Specifications
4
4.3

Power supply

4.4

Battery operation

14
Gas standard
API Standard Conditions 15/1013 15 °C (60 °F)
Cummings Standard 25/991
20 °C/1013 mbar 20/1013 20 °C (68 °F)
Normal Temperature and NTPD
Pressure
Normal Temperature and NTPS
Pressure, Saturated
Ambient Pressure at 25 °C AP25
In this User manual, the unit L/min is based on ambient conditions of
0 °C and 1013 mbar (DIN 1343).
Please refer to Appendix B: Measurement parameters and units.
Here, you will also find the conversion factors for the units of meas-
urement.
Input voltage of the power supply unit:
Output voltage of the power supply unit: 24 VDC, 2.7 A
PF-300 PRO input voltage:
Power supply protection class:
Only use the power supply unit and cable provided!
Operating time in battery operation:
Operating time in battery operation
with MultiGasAnalyser:
Charging the battery
A complete charging process takes 8 h. The service life of the battery is extended if
the battery is charged completely only after a prompt by the device.
The device indicates visually and audibly when the battery must be
charged. Please do not store the battery in depleted state.
Caution: depletion can damage the battery beyond repair!
Temperature Pressure
1013.25 mbar
(14.7 psia)
991 mbar
25 °C (77 °F)
(500 ft altitude)
1013.25 mbar
(760 mmHg)
1013.25 mbar
20.0 °C (68 °F)
(760mmHg)
1013.25 mbar
20.0 °C (68 °F)
(760mmHg)
Current Ambient
25.0 °C (77 °F)
pressure
100 – 240 VAC, 50 – 60 Hz, 2.0 A
24 VDC, 2.5 A
Class I
16 hours
13 hours
Relative
humidity
0 %
0 %
0 %
0 %
100 %
Current gas
humidity
