2.55 9.05 14.96 7.87 9.84 0.4 1½" / 2" 30.8
Installation of the SilensorPro VSD Pool pump with Bluetooth
Location
The pump should be located as close to the water as practicable and mounted on
a firm base in a well-drained position, high enough to prevent any flooding. It is the
installer's/owner's responsibility to locate the pump such that the nameplate can be
easily read and the pump can be readily accessed for service.

Weather Protection

It is recommended that the pump is protected from the weather. Enclosures
should be ventilated to prevent condensation build-up.
7
