- Page 1 Stargazer Spirit XTR Acrylic Window OEM INSTALLATION MANUAL...
- Page 2 Failure to correctly follow the provided instructions may result in death, serious personal injury, severe product and/or property damage, including voiding of the Lippert limited warranty. The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause death or serious personal injury if not performed safely and within the parameters set forth in this manual.
- Page 3 The “CAUTION” symbol above is a sign that a safety risk is involved and may cause personal injury and/or product or property damage if not safely adhered to and within the parameters set forth in this manual. Always wear eye protection when performing service, maintenance or installation procedures. Other safety equipment to consider would be hearing protection, gloves and possibly a full face shield, depending on the nature of the task.
- Page 4 Installation Skylight Roof installation Place the skylight window assembly in the rough opening of the unit, centered side to side with the hinge pins (Fig. 3A) facing towards the front of the unit. Install #8 x1" pan quad T-2 self drilling screws w/assembled 5/8" neo-bond washers (Fig. 4A) in each pre-drilled hole (Fig.
- Page 5 Fig. 9 Fig. 10 Operation All windows must be fully closed prior to travel. Failure to close windows prior to travel could result in product and/or property damage. Skylight Open Position NOTE: DO NOT rapidly slide the profiles of the screen frame assembly. Rapidly sliding the profiles may cause damage to the screen frame or ceiling of the unit.
- Page 6 If desired, slide the inner screens (Fig. 15) forward or back into a comfortable position or keep the screens back in the screen frame to get the maximum air flow from the open skylight window (Fig. 16). Fig. 15 Fig. 16 Skylight Closed Position All windows must be fully closed prior to travel.
- Page 7 Maintenance Spot clean only the frame with a damp cloth and mild soap. Notes Page 7 Rev: 09.28.22 CCD-0006512...
- Page 8 Lippert representative has been provided. Any unauthorized use shall void any applicable warranty. The information contained in this manual is subject to change without notice and at the sole discretion of Lippert. Revised editions are available for free download from lippert.com.
