ActronAir Easyconnect
Installation and Setup Guide for
UltraSlim Ducted, Bulkhead Ducted
and Cassette Systems
Smart Port compatible with:
CRE-071AS
CRE-100AS
CRE-125AS
CRE-140AS
LRE-071AS
LRE-100AS
LRE-130AS
IMPORTANT NOTE:
Please read this manual carefully before installing or operating your air conditioning unit.
MRE-035AS
MRE-050AS
BRE-026BS
BRE-035BS
BRE-052BS
BRE-071BS
Advertisement
Related Manuals for ActronAir easyconnect CRE-071AS
Summary of Contents for ActronAir easyconnect CRE-071AS
- Page 1 ActronAir Easyconnect Installation and Setup Guide for UltraSlim Ducted, Bulkhead Ducted and Cassette Systems Smart Port compatible with: CRE-071AS MRE-035AS CRE-100AS MRE-050AS CRE-125AS BRE-026BS CRE-140AS BRE-035BS LRE-071AS BRE-052BS LRE-100AS BRE-071BS LRE-130AS IMPORTANT NOTE: Please read this manual carefully before installing or operating your air conditioning unit.
-
Page 2: Table Of Contents
Installation Guide Easyconnect App Table of Contents 01. Specification and Precautions ......3 02. Components ............4 03. Installation ............5 04. Download and Install the Easyconnect App ..10 05. Create an Account ..........10 06. Get Started ............11 07. -
Page 3: Specification And Precautions
Easyconnect App and connected controllers. • ActronAir will not be liable for any issues and problems caused by network connections, Wi-Fi router and smart devices. Please contact the product supplier of these third party devices directly to get further assistance. -
Page 4: Components
Installation Guide Easyconnect App 02. Components Name Shape Quantity Smart Port Reciever and CN2 Cable Extension Cable (6 m) 4 Core Wire Control Cable Disposable Remote Controller (Easyconnect setup only) Easyconnect Wi-Fi USB QR Label Screw Wall Mounting Plug AAA Battery (1.5V) Installation Guide - Easyconnect App Document: 9590-4009 Ver. -
Page 5: Installation
Installation Guide Easyconnect App 03. Installation Wi-Fi controller structure size figure: ( All dimensions are in mm unless specified). 36.8 Figure 4-1 Do not exceed supplied cable lengths between indoor unit and smart port. Extension of this length may create loss of communication between the PCB and/or wired control Wi-Fi Smart Port. - Page 6 Installation Guide Easyconnect App 1. Remove the backing plate from the Smart Port Reciever. Insert a screwdriver into the two slots in the lower part of the Smart Port Reciever and remove the backing plate. (See Figure 4-2) smart port the smart port o the slots in the e slots in the...
- Page 7 Screws (M4×20) ig.4-6) Installation Guide Easyconnect App sert the smart kit with slightly strength into the m 3. Insert the supplied Easyconnect Wi-Fi USB into the port at the back of the f the smart port .(Fig.4-7) Smart Port Reciever. (See Figure 4-4) 4.
- Page 8 Installation Guide Easyconnect App To main PCB CN3 Terminal (4 Core Wire Control Cable Connection) Figure 4-7 CN2 Cable To the Connected Wired Controller Figure 4-8 Installation Guide - Easyconnect App Document: 9590-4009 Ver. 2 201126...
- Page 9 Installation Guide Easyconnect App 4. INSTALLATION METHOD wire controller Extension cord smart port 4-core shielding wire Figure 4-9 The connective wires group-2 Fig 4-4 b. Conection to indoor unit with no wired connection. If you want to use both wire controller and WIFI control at the Run the 6m Extension Cable (Supplied) from the Smart Port Receiver CN2 same time , you can use the CN3 port on the smart port 4.
-
Page 10: Download And Install The Easyconnect App
4-9) When under installation, reserve certain leng connecting wire for convenient to take down the s while during maintenance. Installation Guide Easyconnect App 8. Reattach the upper part of the smart port 5. Reattach the upper part to the PCB backing cover. After adjusting the upper case and then buckle th Buckle the upper case after adjusting it, to avoid clamping the wiring during installation and clip it into place onto the backing plate mounted... -
Page 11: Get Started
Installation Guide Easyconnect App 1. Tap on Create Account. 2. Enter your e-mail address, create and confirm a unique password, confirm the terms and conditions and tap on Registration. 06. Get Started NOTES • Ensure that the Android or iOS device can be automatically connected to the Wi-Fi network - you can adjust this in your phone settings. - Page 12 Installation Guide Easyconnect App 1. Tap on + Add Device. 2. Tap the Cassette/Duct option. Installation Guide - Easyconnect App Document: 9590-4009 Ver. 2 201126...
- Page 13 Installation Guide Easyconnect App 3. Power the Air conditioner off from the power supply for 15 seconds, then back on again. 4. Within 8 minutes of power being reset, press the LED button on the remote control 7 times - this will initiate access point mode and allow your phone to link with the Easyconnect app setup process.
- Page 14 Installation Guide Easyconnect App 5. The next step will direct you to connect your network - link to: net_ac_xxxx Default password is “12345678”. NOTE Android devices will allow you to scan the QR code provided with the Easyconnect module, this will bypass the manual setup - allowing for quicker configuration.
- Page 15 Installation Guide Easyconnect App 6. Select your Wi-Fi name (SSID) and enter your router password to commence configuration. 7. When a Wi-Fi connection has been established between Easyconnect and the network - automatic setup will begin. • Once network configuration is successful, a success message notification will appear on the display screen.
- Page 16 Installation Guide Easyconnect App 8. When opening the Easyconnect App, you are greeted with this login page. 9. After a moment, you are taken to your account screen, which will have your linked air conditioners. Multiple air conditioners can be controlled from the one account.
- Page 17 Installation Guide Easyconnect App 10. Press the power button to turn on the air conditioner. 11. Once on, you can control all available options for that air conditioner, to control others, you must go back to the main screen and activate them separately.
-
Page 18: Operating Functions
Installation Guide Easyconnect App 07. Operating Functions Clickwheel Use the clickwheel to adjust the system set temperature up/down. Vertical Swing Turns On/Off vertical louvre. Horizontal Swing Turns On/Off horizontal louvre. Turbo Sets turbo mode On/Off by pressing the lightning symbol when operating in heat and cool modes. - Page 19 Installation Guide Easyconnect App Appendix A Receiver Board for Ducted Units: Installation Guide - Easyconnect App Document: 9590-4009 Ver. 2 201126...
- Page 20 ©Copyright 2020 Actron Engineering Pty Limited ABN 34 002767240. ®Registered Trade Marks of Actron Engineering Pty Limited. ActronAir is constantly seeking ways to improve the design of its products. Therefore, specifications are subject to change without notice. Document: 9590-4009 Ver. 2 Issue Date: 11/2020...
