SIMATIC IPC277G
SIMATIC
Industrial PC
SIMATIC IPC277G
Operating Instructions
08/2021
A5E50059956-AA
Preface
Overview
Safety instructions
Installing and connecting
the device
Commissioning the device
and device functions
Operating the device
Expanding and assigning
parameters to the device
Maintaining and repairing
the device
Technical specifications
Technical support
Markings and symbols
List of abbreviations
1
2
3
4
5
6
7
8
A
B
C

Advertisement

Table of Contents
loading

Related Manuals for Siemens SIMATIC IPC277G

Summary of Contents for Siemens SIMATIC IPC277G

  • Page 1 SIMATIC IPC277G Preface Overview SIMATIC Safety instructions Installing and connecting the device Industrial PC SIMATIC IPC277G Commissioning the device and device functions Operating the device Operating Instructions Expanding and assigning parameters to the device Maintaining and repairing the device Technical specifications...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Preface

    USB stick in PDF format (in multiple languages). Conventions The terms "PC" and "device" are sometimes used to refer to the SIMATIC IPC277G in this documentation. Instead of the specific names of the operating system, we are using the abbreviation "Windows 10"...
  • Page 4 Preface History The following editions of these operating instructions have been published: Edition Comment 08/2021 First edition SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 5: Table Of Contents

    Securing cables ........................38 3.3.7.1 Securing cables for use in hazardous areas ................. 38 3.3.8 Connect device to networks ....................39 Commissioning the device and device functions ................40 General information on commissioning ................40 SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 6 Dimension drawing of 19" device ..................80 8.3.6 Dimension drawing of 22" device ..................81 Dimension drawing of 24" device ..................82 8.3.7 Technical data ........................83 8.4.1 General technical specifications ..................83 8.4.2 Ambient conditions ......................87 SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 7 Markings and symbols ........................107 Overview ......................... 107 Safety ..........................107 Operator controls......................107 Certificates, approvals and markings ................108 Interfaces ........................109 List of abbreviations .......................... 110 Glossary ............................. 113 Index ..............................121 SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 8: Overview

    • Compact design • Rugged • Maintenance-free operation possibility SIMATIC IPC277G is available with various operating units that differ with regard to the display size. This display is a color display with a backlit "wide-screen" format TFT color display. Displays are available in the following sizes for the SIMATIC IPC277G: •...

  • Page 9: Configuration Plan

    In the BIOS setup, you can configure support of RS232/RS422/RS485 for each COM port. DP++ is a DisplayPort Dual-Mode, and it supports HDMI/DP signal output. MUI: Multi-language user interface; More language packages are available on the USB stick. You can install them according to your request. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 10: Structure Of The Devices

    Front view and side view ① Display/touch screen ② Recesses for mounting clips ③ Mounting seal Bottom view ① M.2 SSD card slot ② Interfaces and operating elements ③ Recesses for mounting clips ④ Product label SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 11: 12", 15", 19", 22" And 24" Multi-Touch Devices

    The front view on the left is the standard mounting position, side view on the right. ① Display/touch screen ② Recesses for mounting clips ③ Mounting seal Bottom view ① M.2 SSD card slot ② Interfaces and operating elements ③ Recesses for mounting clips ④ Product label SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 12: 7" And 10" Devices - Interfaces And Operator Controls

    2 × Serial interface, 9-pin RS232/RS422/RS485 D-sub connector ⑦ DPP (X70/X71) 2 × DisplayPort connection ⑧ LAN (X1P1/X2P1/X3P1) 3 × RJ45 Ethernet connections for 10/100/1000 Mbps ⑨ USB 3.1 port (X62/X63) 2 × USB 3.1 port, high current SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 13: Accessories

