Vega VEGAKON 61 Operating Instructions Manual
Conductive point level switch for liquids (front-flush installation)
Hide thumbs
Also See for VEGAKON 61:
- Operating instructions manual (24 pages) ,
- Operating instructions manual (24 pages)
Related Manuals for Vega VEGAKON 61
Summary of Contents for Vega VEGAKON 61
- Page 1 Operating Instructions Conductive point level switch for liquids (front-flush installation) VEGAKON 61 Relay (DPDT) Document ID: 32647...
-
Page 2: Table Of Contents
How to proceed if a repair is necessary ................17 Dismount..........................18 Dismounting steps......................18 Disposal ......................... 18 Supplement ..........................19 Technical data ........................ 19 Dimensions ........................22 Industrial property rights ....................23 Trademark ........................23 Editing status: 2022-03-11 VEGAKON 61 • Relay (DPDT) -
Page 3: About This Document
Symbols used Document ID This symbol on the front page of this instruction refers to the Docu- ment ID. By entering the Document ID on www.vega.com you will reach the document download. Information, tip, note This symbol indicates helpful additional information. -
Page 4: For Your Safety
During work on and with the device, the required personal protective equipment must always be worn. Appropriate use The VEGAKON 61 is a sensor for point level detection. You can find detailed information about the area of application in chapter " Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions. -
Page 5: Safety Label On The Instrument
That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter " Packaging, transport and storage" • Chapter " Disposal" VEGAKON 61 • Relay (DPDT) -
Page 6: Product Description
Alternatively, you can access the data via your smartphone: • Download the VEGA Tools app from the " Apple App Store" or the " Google Play Store" • Scan the DataMatrix code on the type label of the instrument or •... -
Page 7: Adjustment
Interfering buildup is automatically eliminated via the neutralisation electrode, the conductivity detected and the switching point sensitivity derived thereof. An adjustment of the instrument is not necessary. VEGAKON 61 can be used for reliable detection of products over a very wide conductivity and viscosity range. Voltage supply VEGAKON 61 is a compact instrument, i.e. - Page 8 Technical data - Ambient conditions" • Relative humidity 20 … 85 % Lifting and carrying With instrument weights of more than 18 kg (39.68 lbs) suitable and approved equipment must be used for lifting and carrying. VEGAKON 61 • Relay (DPDT)
-
Page 9: Mounting
(e.g. through cleaning processes) or on cooled or heated vessels. To maintain the housing protection, make sure that the housing lid is closed during operation and locked, if necessary. Fig. 3: Measures against moisture ingress VEGAKON 61 • Relay (DPDT) -
Page 10: Mounting Instructions
Mounting instructions Welded socket Remove the supplied seal from the thread of VEGAKON 61. This seal is not required when using the welded socket with O-ring in front. Before welding, unscrew VEGAKON 61 and remove the rubber ring from the welded socket. -
Page 11: Connecting To Power Supply
Make sure that the cable used has the required temperature resist- ance and fire safety for max. occurring ambient temperature Use cable with round cross-section. A cable outer diameter of 5 … 9 mm (0.2 … 0.35 in) ensures the seal effect of the cable gland. If you are using cable with a different diameter or cross-section, exchange the seal or use a suitable cable gland. Connection instructions Danger: Switch off power supply before starting connection work. Connect mains voltage according to the connection diagrams. VEGAKON 61 • Relay (DPDT) -
Page 12: Connection, Relay Module
10 Type plate of the electronics module Connection, relay module Floating relay output Is used to switch external voltage sources to relays, contactors, mag- netic valves, horns etc. Fig. 4: Electronics with relay output Relay output Voltage supply VEGAKON 61 • Relay (DPDT) - Page 13 Inductive loads also result from the connection to a PLC input or output and/or in combination with long cables. It is imperative that you take measures to extinguish sparks to protect the relay contact (e.g. Z diode) or use an electronic version with transistor output. VEGAKON 61 • Relay (DPDT)
-
Page 14: Setup
Signal lamp (2) The switching condition of the signal lamp can be checked when the housing is closed. To adjust VEGAKON 61 loosen the four screws with a wrench on the upper side of the instrument and remove the housing cover. - Page 15 Relay deener- lights gized Failure of the sup- ply voltage (mode A/B) Relay deener- gized Max. detection - Vessel empty Max. detection - Vessel full Min. detection - Vessel full Min. detection - Vessel empty VEGAKON 61 • Relay (DPDT)
-
Page 16: Maintenance And Fault Rectification
12. Check the hold of the wires in the terminals by lightly pulling on them 13. Check cable gland on tightness. The seal ring must completely encircle the cable. 14. Screw the housing lid back on The electronics exchange is now finished. VEGAKON 61 • Relay (DPDT) -
Page 17: How To Proceed If A Repair Is Necessary
7 Maintenance and fault rectification As soon as you insert the electronics module, VEGAKON 61 is ready for operation. How to proceed if a repair is necessary You can find an instrument return form as well as detailed information about the procedure in the download area of our homepage. By doing this you help us carry out the repair quickly and without having to call back for needed information. -
Page 18: Dismount
If personal data is stored on the old device to be disposed of, delete it before disposal. If you have no way to dispose of the old instrument properly, please contact us concerning return and disposal. VEGAKON 61 • Relay (DPDT) -
Page 19: Supplement
, 5 kHz Measurement current < 1 mA Output variable Output Relay output (DPDT), 1 floating spdt Switching voltage max. 253 V AC/DC Switching current max. 3 A AC (cos phi > 0,9), 1 A DC Breaking capacity Ʋ Min. 50 mW VEGAKON 61 • Relay (DPDT) - Page 20 Fig. 5: Ambient temperature - Process temperature Process temperature in °C Ambient temperature in °C Process pressure -1 … 25 bar/-100 … 2500 kPa (-14.5 … 362 psig) Conductance of the medium min. 7.5 µS/cm VEGAKON 61 • Relay (DPDT)
- Page 21 U >60 V DC, the ambient temperature can be max. 50 °C/122 °F) Power consumption 1 … 8 VA (AC), approximately 1.3 W (DC) Electrical protective measures Protection rating IP66 (NEMA Type 4X) Pollution degree Overvoltage category Protection class When used with fulfilled housing protection VEGAKON 61 • Relay (DPDT)
-
Page 22: Dimensions
9 Supplement Dimensions 80 mm x 110 mm ~30 mm (3.15" x 4.33") (1.18") M20x1,5 SW 41mm (1.61") Fig. 7: VEGAKON 61 Threaded version Cone version Temperature adapter VEGAKON 61 • Relay (DPDT) -
Page 23: Industrial Property Rights
Les lignes de produits VEGA sont globalement protégées par des droits de propriété intellec- tuelle. Pour plus d'informations, on pourra se référer au site www.vega.com. VEGA lineas de productos están protegidas por los derechos en el campo de la propiedad indus- trial. Para mayor información revise la pagina web www.vega.com. - Page 24 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2022 VEGA Grieshaber KG Am Hohenstein 113 Phone +49 7836 50-0 77761 Schiltach E-mail: info.de@vega.com...
