Technical Specifications; Operating Limits - Davey SILENSOR PRO SP200BTP Installation And Operating Instructions Manual

Using your SilensorPro VSD pump with a Davey Salt Water
Chlorinator
Davey ChloroMatic and EcoSalt salt water chlorinators require a minimum flow
rate of 21 gallons per minute (80 lpm) through the chlorinator cell
efficiency and cell life. Please refer to the performance graph below as a
reference for the flow in your pool and refer to the pressure indicated by the
gauge on the media or cartridge filter.
Ensure flow rate is sufficient to cover your chlorinator cell plates completely at
all times of operation.

Technical Specifications

Model
Head (m)
RPM
Enclosure Class (IP)
Insulation Class
Voltage (V)
Frequency (Hz)
Motor Input Power
(W / hp)

Operating Limits

Max Water temperature
Max Ambient temperature
SP200BTP
22
Speed 1 to 10 (1500 - 3600)
Backwash Speed – Variable
45
F
220/240 AC
60
Speed Setting 1 - 128W / 0.17hp
Speed Setting 5 - 524W / 0.70hp
Speed Setting 10 – 1111W / 1.49hp
Backwash Setting – 1320w / 1.77hp
6
for best
104°F / 40°C
122°F / 50°C
