Introduction
Safety
Operation
Wiring Diagram
Troubleshooting
Maintenance
Step Assembly Lubrication
Maintenance In A Salt Environment
Notes

Introduction

This manual provides instructions for operating the Lippert Power Step 2.0, which are equipped with a step
lockout switch, control unit and permanent magnet motor onto a motorized coach.
The control unit is a current sensor as well as a switching device. When the motor assembly moves the step
tread to its extended position, or stops moving because of an obstruction such as a curb or the binding of a
damaged or bent step frame, the motor draws a larger amount of current. The control unit senses the larger
current draw and shuts off the power to the motor.
Control units are equipped with an ignition override system. This system is designed so the vehicle will
not be driven with the step in the extended position. When the step is locked in the extended position,
the door closed, and the ignition is turned on, the ignition override system will engage and the step will
automatically retract.
The Auto Extend feature is another safety feature designed to extend the step when the door is opened for
the first time after the vehicle ignition is turned off, regardless of the position of the step switch.
NOTE: Refer to vehicle OEM owner's manual (or OEM Requirements) which will provide switch position of
"on" or "off" for the step lock position.
Additional information about this product can be obtained from lci1.com/support or by downloading
the free LippertNOW app. The app is available on Apple App Store® for iPhone® and iPad® and also on
Google Play™ for Android™ users.
Apple App Store®, iPhone®, and iPad® are registered trademarks of Apple Inc.
Google Play™ and Android™ are trademarks of Google Inc.
For information on the assembly or individual components of this product, please visit:
https://support.lci1.com/steps/
NOTE: Images used in this document are for reference only when assembling, installing and/or operating
this product. Actual appearance of provided and/or purchased parts and assemblies may differ.
Rev: 01.07.22

TABLE OF CONTENTS

Page 2
2
3
4
5
6
6
6
6
7
CCD-0005465