    Overview 1.3 Accessories Accessories Accessories from Siemens are available for your device. These are not included in the scope of delivery. Additional accessories can be found on the Internet: • Industry Mall (https://mall.industry.siemens.com) • Expansion components and accessories (https://w3.siemens.com/mcms/pc-based-automation/en/industrial- pc/expansion_components_accessories)
  • Page 14 Overview 1.3 Accessories Other accessories • Touch stylus only for devices with capacitive multi-touch screen SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 15: Safety Instructions

    The installation of expansions can damage the device, machine or plant. Device and system expansions can violate safety rules and regulations regarding radio interference suppression. If you install or exchange system expansions and damage your device, the warranty becomes void. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 16 • Replace the lithium battery only with an identical battery or types recommended by SIEMENS (article number: A5E48370874). • For any requirements on product maintenance, contact Siemens Technical support (Page 104). • Do not throw lithium batteries into fire, do not solder on the cell body, do not recharge, do not open, do not short-circuit, do not reverse polarity, do not heat above 100°C and...

  • Page 17: Security Information

    In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial security concept. Siemens’ products and solutions constitute one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks.

  • Page 18: Data Protection

    Siemens' products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customers' exposure to cyber threats.

  • Page 19: Installing And Connecting The Device

    A damaged packaging indicates that ambient conditions have already had an impact on the device. The device might be damaged. Do not dispose of the original packaging. Pack the device during transportation and storage. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 20: Identification Data Of The Device

    The device can be clearly identified with the help of this identification data in case of repairs or theft. Enter the identification data in the following table: Identification data Source Value Serial number Product label S VP ... Order number Product label 6AV7886-0..Production version Product label SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 21 Ethernet address 2 (MAC) Ethernet address 3 (MAC) Product label The following image shows the product label on the SIMATIC IPC277G as an example. COA label Microsoft Windows "Product Key" on the "Certificate Of Authenticity" (COA): The COA label is only attached to the rear of the device containing a preinstalled and activated Windows operating system.

  • Page 22: Permitted Mounting Positions

    19", 22" and 24" M.2 Module - 0W 50 °C 45 °C 40 °C The device enclosure fulfills the requirement of a fire M.2 Module - 5W 45 °C 45 °C 40 °C protection enclosure. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 23: Preparing The Mounting Cutout

    • Permissible deviation from plane at the mounting cutout: ≤ 0.5 mm This condition must be fulfilled for the mounted device. • Permissible surface roughness in the area of the seal: ≤ 120 µm (R 120) SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 24: Mounting The Device

    It may result in death or serious physical injury. Isolate the power supply to the control cabinet before opening it. Ensure that the power to the control cabinet cannot be turned on accidentally. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 25 • Equip the control cabinet with struts for stabilizing the mounting cut-out. Install struts where necessary. • If you need to clean the device, use dry ESD cleaning cloths (observing the ESD protective measures). SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 26: Secure With Mounting Clips

    To achieve the degree of protection for the device, the positions for the mounting clips shown below must be adhered to. The positions of the mounting clips are marked by stamps on the cutouts. Fit the mounting clips in all the stamped cutouts. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 27 The following table shows the type, number, and position of the mounting clips needed for the respective devices. IPC277G Mounting clips device Type Quantity Position on the device 7" display 10" display 12" display 15" display SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 28 24" display Requirement • All packaging components and protective foils should be removed from the device. • To install the device, you need the mounting clips from the accessories kit. • A T10 screwdriver SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 29: Fastening A Device Using A Vesa Adapter

    The device is mounted and the relevant degree of protection is ensured at the front. 3.2.3 Fastening a device using a VESA adapter You can also fasten the SIMATIC IPC277G using a VESA (Video Electronics Standards Association) adapter. Different models of VESA adapters are offered by third-party manufacturers.
  • Page 30 Observe any further statutory specifications applying at the location of use of the device and further applicable regulations with regard to the fastening of the device. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 31: Connecting The Device

