IP CEILING MOUNT SPEAKER
IP SQUARE SPEAKER
Thank you for purchasing
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

TABLE OF CONTENTS

6.1. SIP Broadcasting/Two-way Communication ........................................................................ 8
6.2. VMS Broadcasting ............................................................................................................... 8
9.1. IP-A1PC580R ........................................................................................................................ 9
9.2. IP-A1PC580S ..................................................................................................................... 10
10.1. Connections to Line/Mic Input and Line Output Terminals .............................................. 10
10.2. Connections to Control Input and Output Terminals ....................................................... 11
10.3. Removable Terminal Plug Connections .......................................................................... 12
.............................................................................................................................. 13
11.1. System Settings Summary ............................................................................................... 13
11.2. System Requirements ...................................................................................................... 13
11.3. Connection with Browser ................................................................................................. 14
TOA's IP Speaker.
......................................................................................................... 2
.................................................................................................. 4
............................................................................................ 4
................................................................................................... 5
.................................................................................................................. 8
.................................................................................................... 8
............................................................................................ 9
......................................................................................................................... 9
..................................................................................................................... 10
......................................................................................... 15
.............................................................................................. 16
..................................................................................................................... 16
INSTRUCTION MANUAL
................................................................................... 6
IP-A1PC580R
IP-A1PC580S
..................................... 16

Advertisement

Table of Contents
loading

Related Manuals for Toa IP-A1PC580R

Summary of Contents for Toa IP-A1PC580R

  • Page 1: Table Of Contents

    ....................8 8. INSTALLATION PRECAUTIONS .................... 9 9. INSTALLATION ......................... 9 9.1. IP-A1PC580R ........................9 9.2. IP-A1PC580S ........................10 10. CONNECTIONS ........................10 10.1. Connections to Line/Mic Input and Line Output Terminals ..........10 10.2. Connections to Control Input and Output Terminals ............11 10.3.

  • Page 2: Safety Precautions

    PoE switching hub and contact generating sooty smoke or steam as doing your nearest TOA dealer. Make no further otherwise may result in fire or electric shock. attempt to operate the speaker in this condition...
  • Page 3 Modifications Any modifications made to this device that are not approved by TOA Corporation may void the authority granted to the user by the FCC to operate this equipment.

  • Page 4: Summary And Features

    2. SUMMARY AND FEATURES The IP-A1PC580R/A1PC580S IP speakers are equipped with a built-in power amplifier and sound source memory. It can be connected to and used over a local network. • Power is supplied by way of PoE switching hubs.

  • Page 5: Dimensional Drawings

    4. DIMENSIONAL DRAWINGS Unit: mm [IP-A1PC580R] 138 (5.43") HY-BC580U (option) Screw (accessory) Ceiling board IP-A1PC580R 324 (12.76") [IP-A1PC580S] 138 (5.43") 318 (12.52")

  • Page 6: Nomenclature And Functions

    5. NOMENCLATURE AND FUNCTIONS [IP-A1PC580R] [IP-A1PC580S] 10 11...
  • Page 7 1. Line output signal indicator (green) 7. Control input terminals Lights green when a signal is outputting from Allows input of control signals from this speaker or Line output. connected external equipment to enable actions set in the Event settings. 2. Line/Mic input signal indicator (green, red) Lights green when a signal is input to Line/ 8. Functional ground terminal Mic input.

  • Page 8: System Example

    Monitoring with audio 7. HANDLING PRECAUTIONS • Please apply the latest firmware version to this product. The latest version is available at the TOA DATA Library (https://www.toa-products.com/international/). • As this product is IP-based, a slight time lag between actual and broadcast may happen.

  • Page 9: Installation Precautions

    • When attaching the safety wire, be sure that it is fastened securely to the safety wire attachment ring. Safety wire attachment Knockout 9. INSTALLATION HY-BC580U 9.1. IP-A1PC580R (option) Use back can HY-BC580U if UL 2043 (use in air handling spaces) is required. Mounting hole: All wire entry knockouts should use metal ø228.6 mm (ø9")

  • Page 10: Ip-A1Pc580S

    To amplifier, etc. other sound sources Change the DIP switch settings while the power is off. When the connected unit has an unbalanced input, make the connections as follows: HOT (H) IP-A1PC580R Connected unit Cold (C) IP-A1PC580S Earth (E) Shield...

  • Page 11: Connections To Control Input And Output Terminals

    Allowable current: 10 mA or less From external control device’s From external control device’s control output terminals control input terminals For settings, please refer to the separate setup manual. The latest version of the setup manual is available on the TOA DATA Library (https://www.toa-products.com/international/).

  • Page 12: Removable Terminal Plug Connections

    10.3. Removable Terminal Plug Connections Please note the following points when making connections to the control input or output terminals using the supplied removable terminal plugs: Slotted screwdriver • Do not tin stripped wire ends with solder. Soldered wire ends will be crushed when the terminal plug screws are tightened, leading to higher contact Tighten Loosen...

  • Page 13: Settings

    System Date and time settings, NTP server settings, time zone settings For more information, please refer to the separate setup manual. The latest version of the setup manual is available on the TOA DATA Library. (https://www.toa- products.com/international/) 11.2. System Requirements Connectable system requirements are as follows: Display Resolution: 1366 ×...

  • Page 14: Connection With Browser

    The Status screen is displayed, enabling a range of settings. Note For details regarding the setting method, please refer to the separate setup manual. The latest version of the setup manual is available on the TOA DATA Library. (https://www.toa-products.com/ international/)

  • Page 15: Initialization Of Settings

    12. INITIALIZATION OF SETTINGS Follow the procedure below to return all IP speaker settings to their default: When initialized with the Reset key, the IP speaker’s sound source files are left in “Media”, not deleted. Initialization to factory defaults, including deletion of sound source files, should be performed using the browser settings menu.

  • Page 16: Cautions Regarding The Avc/H.264 Patent License

    13. CAUTIONS REGARDING THE AVC/H.264 PATENT LICENSE TOA’s IP-A1PC580R/A1PC580S IP speakers employ MPEG technology (AVC/H.264 Standard) regarding the handling of image information. TOA Corporation has received approval to use this technology from MPEG LA, LLC, the patent management group. Please note that the use of this product is prohibited except the following cases: The use of the product is intended for personal use of a user of the MPEG technology and also for nonprofit use, which includes (i) video encoding conforming to the AVC/H.264 Standard (hereinafter...
