PERGOLA ASSEMBLY
STEP 7
H101103 TORX SOCKET SCREW
H101101 TORX PAN HEAD
(8)
1/4-20x3/4"
(16)
1/4-20
UPRIGHT ASSEMBLY - FROM PREVIOUS STEPS
(2)
H101054
H101053
SEALANT WASHER
STEEL WASHER
(8)
(2)
JOIST ASSEMBLY - FROM PREVIOUS STEPS
(8)
6x20
16
