PERGOLA ASSEMBLY
A1
POST - A4M01565
(2)
6"x6"x88" (152x152x2235)
JOIST ASSEMBLY - FROM PREVIOUS STEPS
(2)
A2
POST - A4M01566
(2)
6"x6"x88" (152x152x2235)
12
STEP 3
TORX PAN HEAD
H101101
1/4-20x3/4"
(8)
H101103
TORX SOCKET SCREW
1/4x20
(16)
H101053
STEEL WASHER
(8)
6x20
H101054
SEALANT WASHER
(8)
