Operating Instructions
(Single Phase & 400V 3 Phase Models)
WARNING: Failure to follow these instructions and comply with all applicable
codes may cause serious bodily injury and/or property damage.
The installation of this product should be carried out by a person knowledgable
in swimming pool plumbing requirements following the Installation Instructions
provided in this manual.
Please pass these instructions on to the operator of this equipment.
Installation and
Advertisement
Table of Contents
Related Manuals for Davey SILENSOR SLS100
Summary of Contents for Davey SILENSOR SLS100
- Page 1 Installation and Operating Instructions (Single Phase & 400V 3 Phase Models) WARNING: Failure to follow these instructions and comply with all applicable codes may cause serious bodily injury and/or property damage. The installation of this product should be carried out by a person knowledgable in swimming pool plumbing requirements following the Installation Instructions provided in this manual.
-
Page 2: Weather Protection
Davey office as listed on the back of this document. Your Davey Silensor Congratulations on your purchase of a quality product from the Davey range of Pool and Spa Equipment. You are assured of many years of reliable and efficient performance from your Davey Silensor backed by Davey’s three year guarantee. - Page 3 AS/NZ 3000 Wiring standards). Davey Silensors are suitable for connection to a nominal 240 volt 50Hz power supply and are equipped with a flex lead and 3 pin plug. If a power outlet is not available within 3 metres of the pump, a 3 pin power point in a safe, dry place, may need to be provided by an electrician.
-
Page 4: Pipe Connection
Pipe Connection A set of applicable (European or Australian) barrel unions are provided for connecting to the piping from the pool. The pumps are designed to accept the following PVC pipes by fitting the pipe to either the inside or the outside of the union tail. Inlet PVC Outlet PVC Model... -
Page 5: Troubleshooting
If you are unable to resolve any installation or operation difficulties with your Silensor , contact the supplier from whom the pump was purchased or your nearest Authorised Davey Pool Equipment Service Centre. If any further assistance is required, contact the Davey Customer... -
Page 6: Water Quality
Removal of the Pump from Pipework Should it be necessary to remove the pump, follow these instructions: 1. Switch off the power and remove the plug from the power source. NOTE: If the pump is wired into a time clock or another automatic control, the wiring should be removed by a qualified electrician. - Page 7 Three phase models are designed for connection to a nominal 400V power supply, but must be wired with a contactor with ‘quick-trip’ overloads set a 4.3 amps. Davey recommend the use of overloads which also have the ability to detect “single phasing” or “dropped phase” conditions in the power supply.
- Page 8 DANGER - Hazardous suction. Do not block water entry into filtration system with any part of your body as the pressure can trap hair or body parts, causing severe injury or death. Do not block suction. Turn off pump immediately if someone becomes trapped. CAUTION! Do not add chemicals directly to the pool skimmer.
- Page 9 CAUTION! In the interest of safety, we advise that all brands and types of pool pumps must be installed in accordance with AS3000 wiring rules or equivalent. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
- Page 10 NOTES...
- Page 11 NOTES...
- Page 12 ABN 18 066 327 517 Website: davey.com.au Website: daveynz.co.nz ® Davey is a registered trademark of Davey Water Products Pty Ltd. © Davey Water Products Pty Ltd 2018. P/N 400278-9 * Installation and operating instructions are included with the product when purchased new.
