4 channel mode:
Channel Value Function
CH1 000-255 Master dimmer (0-100%)
000-031 Blackout
032-063 Open
064-095 Strobe (slow-fast)
096-127 Open
CH2
128-159 Pulse (slow-fast)
160-191 Open
192-223 Random strobe (slow-fast)
224-255 Open
000-127 Pattern wheel index
Pattern wheel clockwise rotation
128-191
CH3 (fast-slow)
Pattern wheel anti-clockwise rotation
192-255
(fast-slow)
000-127 Mirror dish rotation index
Mirror dish anti-clockwise rotation
128-191
CH4 (fast-slow)
Mirror dish clockwise rotation
192-255
(fast-slow)
www.prolight.co.uk
Operating instructions
6 channel mode:
Channel Value Function
CH1 000-255 Master dimmer (0-100%)
000-031 Blackout
032-063 Open
064-095 Strobe (slow-fast)
096-127 Open
CH2
128-159 Pulse (slow-fast)
160-191 Open
192-223 Random strobe (slow-fast)
224-255 Open
000-127 Pattern wheel index
Pattern wheel clockwise rotation
128-191
CH3 (fast-slow)
Pattern wheel anti-clockwise rotation
192-255
(fast-slow)
000-127 Mirror dish rotation index
Mirror dish anti-clockwise rotation
128-191
CH4 (fast-slow)
Mirror dish clockwise rotation
192-255
(fast-slow)
000-003 Blackout
004-031 Show 0 (All shows)
Show 1 (Mirror dish and pattern
032-059
wheel in both directions, no strobe)
Show 2 (Mirror dish and pattern
060-087 wheel in both directions, no strobe,
slow mode non-reactive to sound)
Show 3 (Mirror dish in both direc-
088-115 tions, pattern wheel static - selected
in menu)
CH5
Show 4 (Mirror dish CW, pattern
116-143
wheel CW)
Show 5 (Mirror dish CW, pattern
144-171
wheel CCW)
Show 6 (Mirror dish CCW, pattern
172-199
wheel CW)
Show 7 (Mirror dish CCW, pattern
200-227
wheel CCW)
Show 8 (Mirror dish and pattern
228-255 wheel in both directions, some
strobe)
CH6 000-255 Show mode motor speed (slow-fast)