    • Always pull out the power plug when you are not using the device or if the device is defective. The power plug must be freely accessible. • Use a central power isolating switch for cabinet installation. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 32 Utilisez des câbles en cuivre (Cu) pour tous les câbles d'alimentation qui sont raccordés à l'appareil par des bornes, par exemple les câbles d'alimentation 24 V CC sur le connecteur d'alimentation 24 V CC. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 33: Connecting The Protective Earth

    Firmly attach the cable lug to the protective conductor connection on the device using the M4 thread (see part labeled). Connect the protective conductor to the protective conductor connection of the cabinet or the plant in which the device is installed. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 34: Connecting The Power Supply To The 7" And 10" Devices

    24 VDC connection. • Tightening torque: 0.56 Nm • A slotted screwdriver with approximate 3 mm blade. Procedure Switch off the 24 VDC power supply. Connect the wires of the power supply. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 35: Connecting The Power Supply To The 12", 15", 19", 22" And 24" Devices

    • You are using the supplied terminal. • A two-core cable with a cable cross-section of 0.75 mm to 2.5 mm for the 24 VDC connection. • Tightening torque: 0.56 Nm • A slotted screwdriver with approximate 3 mm blade. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 36 3.3 Connecting the device Procedure Switch off the 24 VDC power supply. Connect the wires of the power supply. Connect the connection terminal at the marked position. Secure the connection terminal with the marked screws. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 37: Installing Ethernet Connector Strain Relief

    M3 × 8 panhead screw from the accessory. Fasten the Ethernet connector strain relief with two M3 × 6 setscrews on the right side. Secure the Ethernet connector with cable ties for each port. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 38: Installing The Cable Strain Relief

    Make sure that the cables are not crushed by the cable ties. Secure the cable mounting plate to the device using the supplied screws. The following figure shows how to fix elements on a built-in device using 7 inch of SIMATIC IPC277G as an example. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 39: Connect Device To Networks

    Control level. Information on this can be found on the SIMATIC NET Manual Collection CD. The software package and the documentation are not included in the product package. Additional information You can find additional information in Technical support. (Page 104) SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 40: Commissioning The Device And Device Functions

    The commissioning procedure in this chapter is only applicable to the IPCs with operating system. For the configurations without operating system pre-installed, contact the operating system provider to install the operating system first. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 41 "OFF" position after device has finished shutdown operation. Additional information Information on your operating system can be found on the Internet: • Microsoft® Windows® 10 (https://support.industry.siemens.com/cs/ww/en/view/109749498) • Reinstalling the operating system (Page 66) SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 42: Advanced Device Functions

    • Temperature nearby the processor A temperature error is triggered when one of the three temperature values exceeds the set temperature threshold and the following reaction is initiated: Reaction Option The DiagBase or DiagMonitor software is enabled None SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 43: Watchdog (Wd)

    The "Reset on" option immediately triggers a hardware reset that can cause data loss on Windows and damage to the installation. Watchdog monitoring times The hardware supports the following control unit times: • 1 to 256 seconds • 1 to 256 minutes SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 44: Battery Monitoring

    A memory window with a maximum size of 512 KB can be displayed by means of PCI address register. The base address is initialized via the BIOS (see section "Input/output address areas (Page 99)"). A corresponding function is implemented there for using the NVRAM under SIMATIC software controller. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 45: Operating The Device

    • When plugging or unplugging USB components • While Scandisk is running • During a BIOS update • Screen keyboard for touch device • External keyboard, connected through USB • External mouse, connected through USB SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 46: Ipc Driver And Tools

    • Always connect the device to an earth conductor. • The earth conductor from the device must be connected directly to earth with low impedance (short connection, minimum cross-section 2.5 mm = AWG14). SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 47 Windows operating system, as well as with the application to be used and its functions. Ensure that the gestures which the user executes on the multi-touch display are recognized by the application. It is possible that certain gestures need to be trained beforehand. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 48 Once the interference is over, the touch screen is no longer locked. Additional information A "touch pen system", which is suitable for both single-touch and multi-touch screens, is available on the Industry Mall (https://mall.industry.siemens.com) (6AV2181-8AV20-0AX0). SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 49: Expanding And Assigning Parameters To The Device

