INSTALLATION AND MAINTENANCE INSTRUCTIONS
B112LP Plug-in Detector Base
For use with the following smoke detectors:
IN US: 1151, 2151
IN CANADA: 1151A, 2151A
IN EUROPE: 1151E, 2151E
Specifications
Base Diameter:
Base Height:
Weight:
Mounting:
Operating Temperature Range:
Operating Humidity Range:
Electrical Ratings - includes base and detector
System Voltage:
Maximum Ripple Voltage:
Start-Up Capacitance:
Standby Ratings:
Alarm Ratings:
Reset Voltage:
Reset Time:
Start-up Time:
Relay Contact Ratings:
Resistive or Inductive (60% Power Factor)
Form A:
Form C:
Before Installing
Please read thoroughly System Sensor's Applications Guide
for System Smoke Detectors (SPAG91), which provides
detailed information on detector spacing, placement,
zoning, wiring, and special applications. This manual is
available online at www.systemsensor.com. (For installa-
tion in Canada, refer to CAN/ULC-S524, Standard for the
Installation of Fire Alarm Systems and CEC Part 1, Sec. 32.)
NOTICE: This manual should be left with the owner/user
of this equipment.
IMPORTANT: The detector used with this base must be
tested and maintained regularly following NFPA 72 require-
ments. The detector used with this base should be cleaned
at least once a year.
6.2 inches (157 mm)
0.95 inches (24 mm)
0.3 lb. (137 g)
4-inch square box with or without plaster ring. Min. depth–1.5 inches
3-1/2-inch octagon box. Min. depth–1.5 inches
0° to 49°C (32° to 120°F)
10% to 93% Relative Humidity, Noncondensing
24 VDC
4 Volts peak-to-peak
0.02µF Maximum
20 VDC Minimum
29 VDC Maximum
120 µA Maximum
17 mA Minimum
36 mA Maximum
1.4 VDC Minimum
0.3 Seconds Maximum
(The optional RA400Z operates within specified detector alarm currents.)
34.0 Seconds Maximum
2.0 A @ 30 VAC/DC
2.0 A @ 30 VAC/DC
0.6 A @ 110 VDC
1.0 A @ 125 VAC
General Description
The Model B112LP detector base is designed for use with
System Sensor model 2151 photoelectronic and 1151 ioniza-
tion detector heads. This four-wire base is equipped with
screw terminals for the connection of power, ground, and
an optional remote annunciator.
Mounting
The detector base mounts directly to 3-1/2 inch and 4-inch
octagon boxes and 4-inch square boxes, with or without
plaster rings. To mount the base, remove the decorative
ring by rotating it in either direction to unhook the snaps
before separating the ring from the base. Use the screws
supplied with the junction box to attach the base to the
box through the appropriate slots in the base (see Figure
1). Position the decorative ring around the base and rotate
it in either direction until the ring snaps into place.
1
