ISTRUZIONI PER L’USO Pagina INSTRUCTIONS FOR USE Page MODEL#: HC25series HC30series HC40series Rev. 03 del 22/06/11...
Page 2
AVVERTENZE − Leggere attentamente questo manuale prima di utilizzare il frigorifero. − Qualora questo apparecchio dovesse sostituirne uno di vecchio tipo si raccomanda di rendere inservibile l’eventuale serratura prima di rottamarlo. − Verificare che l’imballo sia integro, in caso contrario segnalarlo al trasportatore. −...
Page 3
− Mantenere libere da ostruzioni le aperture di ventilazione nell’involucro dell’apparecchio e/o struttura da incasso. − Non rimuovere mai le protezioni (carter) del frigorifero. − Eseguire sempre le verifiche, i controlli e le manutenzioni programmate descritte in questo manuale. − L’apparecchio non deve essere esposto alla pioggia. −...
Eventuali modifiche appariranno, secondo le necessità nelle successive versioni del manuale. Identificazione del costruttore o del responsabile per la CEE Il frigorifero è immesso sul mercato da : Vitrifrigo s.n.c Via Della Produzione, 9 61020 Montecchio (PU) Tel. +39 0721 491080 Fax.
INSTALLAZIONE E’ consigliabile pulire l’interno del frigorifero ad assorbimento utilizzando acqua tiepida e un detergente delicato, e poi asciugarlo completamente prima dell’uso. La temperatura dell’apparecchio dipenderà da diversi fattori: La temperatura nella stanza La frequenza e la durata con cui viene aperta la porta del frigorifero. Il numero di prodotti presenti nel frigorifero Potrà...
PARTI E CARATTERISTICHE DEL PRODOTTO Lampadina Scomparto Piedini Scaffale COME FAR FUNZIONARE IL FRIGORIFERO AD ASSORBIMENTO 1. Inserire la spina nella presa. 2. Per aggiustare la temperatura ruotare la manopola del termostato all’interno del frigorifero. SBRINAMENTO AUTOMATICO Alcuni modelli sono provvisti di un sistema di sbrinamento automatico. Per la maggior parte dei modelli, provvisti di un sistema di sbrinamento manuale, è...
① L A M P A D I N A ② SCHEMA ELETTRICO Per gli apparecchi con sbrinamento manuale ① ⑤ ③ ④ ③ ④ ② LAMPADINA Alimentazione elettrica HT Condotto termico INTERRUTTORE SAT Controllo della temperatura LAMPADINA LAMPADINA NOTA: Lampadina a LED non sostituibile dall'utente, in caso di guasto contattare il SERVIZIO DI ASSISTENZA.
Page 9
WARNINGS − Read this manual carefully before using the refrigerator. − If this appliance is replacing an older model, any locking device must be rendered completely non-functional prior to disposal. − Make sure that the packaging is undamaged; report any damage found to the carrier. −...
Page 10
− Never remove safeguards (casings) from the refrigerator. − Always perform the checks, inspections, and scheduled maintenance, as specified in this manual. − The appliance must never be exposed to rain. − Place foods inside the refrigerator in their original packaging or inside specific containers for use with foods. −...
Any variations will be included in subsequent versions as necessary. Identification of Manufacturer or EEC Officer Your refrigerator is made in China and placed on the market by: Vitrifrigo s.n.c Via Della Produzione, 9 61020 Montecchio (PU) Tel. +39 0721 491080 Fax.
INSTALLATION It is advisable to clean the inside of the absorption refrigerator with lukewarm water using a mild detergent, and then to dry it thoroughly prior to use. The temperature in the appliance will depend on: The temperature in the room The frequency and duration of periods when the door is open.
PRODUCT PARTS AND FEATURES Lamp Balcony Feet HOW TO OPERATE ABSORPTION REFRIGERATOR 1. Insert power plug into wall outlet Shel 2. To adjust the temperature turn thermostat knob inside the cabinet. , Automatic Defrosting Some models are with automatic defrosting system. For most models which are with manual defrosting system, you just turn the thermostat knob to zero position until the accumulated frost melts then return to normal position.
① ⑤ CIRCUIT DIAGRAM ② ③ ④ LAMP SWITCH ⑤ ② ③ LAMP XP Power Supply HT Heating Tube LAMP SWITCH SAT Temperature Control LAMP ④ NOTE: The LED lamp cannot be replaced by the user; in case of failure, contact the ASSISTANCE SERVICE. Pag.
2006/95/CEE 2004/108/CEE. DECLARATION OF CONFORMITY VITRIFRIGO snc, with it main office in via della Produzione 9, 61020 Montecchio (PS), Italy, hereby DECLARES, under its sole responsibility, that the refrigerator or refrigerating unit designed for the refrigeration and preservation of food...