    • A T10 screwdriver Procedure - Opening the 7" and 10" multi-touch devices Remove the marked four screws on the rear panel of the device. Lift up the device's touch panel. Unscrew the marked screws. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 50 Lift up the device from the touch panel. Unplug the marked three cables on the motherboard. Procedure - closing the device To close the device, carry out the steps for opening the device in the reverse order. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 51: Installing The M.2 Module

    Installing the M.2 Module Introduction to the M.2 Module Siemens uses the M.2 Module to extend the Siemens IPC. It can be produced by Siemens or other third-party suppliers. Our device provides one or several M.2 Key B interfaces and mounting positions.
  • Page 52 : You can through M.2 Key E to Key B adapter accessory (Page 13) to support Key E and Key A+E module. : You can through the SIM card adapter to install the 4G/5G SIM card to connect to the network. Requirement • The device is opened. • A T8 screwdriver SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 53 Note: Make sure the M.2 Module board is located between head and spacer of assembly screw. If the M.2 Module has a cable with an additional interface-card connect to the housing opening, you need to do the following procedures: SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 54 100 mm and no longer than 200 mm. Secure the additional interface-card in the position of the COM interface with screws. Procedure - Removing the M.2 Module Follow the above steps in reverse order to remove the M.2 Module. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 55: Installing And Removing M.2 Nvme/ Sata Ssd

    • A T10 screwdriver Procedure - installing the M.2 NVMe/SATA SSD Remove the two retaining screws. Pull out the M.2 SSD slot. Place the thermal pad to the corresponding position of the M.2 NVMe/SATA SSD chip. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 56 Plug in the slot back into the device and tighten it with designated screws. Procedure - removing the M.2 NVMe/SATA SSD To remove the M.2 NVMe/SATA SSD, carry out the steps for installing the M.2 NVMe/SATA SSD in the reverse order. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 57: Maintaining And Repairing The Device

    Maintaining and repairing the device Maintenance intervals To maintain high system availability, Siemens recommends you replace some of the PC components that subject to wear in according with the replacement intervals indicated in the table below. Component Replacement interval: CMOS backup battery...

  • Page 58: Cleaning The Device Front

    You may possibly trigger unwanted actions of the device or controller that are liable to cause personal injury or damage to the machinery. Always switch off the device before you clean it. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 59 2. Moisten only the cleaning cloth, do not spray liquids directly onto the device. 3. Clean the enclosure surface with a damp cloth and make sure that no water enters the device. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 60: Installing And Removing Hardware

    – Rated voltage: 3 VDC – Max abnormal charging current: 10 mA • For any requirements on product maintenance, contact Siemens Technical support (Page 104). • Do not throw lithium batteries into fire, do not solder on the cell body, do not recharge, do not open, do not short-circuit, do not reverse polarity, do not heat above 100°C and...
  • Page 61 – Courant de charge anormal max. : 10 mA • Pour toute demande concernant la maintenance du produit, contactez le support technique (Page 104) Siemens. • Ne jetez pas au feu des piles au lithium, n'effectuez pas de soudage sur la pile, ne la rechargez pas, ne l'ouvrez pas, ne la court-circuitez pas, n'intervertissez pas les pôles, ne...

