ActronAir Easyconnect
Installation and Setup Guide for Wall Hung
Systems
Compatible with:
Serene
Serene 2
WRE-026AS
WRE-026CS
WRE-035AS
WRE-035CS
WRE-050AS
WRE-050CS
WRE-071AS
WRE-072CS
WRE-080AS
WRE-085CS
IMPORTANT NOTE:
Please read this manual carefully before installing or operating your air conditioning unit.
Advertisement
Table of Contents
Related Manuals for ActronAir Easyconnect Serene
Summary of Contents for ActronAir Easyconnect Serene
- Page 1 ActronAir Easyconnect Installation and Setup Guide for Wall Hung Systems Compatible with: Serene Serene 2 WRE-026AS WRE-026CS WRE-035AS WRE-035CS WRE-050AS WRE-050CS WRE-071AS WRE-072CS WRE-080AS WRE-085CS IMPORTANT NOTE: Please read this manual carefully before installing or operating your air conditioning unit.
-
Page 2: Table Of Contents
Installation Guide Easyconnect App Table of Contents 01. Specification and Precautions ......3 02. Installation ............4 03. Download and Install the Easyconnect App ..5 04. Create an Account ..........5 05. Device Configuration ........... 7 05.01. Amazon Alexa 05.02. Google Home 05.03. -
Page 3: Specification And Precautions
Easyconnect App and connected controllers. NOTE ActronAir will not be liable for any issues and problems caused by network connections, Wi-Fi router and smart devices. Please contact the product supplier of these third party devices directly to get further assistance. -
Page 4: Installation
Installation Guide Easyconnect App 02. Installation BEFORE STARTING: Isolate the power to the indoor unit and ensure power is not being supplied to the system to prevent electric shock. Ensure correct lockout/ tag out procedures are adhered to. Remove the Easyconnect USB kit from the box and take off the protective cap. 1. -
Page 5: Download And Install The Easyconnect App
Installation Guide Easyconnect App Serene Serene 2 Install the Wi-Fi USB cable Install the Wi-Fi USB cable into CN03 if required. into CN03 if required. Serene Serene 2 Ensure that the Easyconnect Module is secured into the receiver panel. 3. Close the panel and reset power to the Air conditioner. 03. - Page 6 Installation Guide Easyconnect App 1. When the app is opened for the first 2. Tap on Create Account. time, it will ask permission for sending notifications. It is the discretion of the user to allow or disallow the permission. The user can change this permission at any time in the phone’s settings.
-
Page 7: Device Configuration
Installation Guide Easyconnect App 05. Device Configuration 05.01. Amazon Alexa Download Amazon Alexa from Once the Amazon Alexa app has google playstore or apple if you been installed on your device, haven’t done so already. Once open up the app. Click on the logged in, follow below steps “More”... - Page 8 Installation Guide Easyconnect App Search for “easyconnect” skill. Select Easyconnect” from the results list. Once you have selected A login prompt for easyconnect EasyConnect from the results list, will appear, login with your click on “Enable to Use” button Easyconnect app credentials. which will take you to the next step.
-
Page 9: Google Home
Installation Guide Easyconnect App Once logged in, the Amazon Alexa 10. Alexa will then start looking for App will confirm the successful devices to connect with. linking of your account. You can now close this window by clicking on “Done” on the top left hand corner. - Page 10 Installation Guide Easyconnect App Choose “easyconnect” and jump After logging in to your to the authorisation page of Easyconnect account, tap “Agree Easyconnect App. and Link”. You will be redirected to Google Home App and the device will be shown. Now you can use Google Home voice controller to control your devices.
-
Page 11: Smart Device (Easyconnect)
Installation Guide Easyconnect App 05.03. Smart Device (Easyconnect) NOTES • Ensure that the Android or iOS device can be automatically connected to the Wi-Fi network - you can adjust this in your phone settings. • To configure Easyconnect, a wireless remote controller must be used - a disposable control is supplied in the kit to setup the Wi-Fi. - Page 12 Installation Guide Easyconnect App 6. Select home Wi-Fi, enter the 7. Wait to connect to the network. password. 8. Device successfully detected. 9. You can choose an existing name or You can modify the default name. customize a new name. 05.03.02.
- Page 13 Installation Guide Easyconnect App 3. Power the Air conditioner off from 4. Within 8 minutes of power being the power supply for 15 seconds, reset, press the LED button on the then back on again. remote control 7 times - this will initiate access point mode and allow your phone to link with the Easyconnect app setup process.
- Page 14 Installation Guide Easyconnect App 5. The next step will direct you to connect your network - link to: net_ac_xxxx Default password is “12345678”. NOTE Android devices will allow you to scan the QR code provided with the Easyconnect module, this will bypass the manual setup - allowing for quicker configuration.
- Page 15 Installation Guide Easyconnect App 7. Select your Wi-Fi name (SSID) and 8. When a Wi-Fi connection has been enter your router password to established between Easyconnect commence configuration. and the network - automatic setup will begin. • Once network configuration is successful, a success message notification will appear on the display screen.
-
Page 16: Operation And Control
Installation Guide Easyconnect App 06. Operation and Control 06.01. Amazon Alexa SUPPORTED VOICE COMMANDS Please use the name of your Air Conditioner as <device>. Function Utterance Power On “Alexa, turn <device> on.” “Alexa, turn <device> off.” Power Off Report power state “Alexa, is <device>... -
Page 17: Google Home
Installation Guide Easyconnect App NOTE Some features may not be available depending on the model. Please refer to the product catalogue for applicable features 06.02. Google Home SUPPORTED VOICE COMMANDS Function Utterance Power On “Hey Google, turn on air conditioner” “Hey Google, turn off air conditioner”... - Page 18 Installation Guide Easyconnect App Function Utterance Fan Speed Medium “Hey Google, set air conditioner to medium speed.” Fan Speed High “Hey Google, set air conditioner to high speed.” Fan Speed Auto “Hey Google, set air conditioner to enhanced.” Report controller ambient “Hey Google, what is the temperature temperature on air conditioner?”...
-
Page 19: Smart Device (Easyconnect)
Installation Guide Easyconnect App 06.03. Smart Device (Easyconnect) 1. When opening the Easyconnect 2. After a moment, you are taken to App, you are greeted with this login your account screen, which will page. have your linked air conditioners. Multiple air conditioners can be controlled from the one account. -
Page 20: Smart Device - Operating Functions
Installation Guide Easyconnect App 07. Smart Device - Operating Functions Clickwheel Use the clickwheel to adjust the system set temperature up/down Vertical Swing Turns On/Off vertical louvre Horizontal Swing Turns On/Off horizontal louvre Turbo Sets turbo mode On/Off by pressing the lightning symbol on heat and cool mode Sleep Mode 8 hour customisable sleep setting depending on the user’s comfort. - Page 21 Installation Guide Easyconnect App ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................Installation Guide - Easyconnect App Document: 9590-4008 Ver. 6 230501...
- Page 22 Installation Guide Easyconnect App ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................Installation Guide - Easyconnect App Document: 9590-4008 Ver. 6 230501...
- Page 23 Installation Guide Easyconnect App ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................Installation Guide - Easyconnect App Document: 9590-4008 Ver. 6 230501...
- Page 24 ©Copyright 2019 Actron Engineering Pty Limited ABN 34 002767240. ®Registered Trade Marks of Actron Engineering Pty Limited. ActronAir is constantly seeking ways to improve the design of its products, therefore specifications are subject to change without notice. Installation Guide - Easyconnect App...
