ROHO Air Insert Setup, continued
Note: Before following these instructions, read the safety information on the previous page. See also the instructions in
this manual for removing or replacing the air insert.
1 Inflate the air insert:
Suggestion: transfer off the air insert before inflating.
a. To access the inflation valve, remove or move the cover (if used).
b. Slide the hand pump nozzle over the inflation valve. Open the inflation valve, at
least one full rotation.
c. Inflate until all of the air cells feel firm.
d. Close the inflation valve completely. Remove the hand pump. Make sure the
inflation valve is closed.
Note: To open, turn the inflation valve at least one full rotation. The inflation valve will
spin freely when open.
2
Transfer - Warnings:
- Before the user transfers to the product, the air insert must be securely installed on the Tru-Shape seating
surface. A cover, if used, should be correctly installed.
- Before performing a Hand Check, the user must transfer to the product in their usual sitting position.
3 Perform a Hand Check:
During a Hand Check, you will use the width of the fingers to see if the air cells
are properly inflated*. When the air cells are properly inflated, the user is both
immersed in the air cells and supported by the air cells.
a. Slide your hand between the air cells and the user, and feel for the user's
lowest bony prominences**.
b. Refer to the Hand Check Guide below to adjust the air insert.
**Suggestion: To help locate the bony prominences while performing a hand check, lift
and lower the leg.
Hand Check Guide
Place a hand beneath the
lowest bony prominences (ITs)
and make sure there is at least
½ in. (1.5 cm) of air.
If the air cells are not properly
inflated, add or remove a small
amount of air. Repeat until the
air cells are properly inflated.

ROHO Air Insert Removal and Replacement

To remove the air insert:
1 If a cover is being used, remove it from the seating system.
2 Gently pull the inflation tubing through the hole, located in the back of the foam base.
3 Remove the air insert from the foam base.
To replace the air insert:
1 Line up the hook and loop fastener strips and refer to directional labels to correctly place the air insert into
the foam base. Press to attach securely.
2 Insert the inflation tubing through the hole, located in the back of the foam base.
3 Check inflation. If adjustment is needed, follow the air insert setup instructions.
4 If a cover is being used, replace it on the seating system.
Tru-Shape Operation Manual
Underinflated
7
* The recommended
distance between the
lowest bony prominence
and the seating surface is
½ - 1 in. (1.5 - 2.5 cm).
Overinflated
½ - 1 in. (1.5 - 2.5 cm)
Open Close
Proper Inflation