  • Page 62: Replacing The Memory Module

    DDR4 up to 3200MT/S SODIMM 260pin DDR4‐SDRAM DDR4 up to 3200MT/S SODIMM 260pin DDR4‐SDRAM DDR4 up to 3200MT/S SODIMM 260pin Requirement • The device is disconnected from the power supply. • All connecting cables on the device are unplugged. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 63 ESD directives on handling electrostatic sensitive components. Note Siemens strongly recommends that you use only memory modules approved by Siemens. Siemens disclaims any liability for impairment of functions caused by the use of third-party memory modules. CAUTION • A memory module cab be installed only when the direction is correct. Make sure your insert the memory card in the correct direction.
  • Page 64 T10 screwdriver on the motherboard. Press the retaining clips outward in the direction of the arrows to unlock the memory socket. Pull out the memory module from the socket. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 65 Unplug the marked COM cables on the motherboard and remove the interface plate of the device. Unscrew the marked two spring screws with a T8 screwdriver on the motherboard. Unscrew the marked other eight screws with a T10 screwdriver on the motherboard. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 66: Reinstalling The Operating System

    • Windows 10 operating system is installed in your IPC. • You need to connect a mouse, a monitor and a keyboard to your PC. • You also need the supplied USB stick to your PC. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 67 4. Click Accept to accept the license agreement. 5. Click Install to allow the computer to start the installation. The installation starts. 6. Click Yes to confirm the user account control question. 7. Click Finish. The chipset installation is completed. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 68 3. Click Yes to confirm the user account control question. 4. Click Next to continue. 5. Click Yes to accept license agreement. 6. Click Next to confirm the Readme File Information and move on. The installation starts. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 69: Recycling And Disposal

    Recycling and disposal Due to their low level of pollutants, the devices described in these operating instructions can be recycled. Contact a certified disposal service company for environmentally sound recycling and disposal of your old devices. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 70: Technical Specifications

    The following shows the approvals that may be available. For the device itself, it is certificated as shown on the product label and package label. ISO 9001 certificate The Siemens quality management system for all production processes (Development, Production, Sales and Service of Automation Products, -Systems and -Solutions) meets the requirements of ISO 9001:2015 This has been certified by DQS (the German society for the certification of quality management systems).
  • Page 71 Avis Canadian Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Responsible party for Supplier's Declaration of Conformity Siemens Industry, Inc. Digital Factory - Factory Automation 5300 Triangle Parkway, Suite 100 Norcross, GA 30092 Mail to: (amps.automation@siemens.com)
  • Page 72 Cat3G devices for use in Zone 2. Observe the following standards for use in hazardous areas: EN 60079-0 : 2012 + A11 : 2013, EN 60079-7 : 2010, IEC 60079-0 :2011 (Ed.6), + Corr.1. 2012 + Corr.2. 2013, IEC 60079-7 SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 73: Directives And Declarations

    The device is designed for the following areas of application corresponding to the CE marking: Scope of application Requirements for Interference emission Immunity to interference Industrial area, residential, EN 61000-6-3 +A1, CAN/CSA-CISPR EN 61000-6-1, EN 61000-6-2, NAMUR NE 21 commercial and light-industrial 22:10 SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 74: Rohs Directive

    The material with which an electrostatically-charged person comes into contact is of particular significance. The figure shows the maximum electrostatic voltages with which a person is charged, depending on humidity and material. These values conform to the specifications of IEC 61000-4-2. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 75 This way, the discharge energy does not reach and damage the sensitive components. – Discharge your body electrostatically by touching grounded metallic parts before you take a measurement at a module. Always use grounded measuring instruments. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 76: Dimension Drawings

    Technical specifications 8.3 Dimension drawings Dimension drawings 8.3.1 Dimension drawing of 7" device all dimensions in mm SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 77: Dimension Drawing Of 10" Device

    Technical specifications 8.3 Dimension drawings 8.3.2 Dimension drawing of 10" device all dimensions in mm SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 78: Dimension Drawing Of 12" Device

    Technical specifications 8.3 Dimension drawings 8.3.3 Dimension drawing of 12" device all dimensions in mm SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 79: Dimension Drawing Of 15" Device

    Technical specifications 8.3 Dimension drawings 8.3.4 Dimension drawing of 15" device all dimensions in mm SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 80: Dimension Drawing Of 19" Device

