Jacuzzi PROFILE Installation Manual page 33

Press the "Up/Down"
displayed.
While the LED above the thermometer symbol is on, hold
down the "Light" button for approximately 5 seconds: when
the button is released the screen briefly shows the new refer-
ence value alternated with the word "Eco"; then, the current
temperature will appear again.
To turn the function off, proceed as indicated above (press
the "Up/Down" button, etc.).
NOTE:
- To check the function status, press the "Up/Down"
"Eco" appears, the function is on.
Water filtering
The water needs to be filtered to keep it clean and clear. This option
is active during the day as follows:
- two filtration cycles that are repeated every 12 hours.
Each filtration cycle is has an initial phase, in which the pump
and the blower (where present) are turned on one at a time for
approximately one minute; then the cycle continues, activating
the Clearray Active Oxygen™ and the filtration pump for the re-
maining time.
S
ETTING THE FILTERING CYCLES
To set the filtering cycle:
Hold down the "Pump"
onds: dx (where "x" indicates the duration in hours) appears on the
screen.
Use the "Up/Down"
(from a minimum of 0 to a maximum of 12 hours).
NOTE: press and hold the button until you reach the desired val-
ue; by releasing the button and pressing it again, the adjustment is
made in the opposite direction.
Press the "Pump" button again and the selected value is
confirmed, and the cycle start delay is programmed with re-
spect to the "0" time (sy parameter where "y" indicates the num-
ber of hours).
WARNING: time "0" is the instant when power is supplied to the hot
tub through the main switch or the time when the parameters are
stored; if, for example, the value "4" is set as the start delay of the
cycle, this means that the filtration will start 4 hours after turning
on the hot tub, or after storing the parameters; it is also possible to
reduce the parameter value to 0 "s": In this case, the filtration cycle
will start immediately.
Set the start delay (from a minimum of 0 to a maximum of 12)
button: the current temperature is
button for approximately 5 sec-
button to enter the desired duration
using the "Up/Down"
"Pump" button to store the values inserted and to exit the
programming mode.
When the function is active, the LED of the respective symbol
lights up (if it flashes, it means that the cycle has been suspended;
see relative section).
During the filtration cycle, the relative LED flashes.
NOTES
If no key is touched for about 5 seconds, the device exits "parame-
ter-setting" mode.
If there is a power outage, the data in the memory is saved, but the
button: if time "0" will become the moment at which the electricity comes
back on. Therefore, it may be necessary to turn the main switch up
the line from the hot tub off and back on to re-align the cycle start
delay with the memorized parameters.
It is possible to vary the filtering cycle setting parameters at any
time by following the procedure provided at the beginning of this
chapter. By modifying these parameters, time "0" is "shifted"
to the time in which the new values are saved.
S
USPENDING THE FILTERING CYCLES
Activating the hydromassage stops the filtration cycle, but it
resumes about 5 minutes after the function has turned off.
Moreover, with these models, the "silence" mode also sus-
pends the filtering cycle (refer to the respective section for fur-
ther details).
The filtering cycle may be suspended by the anti-freeze pro-
tection ("Smart Winter") or due to overheated water. Refer to the
respective chapters.
C ® (
LEARRAY
The Clearray® system helps to disinfect and purify water, thus reduc-
ing the need for chemical products.
The Clearray® system operates automatically and is depend-
ent on activation of the filtration pump during the filtering cycle;
it remains off when the hydromassage is on; Clearray® begins
operating once again 40 minutes after switching off the afore-
mentioned functions (where a filtering cycle is active).
Hydromassage activation
This function is activated by pressing the "Pump"
(display B) or the
nalled by the respective LED - display B - which may also be flashing;
on displays A1/A2, the button briefly lights up blue, then returns to
white).
33
button and confirm the value with the
).
WHERE EXPECTED
button (display A1/A2) (activation is also sig-
button
