Tallboy
Assembly Instructions
833/4448
- please keep for future reference
Dimensions
Width - 35cm
Depth - 30cm
Height - 169.5cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
Issue 1 - 26/04/11
Advertisement
Related Manuals for hygena Tallboy 833/4448
Summary of Contents for hygena Tallboy 833/4448
- Page 1 Tallboy Assembly Instructions 833/4448 - please keep for future reference Dimensions Width - 35cm Depth - 30cm Height - 169.5cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 Issue 1 - 26/04/11...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 1 and 2. - Page 3 Components - Panels Please check you have all the panels listed below 1 Base x 1 2 Middle shelf x 1 3 Bottom left side x 1 4 Bottom right side x 1 (29(w)cm x 28.5(d)cm) (35(w)cm x 30(d)cm) (89(h)cm x 28.5(d)cm) (89(h)cm x 28.5(d)cm) 5 Top left side x 1 6 Top right side x 1...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 0845 640 0800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Using Camlocks Step 1 Step 3 Connect the male Push the male camlock camlock as directed in into the entry hole. the assembly instructions using a screwdriver. Step 4 Step 2 Turn the female camlock Insert the female clockwise with a camlock as shown in the screwdriver.
- Page 6 Assembly Instructions Assembly Instructions Step 3 Step 3 Screw 2 x male camlock Fix 4 x small female camlock into reverse of drawer into front underside of 2 x top as shown. shelf as shown. Step 4 Fix 4 x 35mm male camlock and 2 x 30mm wooden dowel...
- Page 7 Assembly Instructions Assembly Instructions Step 6 Step 7 Connect top base Connect base and top shelf bottom right side to top right side as shown and tighten the female camlocks in Tighten female camlocks underside of base with in under side of top base a screwdriver.
- Page 8 Assembly Instructions Step 10 Connect top left side to exposed ends of top shelves as shown and tighten the female camlocks in underside of shelves with a screwdriver. Step 11 Fix assembly completed at Step 10 to middle shelf as shown using 4 x 35mm screw Note: the male camlocks and wooden dowels...
- Page 9 Assembly Instructions Step 12 Connect top assembly completed at Step 11 as shown. Tighten the female camlocks inside the unit with a screwdriver. Note: the groove in the edge of top must be pointing to the rear. Step 13 Connect assembly completed at Step 12 to assembly completed at Step 8 as shown.
- Page 10 Assembly Instructions Step 14 Fix bottom back panel and top back panel to the rear of the unit using back panel screws as shown.
- Page 11 Assembly Instructions Step 15 Connect door to the unit using 2 x hinge and 8 x 10mm screw as shown ( Connect handle door using 2 x 16mm bolt as shown ( Connect catch plate to door using 1 x 10mm screw...
- Page 12 Assembly Instructions Step 16 Insert 8 x shelf bracket into holes inside the unit at the desired heights ensuring that each set of shelf brackets are level with each other. Set 2 x internal shelf onto shelf brackets as shown.
- Page 13 Assembly Instructions Step 17 To prevent accidental toppling it is strongly recommended to fix the unit to a wall. Connect safety strap to the top of the unit using 1 x 10mm screw Fix the other end of the safety strap to a wall using 1 x rawl plug 1 x washer and 1 x...
-
Page 16: A Guide To Wall Mounting & Fixings
A Guide to Wall Mounting & Fixings IMPORTANT: When drilling into walls always check that there are no hidden wires or pipes etc. Make sure that the screws and wall plugs being used are suitable for supporting your unit. Consult a qualified tradesperson if you are unsure.