    Technical specifications 8.3 Dimension drawings 8.3.5 Dimension drawing of 19" device all dimensions in mm SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 81: Dimension Drawing Of 22" Device

    Technical specifications 8.3 Dimension drawings 8.3.6 Dimension drawing of 22" device all dimensions in mm SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 82: Dimension Drawing Of 24" Device

    Technical specifications 8.3 Dimension drawings 8.3.7 Dimension drawing of 24" device all dimensions in mm SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 83: Technical Data

    In accordance with ISO 9001 : The device may only be connected to a 24 VDC power supply which meets the requirements of a safe extra-low voltage (SELV/PELV) in accordance with IEC/EN/DIN EN/UL 61010-2-201. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 84 Emission(Telecommunications/Net 84 dB(μV) to 74 dB(μV) Q work Port), 74 dB(μV) to 64 dB(μV) M in accordance with IEC 61000-6-3 0.5 MHz to 30 MHz: + A1 74 dB(μV) Q / 64 dB(μV) M SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 85 M.2 B key module Drive, memory medium M.2 NVMe/SATA SSD • Slot X50: support NGFF M.2 2230/2242/2280 with Key M/Key B+M • 256GB Eco SSD USB stick External, can be connected via USB port SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 86 3 × Gigabit Ethernet interface (three RJ45) electrically isolated, Wake on LAN and Remote Boot are supported: • X1P1: Marwell 88E1512 • X2P1: Marwell 88E1512 • X3P1: Marwell 88E1512 COM1/2 RS232/RS422/RS485 (optional), max. 115 Kbps, D-sub connector, 9-pin SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 87: Ambient Conditions

    (Power supply is located at the top) Temperature during storage/transport -20 °C to +60 °C Gradient • Operation: Max. 10 °C/h • Storage: 20 °C/h, no condensation Relative humidity, tested in accordance with IEC 60068-2-78, IEC 60068-2-30 SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 88 5 to 8.4 Hz: 3.5 mm • 8.4 to 500 Hz: 9.8 m/s Shock resistance, tested in accordance with IEC 60068-2-27 Operation • 150 m/s², 11 ms • 5g, 30 ms Storage/transport • 250 m/s , 6 ms SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 89: Power Demand Of The Components

    A for 25 ms. A 24 V power source with a limit current lower than 2.0 A is not permitted. A voltage drop under 18.0 V during booting of the device is not permitted. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 90: Power Supply 12", 15", 19", 22" And 24" Device

    36 W 46 W Atom® x6413E Device with Intel 35 W 36 W 42 W 36 W 46 W Atom® x6414RE USB expansion See section "Power demand of the components (Page 89)" M.2 Module SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 91: Hardware Descriptions

    External • 2 × DP++ External 9-pin D-sub, either: • 2 × RS232/RS485/RS422 Only four of these USB ports may be operated simultaneously in high current mode, max. 10 W. 8.5.2.2 USB 3.1 port SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 92: Dc In Connector

    Bi-directional data A- Input/output BI_DB+ Bi-directional data B+ Input/output BI_DC+ Bi-directional data C+ Input/output BI_DC- Bi-directional data C- Input/output BI_DB- Bi-directional data B- Input/output BI_DD+ Bi-directional data D+ Input/output BI_DD- Bi-directional data D- Input/output Shield – SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 93: Displayport

    DP data 3+ Output Ground ML_Lane 3- DP data 3- Output CONFIG1 CONFIG1 CONFIG2 CONFIG2 AUX_CH+ Auxiliary channel+ Bidirectional Ground AUX_CH- Auxiliary channel- Bidirectional Hot Plug Detect Input Ground DP_PWR +3.3 V (Power switch) power out SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 94: Serial Interface

    Receive data - (I) for full-duplex mode Signal ground Pin assignment RS485 Short description Meaning Data- Transmit / receive data - (I/O) for half-duplex mode Data+ Transmit / receive data+ (I/O) for half-duplex mode Signal ground SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 95: Internal Interfaces

