- Page 1 . p r o l i g h t . c o . u k Order code: EQLED53 user manual...
-
Page 2: Safety Instructions
Equinox Domin8R Safety WARNING FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! CAUTION! Keep this equipment away from rain, moisture and liquids. SAFETY INSTRUCTIONS Every person involved with the installation, operation & maintenance of this equipment should: Be competent Follow the instructions of this manual... -
Page 3: Operating Determinations
Equinox Domin8R Safety IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorised modification to the equipment. • Never let the power-cable come into contact with other cables. Handle the power-cable and all mains voltage connections with particular caution! •... -
Page 4: Technical Specifications
Equinox Domin8R Technical specifications You should find inside the Equinox carton the following items: 1, Equinox Domin8R 2, Power cable 3, Instruction manual Technical Specifications: DMX channels: 16 120 Ultra Bright LEDs (R: 40, G: 40, B: 40) Sound active, auto, master/slave and DMX modes Power in/out sockets 3-pin XLR in/out sockets Robust metal housing... -
Page 5: Sensitivity Control
Equinox Domin8R Overview Sensitivity Overview control Microphone Dip switches DMX out DMX in Power in/out sockets DMX Function Chart Channel Value Function 0-255 Mirror 1 tilt up and down 0-255 Mirror 2 tilt up and down 0-255 Mirror 3 tilt up and down 0-255 Mirror 4 tilt up and down 0-255... - Page 6 Equinox Domin8R DMX Set up DMX-512: • DMX (Digital Multiplex) is a universal protocol used as a form of communication between intelligent fixtures and controllers. A DMX controller sends DMX data instructions form the controller to the fixture. DMX data is sent as serial data that travels from fixture to fixture via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX fixtures (most controllers only have a data “out”...
- Page 7 Equinox Domin8R DMX Set up Notice: • Be sure to follow figures 2 & 3 when making your own cables. Do not connect the cable’s shield conductor to the ground lug or allow the shield conductor to come in contact with the XLR’s outer casing. Grounding the shield could cause a short circuit and erratic behaviour.
- Page 8 Equinox Domin8R Dip Switch Reference Chart DMX Dip Switch Quick Reference Chart Dip Switch Position Dip Switch position DMX Address...
- Page 9 w w w . p r o l i g h t . c o . u k...
