Principle; Connection; Led Signal - IMT Analytics FlowAnalyser PF-300 PRO User Manual

8.4

Principle

8.5

Connection

8.6

LED signal

IMT Analytics AG
1
3
MultiGasAnalyser OR-703 consists of an OR sensor head
2
tional) , an airway adapter
The OR sensor head is located at the top of the airway adapter. The sensor head
contains all the optical components that are required for measuring all the gases.
Since all the calibration data is stored in the relevant sensor head, it is possible to
change the sensors without recalibration.
The OR sensor first must be connected to the RS-232 input of FlowAnalyser PRO
(at the back).
Attach the OR sensor to the airway adapter from above. If it is in the correct position,
the sensor will click into place. Wait 15 minutes before the first measurement until the
sensor has warmed up.
A green LED indicates that the sensor is ready for operation.
Continuous green light
Continuous blue light
Continuous red light
Flashing red light
Flashing green light
MultiGasAnalyser OR-703
4
2
1
3 4
and a connecting cable
System OK
Anaesthetic agent exists
Sensor error
Please check the adapter
Calibration of the OR sensor
, an O sensor cell (op-
2
.
8
37