    8.5.3.2 USB 2.0 pin header Signal VBUS_USB1 VBUS_USB2 USB1_D- USB2_D- USB1_D+ USB2_D+ 8.5.3.3 M.2 interface M.2 Module (X100) Pin no. Signal Signal Pin no. 3.3V 3.3V 3.3V SUSCLK RESET# SIM DETECT ANTCTL3 COEX_RXD(I) ANTCTL2 SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 96 CONNECTOR KEY B CONNECTOR KEY B USB_D- W_DISABLE# USB_D+ WWAN_PWR_OFF_N 3.3V 3.3V M.2 Module (X101) Pin no. Signal Signal Pin no. 3.3V 3.3V 3.3V CFG1 SUSCLK RESET# ANTCTL3 COEX_RXD ANTCTL2 COEX_TXD ANTCTL1 COEX_NC ANTCTL0 REFCLKp SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 97: Lvds Interface

    CONNECTOR KEY B USB_D- W_DISABLE# USB_D+ 3.3V 3.3V 8.5.3.4 LVDS interface Short description Short description VCC 5V VCC 5V VCC 3.3V VCC 3.3V OTXN0- OTXP0+ OTXN1- OTXP1+ OTXN2- OTXP2+ OCLKN- OCLKP+ OTXN3- OTXP3+ ETXN0- ETXP0+ SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 98: Backlight Interface

    1. Right-click the Windows Start menu and select "Device Manager". 2. Click on the View menu and turn on " Resources by type" or "Resources by connection". All the interrupts show under the Interrupt request (IRQ) catalog. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 99: Input/Output Address Areas

    SIO logic device 8 CR F2h Watchdog state register (Page 100) SIO logic device 7 CR FDh Battery status register (Page 100) For more information and reference code for accessing to Super IO, contact Siemens Technical support. 8.5.5.2 Watchdog control register...

  • Page 100: Watchdog State Register

    Length of the memory area NVRAM base address register NVRAM memory address (default setting) Address variable (depending Address is assigned dynamically 80000 h on the slot where NVRAM is (depending on device located) configuration) SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 101: Bios Description

    Setup parameters may not be included, depending on your order. The interface of your BIOS Setup can deviate from the figures in this document. You can find a detailed description on Firmware/BIOS description (SIMATIC IPC227G, IPC277G) Operating Instructions (https://support.industry.siemens.com/cs/ww/en/view/109797240). SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 102: Bios Update

    If you have purchased a new BIOS update for your device, follow these steps to install the update: 1. Connect the device to the power supply. 2. Take the BIOS update you downloaded from the Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/view/75842768)page and place it on the USB stick.

  • Page 103: Alarm, Error And System Messages

    Check the CMOS clock. Keyboard error • Field PG: Internal keyboard defective and no external keyboard connected • Other devices: Keyboard defective or not connected SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 104: Technical Support

    Tools & downloads Please check regularly if updates and hotfixes are available for download to your device. The download area is available on the Internet at the following link: After Sales Information System SIMATIC IPC/PG (http://www.siemens.com/asis) SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 105: Troubleshooting

    1. Open the BIOS Setup. on the PC 2. Set the time or date. Although the BIOS The backup battery is dead. Replace the backup battery. setting is OK, the time and data are still wrong SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 106: Notes On The Use Of Third-Party Modules

    If the error no longer occurs, the third-party module • Different pin assignment being used was the cause of the fault. Replace the thrid-party module with a Siemens module or contact the module supplier. If the device still crashes, contact your technical support team. •...

