- Page 1 Stargazer Nano Wide Skylight OEM INSTALLATION MANUAL...
- Page 2 Notes Introduction The Stargazer Nano Wide Skylight can be installed on the roof of a unit to provide ventilation and allow sunshine in while providing privacy. The inner screen frame options allow for different types of ventilation and guards against pests. The inner screen assembly is a combination of a flyscreen and shade for windows that can be pulled across the skylight opening by hand using the two different profiles.
- Page 3 • Closed cell foam tape or butyl tape Prior to Installation Be sure to check that rough opening measures to the size stated on the Stargazer Nano Wide Skylight label. Be sure that the opening has proper framework supporting it, ie; aluminum, steel tubing or lumber.
- Page 4 Install #8 x1" pan quad T-2 self drilling screws w/assembled 5/8" neo-bond washers (Fig. 4A) in each pre-drilled hole (Fig. 4B) along the perimeter of the Stargazer Nano Wide Skylight outer frame. Apply the gunnable self-leveling sealant over each screw (Fig. 5A - green area).
- Page 5 Press in on the latch button (Fig. 12A) and swing the latch (Fig. 12B) from the closed position (Fig. 12) to the open position (Fig. 13A). NOTE: The Stargazer Nano Wide Skylight opens to a maximum 15 degrees. DO NOT force the skylight window open any farther than it will extend.
- Page 6 If applicable, toggle the screen latch (Fig. 17A) to slide the screens (Fig. 17B) back into the screen frame to be able to access the Stargazer Nano Wide Skylight's five skylight window latches. Pull down on the skylight window handle (Fig. 18A) and swing all five open latches (Fig. 19A) to the closed position (Fig.
- Page 7 Maintenance Spot clean only the frame with a damp cloth and mild soap. Notes Page 7 Rev: 09.28.22 CCD-0006845...
- Page 8 Lippert representative has been provided. Any unauthorized use shall void any applicable warranty. The information contained in this manual is subject to change without notice and at the sole discretion of Lippert. Revised editions are available for free download from lippert.com.
