WWW.LIGHTEMOTION.COM.AU
FLAT1012
User's instruction manual
This manual contains important information about the safe installation and use of this product
Please read this instruction manual carefully before installing or operating
Please keep these instructions in a safe place for future reference
www.lightemotion.com.au
Advertisement
Table of Contents
Related Manuals for Light Emotion FLAT1012
Summary of Contents for Light Emotion FLAT1012
- Page 1 WWW.LIGHTEMOTION.COM.AU FLAT1012 User’s instruction manual This manual contains important information about the safe installation and use of this product Please read this instruction manual carefully before installing or operating Please keep these instructions in a safe place for future reference...
-
Page 2: What Is Included
Congratulations on the purchase of your FLAT1012 by Light Emotion. We are confident that you will be satisfied with your purchase. We have prepared this manual to assist you with the operation of this item. CONTENTS SECTION Page WHAT IS INCLUDED, SAFETY INSTRUCTION POWER, FUSE, INSTALLATION MAINTENANCE &... -
Page 3: Installation
• In the event of serious operating problem, stop using the unit immediately. Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest authorized technical assistance center. •... -
Page 4: Maintenance & Periodic Checks
2. This lighting effect must be 0.5m away from any flammable materials or any walls or ceilings. 3. Do not block or inhibit the air flow from the ventilation holes. Light Emotion have various hook clamps* and safety wires* suitable for your PAR 64LED Please contact your local dealer for more information *Not included. -
Page 5: Operation
OPERATION: There are six kinds of running modes which are selected by ‘MODE’ button. The DP dot of fourth digital display will be flicking when you operate it, and then the DP dot will automatically turn off after 60 seconds if there is not any other operation. The four digit display will show the current operation mode. - Page 6 1) Manual dimmer color select Press ‘MODE’ button until the display shows red ‘ ’, then press the ‘SET UP’ to choose different color, green ‘ ’, blue ‘ ’, white ‘ ’ and UV ‘ ’, then press ‘UP’ or ‘DOWN’ button to set the dimming rate 0 to 255.
- Page 7 1) DMX address select mode The control board allows you to assign the DMX address which is defined as the first channel of FLAT1012. Press ‘MODE’ button until the display shows ‘ ’, then press ‘UP’ or ‘DOWN’ button to set the DMX address. The four digital display will be flicking when there is no controller signal.
- Page 8 7 channels mode • CH NO. DMX Value Function 0-255 0% - 100% 0-255 Green 0% - 100% 0-255 Blue 0% - 100% 0-255 White 0% - 100% 0-255 0% - 100% 0-255 Master dimmer 0% - 100% Color macros Please refer to color macros table NOTE: Channel 1, 2, 3, 4 and 5 have no function, when Channel 7 is working.
-
Page 9: Specifications
SPECIFICATIONS: • Weight: 3.4 kg • Size: 310 x 285 x 115mm • Power input: AC 90V-240V/50HZ-60HZ • Wattage: 105W • LEDs: 12 pcs 10RGBWUV (5 in one) • Beam angle of LEDs: 40 degree • 3-pin female XLR socket and 3-pin male XLR socket •...