  • Page 107: Markings And Symbols

    Disconnect the power plug before Opening for Kensington lock opening Attention ESD (Electrostatic sensitive Warning of hot surface device) Operator controls Symbol Meaning Symbol Meaning On/off switch, without electrical Eject CD/DVD isolation On/off switch, without electrical isolation SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 108: Certificates, Approvals And Markings

    CE markings for European countries Marking of Federal Communications Commission for the USA EFUP (Environment Friendly Use Approved for Korea Period) marking for China Test mark of the Underwriters Disposal information, observe the Laboratories local regulations. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 109: Interfaces

    DVI-D interface Line In LAN interface, not approved for Line Out connecting WAN or telephone Serial port Microphone input USB port Universal Audio Jack USB 2.0 high-speed port Headphone output USB 3.0 super-speed port SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 110: List Of Abbreviations

    Disk Operating System DisplayPort Deutsche Gesellschaft zur Zertifizierung von Qualitätsmanagement mBH Data Set Ready Ready for operation Data Terminal Ready Data terminal is ready Digital Versatile Disk Components sensitive to electrostatic charge European standard SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 111 Optical Disk Drive Personal computer Peripheral Component High-speed expansion bus Interconnect PCIe Peripheral Component High-speed serial, differential full-duplex PtP Interconnect express interface with high data rate. Programming device POST Power On Self Test SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 112 Intel technology which provides a virtual, closed environment. VT-d Virtualization Technology for Enables the direct assignment of a device (e.g. Directed I/O network adapter) to a virtual device. Watchdog Program monitoring with error detection and alarming. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 113: Glossary

    Communauté Européene: The CE symbol confirms the conformity of the product with all applicable EC directives such as the EMC Directive. Chipset Located on the motherboard, connects the processor with the PCI or PCIe bus and the external interfaces. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 114 TVs to computers, DVD players and similar devices. Drivers Program parts of the operating system. They adapt user program data to the specific formats required by I/O devices such as hard disk, printers, and monitors. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 115 10/100/1000 Mbps. Execute Disable Capability Hardware implementation that prevents mutual memory accesses by programs and applications. It is only effective when all relevant system components, such as processors, operating systems and applications are supported. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 116 Intel Active Management Technology This technology permits diagnostics, management and remote control of PCs. It is only effective when all relevant system components, such as processors, operating systems and applications are supported. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 117 Conventional drives can be used as USB devices. License key The license key represents the electronic license stamp of a license. Siemens AG issues a license key for each software that is protected by a license. License key USB flash drive The license key USB flash drive contains the authorizations or license keys required to enable protected SIMATIC software.
  • Page 118 Industrial Ethernet meets the requirements of industrial automation technology. Programmable controller The programmable controllers of the SIMATIC S7 system consist of a central controller, one or more CPUs, and various other modules (e.g. I/O modules). SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 119 This design makes SSDs more rugged, provides shorter access times, low energy consumption and rapid data transfer. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 120 Wake on Local area network. This function allows the PC to be started via the LAN interface. Warm restart The restart of a computer after a program was aborted. The operating system is loaded and restarted again. The CTRL+ ALT+ DEL hotkey can be used to initiate a warm restart. SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

  • Page 121: Index

    PROFINET, 41 Open, 53 Interface, 90 DiagBase software, 45 DisplayPort, 97 DiagMonitor Interfaces Temperature monitoring, 45 RJ45 Ethernet, 96 Diagnostics, 45 USB 3.0, 96 DiagBase software, 45 IT communication, 41 Directive ESD Directive, 79 SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 122 Switching on the device, 44 Device, 53 System resources, 102 Operating system Currently allocated system resources, 102 Initial commissioning, 43 Operation Capacitive multi-touch screen, 50 Touch screen, 49 Temperature monitoring, 45 Tools, 62 Touch screen Operation, 49 SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...
  • Page 123 Index UKCAI, 77 USB, 95, 99 USB 3.0 Interface, 96 Ventilation slits, 27 Warranty, 17 Watchdog, 46 Monitoring function, 46 Monitoring times, 46 SIMATIC IPC277G Operating Instructions, 08/2021, A5E50059956-AA...

Table of Contents
